HP-Agilent/Keysight 6625A

Keysight high performance DC power supplies offer spec and accuracy for test optimization. The precision multiple output, 25W – 50W GPIB 6625A, 6626A, 6628A, and 6629A provide fast, low-noise outputs- dual-range, precision low current measurement- built-in measurements and advanced programmable features- and protection features to ensure DUT safety. * Low-range volts, amps 25W: 0 to 7 V, 0 to 15 mA. * Low-range volts, amps 50W: 0 to 16 V, 0 to 200 mA. * High range volts, amps 25W: 0 to 50 V, 0 to 500 mA. * High range volts, amps 50W: 0 to 50 V, 0 to 1 A or, 0 to 16 V, 0 to 2 A. * Voltage 25W: 0.016% + 1.5 mV (low), 10 mV (high). * Voltage 50W: 0.016% + 53 mV (low), 10 mV (high). * Current 25W: 0.04% + 15 µA (low), 100 µA (high). * Current 50W: 0.04% + 185 µA (low), 500 µA (high). * Voltage rms: 500 µV. * Peak-to-peak: 3 mV. * Current rms: 0.1 mA.
25W or 50W, 2 outputs
