EIP 548B

The EIP 548B frequency counters provide the capability to selectively measure individual signals in a multi-signal environment. Additionally, they can simultaneously measure the average power level of the isolated input signal. The 548B extends the range to 26.5 GHz. – The frequency range is 10Hz to 26.5GHz and -30 dBm Sensitivity. – Power measurement to 0.1 dB resolution. – Power measurement accuracy to ±0.5 dB typical. – 200 Watt (+53 dBm) peak damage protection. – 10 dB automatic amplitude discrimination. – 200 ms acquisition time. – Up to 600MHz/sec tracking speed. – 20MHz P-P FM tolerance up to a 10MHz rate
