Showing 181–210 of 1386 results
-
Attenuator
M/A-COM EUROTEC 2082-6042-10
RF Attenuator – Coaxial from XMA
Connectors SMA Male (Plug)/ SMA Female (Jack)
18 GHz, 500 W
The overall length of the XMA SMA Coaxial Attenuators are .86 inch for 3, 6 and 10 dB and 1.02 Inches for 20 and 30 dB.
The body is passivated stainless steel round body design with an operating temp range of -65c to +125c.
The maximum VSWR is < 1.15:1 @ DC-4GHz, <1.25:1 @ 4-12.3 GHz and <1.35 @ 12.4-18. DatasheetSKU: n/a -
Attenuator
HUBER SUHNER 6803.01.A + HUBER SUHNER 6806.01.A
HUBER+SUHNER 6803.01.A
RF Attenuator 50 Ω, 4 GHz, 3 dB
Connectors (side 1 / side 2) BNC plug (male) / BNC jack (femaleHUBER+SUHNER 6806.01.A
RF Attenuator 50 Ω, 4 GHz, 6 dB
Connectors (side 1 / side 2) BNC plug (male) / BNC jack (female)
Datasheet 6806.01.A
Datasheet 6803.01.ASKU: n/a -
Power Sensor
HP-Agilent/Keysight R8486A
HP AGILENT KEYSIGHT R8486A Thermocouple Waveguide Power Sensor 26.5 GHz to 40 GHz
The R8486A power sensor is designed for use with the EPM series, EPM-P series, 70100A, E1416A, 435A/B, 436A, 437A, 438A series power meters. The R8486A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• 50 MHz calibration port
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST) millimeter-wave sensor calibration
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 26.5 GHz to 40 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -10 dBm to +20 dBm)
• UG-599/U waveguide flange
DatasheetSKU: n/a -
Power Sensor
AGILENT – Hp/Keysight 8487A
HP AGILENT KEYSIGHT 8487A POWER SENSOR 50 MHz to 50 GHz
The 8487A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters. The 8487A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 50 MHz to 50 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• 2.4 mm(m) connector
Scheda TecnicaSKU: n/a -
Power Sensor
HP-Agilent/Keysight 8485A
HP AGILENT KEYSIGHT 8485A POWER SENSOR 50 MHz to 26.5 GHz
The 8485A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters. The 8485A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 50 MHz to 26.5 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• 3.5 mm(m) connector
DatasheetSKU: n/a -
Power Sensor
HP-Agilent/Keysight 8481A
HP AGILENT KEYSIGHT 8481A POWER SENSOR 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
The 8481A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 10 MHz to 18 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• N (m) connectorSKU: n/a -
ADAPTOR
HUBER + SUHNER 33PC35-50-01-1/199 NE ADAPTOR PLUG/JACK 22644362
The HUBER + SUHNER 33PC35-50-01-1/199 NE is a Adaptor plug/jack PC 3.5 plug (male) / PC 3.5 jack (female).
It used for test and measurement applications precision adaptor* Interface 1: PC 3.5 plug (male)
* Interface 2: PC 3.5 jack (female)
* Impedance: 50 Ω
* Interface freq. Max: 33 GHz
* Frequency Range 1: 0 GHz to 18 GHz
* Frequency Range 2: 18 GHz to 26.5 GHz
* Return loss band 1: 28 dB
* Return loss band 2: 23 dB
* BATCH Nr 02.26942
* Manufacture code: 22644362
DatasheetSKU: n/a€50.00 View Product -
Rohde & Schwarz ESHS10
R&S ESHS10 EMI Test Receivers, 10: 9 kHz to 30 MHz
The receivers ESHS 10 is suitables for measuring electromagnetic interference in line with commercial standards:
• CISPR16, VDE0876 and ANSI C63.2
• EN55011 to 55022, ETS, FCC, VCCI and VDE 0871 to 0879 and ANSI C63.4The instruments are ideal for routine tasks in industry such as development and approval tests in line with commercial standards. Featuring mains-independent battery powering, they are also suitable for mobile applications at EMC service providers, test houses and safety standard authorities.
Superior circuit design
• High measurement accuracy, typical error 0.5 dB
• Wide dynamic range, typical noise figure 7 dB with preamplifier, third-order intercept point 20 dBm (without preamplifier)
• Calibrated attenuator with high pulse loading capacity, switchable in 10-dB steps from 0 to 120 dB
• Comprehensive preselection filters
• Switchable preamplifier with wide dynamic range
• Crystal-stabilized, fast synthesizer with high resolution and sweep mode for fast frequency scanning
• High-level mixer with high oscillator rejection
• Delay-equalized IF filtersDemodulation
• Parallel detectors for average, peak and quasi-peak indication
• 60 dB operating range also for quasipeak and average value indication
• Highly linear envelope detector with more than 70 dB dynamic range
• AM and A0 demodulators (ESVS also FM)
• Logarithmic amplifier with more than 70 dB dynamic range
• Peak indication with automatic consideration of IF bandwidth correction values for broadband interference measurements
• Automatic overload detection in mixer stages and in test channel by permanently activated peak detectorsPowerful processor system
• Manual operation or internal or external processor control
• Flash EPROMs for convenient and fast firmware update through PC
• Macros for automatic and semiautomatic test runs
• Automatic level calibration
• Automatic consideration of frequencydependent transducer factors
• All built-in functions fully programmable via IEC/IEE bus
• Fast measurement in external trigger mode; output of up to 5000 values/s via IEC/IEEE bus, up to 400 values/s including frequency change within certain frequency bands
• 12-bit A/D converter with short conversion time, measurement time selectable between 1 ms and 100 s
• High measurement accuracy thanks to automatic total calibration
• Automatic monitoring of all synthesizer loops and supply voltages during operationOptimum result display and printout
• Measurement of voltage, field strength, current and pulse spectral density with display of relevant units
• Indication of result on analog meter or digital display with 0.1 dB resolution
• Output of results as lists and diagrams on printer including limit linesFurther features
• Digital level indication on LCD and analog level indication on moving-coil meter taking into account transducer factors and their units
• Numerous interfaces for driving or feeding additional devices
• AC supply as well as battery powering for mobile applications
DatasheetSKU: n/a -
Power Supply
HP-Agilent/Keysight 6645A
HP high performance DC power supplies offer speed and accuracy for test optimization. The single output, 200 W, GPIB 6641A-6645A provide fast, low-noise outputs; analog control of output voltage and current; fan-speed control to minimize acoustic noise; as well as parallel and series connections of multiple units.
The HP 180W, GPIB, single output 6645A is a versatile programmable supply designed to maximize test throughput during design verification or on the production line, and is fully programmable to help reduce test time through a variety of automated capabilities.
Output Ratings
Output voltage: 0 to 120 V
Output current (40° C): 0 to 1.5 A
Maximum current (50° C/55° C): 1.4 A/1.3 AProgramming Accuracy at 25°C ±5°C
Voltage 0.06% + 51 mV
Current 0.15% + 1.7 mARipple & Noise (20 Hz – 20 MHz)
Voltage rms: 700 µV
Voltage peak-to-peak: 7 mV
Current rms: 1 mA
DatasheetSKU: n/a -
CHROMA 2327 VIDEO PATTERN GENERATOR, WITH REMOTE KEYPAD A225003
Chroma 2227/2327 Video Pattern Generators not only combine the signals of analog (250MHz) and digital (165MHz) to provide the VESA standard video signal source for LCD Monitor/CRT Monitor, it also integrates the TV (NTSC / PAL/SECAM) signal to fit in the multimedia display applications for the newly risen LCD TV, PDP TV, LCOS TV and DLP RPTV industries. Users can utilize the software application, VPG PLUS, either on PC or on the Video Pattern Generator itself to edit various timing parameters, patterns and test procedures. Its complete test functions can fully meet the requirements for R&D, production test and quality assurance in all video related industries.
Analog/TMDS/SDTV/HDTV Signals Support The 2227/2327 Video Pattern Generators equipped with microprocessor and precision Phase Locked Loop (PLL) circuit have accuracy up to 25PPM/1PPM after calibration are featured in high accuracy, high stability and high speed. Moreover, all of its horizontal timing parameters are in one-pixel resolution, which can provide the video signal with 256-color per pixel. For analog signal output, its pixel frequency can up to 250MHz and the RGB signals meet the RS-343A standard. It also supports Y/R-Y/B-Y, Y/Pb/Pr, Y/Cb/Cr and sync signals for tri-level output to fulfill the test requirements for HDTV.
The digital signal is in TMDS output with pixel frequency from 25~165MHz and test screen resolution up to UXGA. Its DVI-I Connector containing digital, analog and DDC2B signals meet the DDWG DVI standard. In addition Electrostatic Discharge (ESD) and Surge are designed for protection.
As to the TV output spec, the image and chromaticity of 2227/2327 meet the regulations of NTSC/PAL/SECAM, which the output signals include VBS composite signal with BNC and Y/C (Luminance/Chrominance) image/chromaticity separation signal with S-Video output connector.
Chroma 2227/2327 Video Pattern Generators have built in rich timing files and various patterns selections to increase the product usage as well as to decrease the engineer workload for setting operation. The embedded NVRAM memory device and optional memory card allow users to save the data files of accomplished settings for recall. The parameters for output patterns and timings can be programmed by PC via RS232C and loaded to memory card via the 22xx Series VPGs, meanwhile the operation sequences can be programmed and controlled by VPGplus on PC via RS232C interface. VPGplus provides a convenient operating environment for VPG users. Users can set the VPG parameters for the data of timing, pattern, program and icon, etc.
Following the rising market of multi-media display the competition and demand for product quality are getting more and more sever as consumers often request and search for higher pixels with less bad cells as well as low cost video display products before purchasing. Under this circumstance, the Chroma 2227/2327 Video Pattern Generators with high resolution test quality can meet the multi-media display applications at present, and the features described above make the Video Pattern Generator a indispensable testing tool for the RD engineers and production manufacturers.
Key Features:
* Analog pixel rate 250MHz* TMDS pixel rate 165MHz
* TV NTSC/PAL/SECAM signal support
* S-Video / VBS composite output
* 2 level SDTV & 3 level HDTV Format
* HDCP V.1.0 support
* Closed Caption function support
* V-Chip function support
* Y/Pb/Pr,Y/Cb/Cr,Y/R-Y/B-Y output
* One-pixel resolution
* Display size up to 4096×2048 max
* Picture for BMP format support
* DDC2B Read / Write
* PC remote control
* Storing data with memory cards
* Supporting Gamma calibration
* ESD circuit protection built-in
DatasheetSKU: n/a -
Oscilloscope 2 channels
RIGOL MSO5152-E
MSO5000-E series digital oscilloscope is a high-performance oscilloscope model designed based on RIGOL UltraVision II technology. With a 9-inch capacitive multitouch screen, the MSO5000-E series integrates 7 independent instruments into one, delivering super sample bandwidth ratio, extremely high memory depth, and other excellent specifications. It is compact and portable in design, and all of the MSO5000-E series products support multiple channels, and the upgrade of the analysis software. As it integrates many functions of multiple instruments, different user groups can have more choices in selecting their desired product based on their needs, helping them save their budget to a large extent while enjoying the superior test support and user experience.
* Analog bandwidth: 150 MHz
* 2 analog channels, 1 EXT channel, and a standard configuration of 16 digital channels (required to purchase the probe)
* Up to 4 GSa/s real-time sample rate
* Up to 100 Mpts memory depth (option)
* High waveform capture rate (over 300,000 wfm/s)
* Auto measurement of 41 waveform parameters; full-memory hardware measurement function
* A variety of serial protocol triggers and decodes
* Up to 450,000 frames of hardware real-time and ceaseless waveforms recording and playback functions
* Independent search, navigation keys, and event table
* Built-in advanced power analysis software (option)
* Integrates 7 independent instruments into 1, including a digital oscilloscope, a logic analyzer, a spectrum analyzer, an arbitrary waveform generator, a digital voltmeter, a frequency counter and totalizer, and a protocol analyzer
* 9-inch capacitive multi-touch screen, 256-level intensity grading display, with color persistence
* Multiple interfaces available: USB HOST&DEVICE, LAN(LXI), HDMI, TRIG OUT, and USB-GPIB
* Web Control remote command
* Unique online version upgrade
* Novel and delicate industrial design, easy to operateSKU: n/a€899.00 View Product -
DC Electronic Load
Höcherl & Hackl PLI 2112 / H&H PLI2112
Höcherl & Hackl PLI 2112 Electronic Load
The PLI series of electronic loads provide a comfortable operation by a graphical user interface. The PLI series highlight is the extensive variety of standard interfaces. Apart from Ethernet, USB, RS-232 and Analog interface there is a standard CAN interface. Programming is done in SCPI syntax.
The units provide constant current mode, constant voltage mode, constant power mode and constant resistance mode. In addition, protections for current and voltage can be set in any mode. A static data acquisition function allows to store measurement data on an external USB flash drive. Dynamic operation can be configured by up to 300 list point settings. The Electronic Load saves the synchronously acquired measurement data with timestamp. A configurable trigger model controls data acquisition, static and dynamic settings.
Special applications, such as fuel cell tests, need to load the DUT down to almost 0 V. For these purposes we supply a range of models with an integrated zero-volt supply.– Voltage: 120 V
– Current: 60 A
– Power: 2100 W
DatasheetSKU: n/a -
Digital Multimeter
FLUKE 8846A
Digital Multimeter Fluke 8846A, 1000V1000V ca, 10A ca, CAT I, CAT II True RMS
The Fluke 8845A and 8846A 6.5 digit precision CAT II 600 V multimeters have the precision and versatility to handle your most demanding measurements, on the bench or in a system. These meters are both high performance and feature rich, yet also remarkably easy to use. These digital multimeters perform the functions you would expect to see in a multifunction DMM, including measuring volts, ohms, and amps. Basic V dc accuracy of up to 0.0024 %, 10 A current range, and a wide ohms range give you an unbeatable combination of measurement capability. You can also use the 8845A and 8846A to measure temperature, capacitance, period, and frequency—the functions of a counter, capacitance meter, and thermometer are built in for unparalleled versatility. Extend the meters’ utility even more with their graphical display modes, including TrendplotTM paperless recorder mode, statistics and histograms—features you won’t find on other multimeters. Of course, these meters are also durable and dependable, features you expect from any Fluke meter. This unique combination of features and performance makes the 8845A and 8846A an unbeatable value for a wide variety of applications, including manufacturing test, research and development, and service.
DatasheetSKU: n/a -
Power Supply
TDK-Lambda GEN-60-40-1P230
Programmable Lab Power Supply 0-60 V DC 0-40 A
This 2400 W lab power supply sets new standards. They are currently the most powerful 1 HU lab power supplies on the market. Another advantage is that you can stack one device on top of another which means that it needs no air slit either above or below and can actually get by on 1 HU.
Output voltages of up to 60 V and output currents of up to 40 A can be adjusted directly on the device or remotely via the built-in RS232/RS485 interface. All important functions can also be programmed via analogue inputs (control voltage 0 5V, 0-10V, control current 4-20 mA or via external resistor; relevant drivers are available for the digital control e.g., via LabView and LabWindows). High-resolution 16-bit A/D and D/A converters enable very precise settings and programming; the dial controls on the device can be switched between coarse and fine adjustment.
A dual digital display shows the current values, and various status information (andOver Voltage Protection, Under Voltage Limit, overload mode, address settings again), and a monitor output provides corresponding analog voltages (0 – 5 V or 0 – 10 V) for an external monitoring The device can naturally be operated as a constant voltage as well as a constant current source and can, if necessary, automatically switch between these operating modes. Several devices can be switched serially or in parallel. This GEN/H model is half the structural shape of 19″ racks.
DatasheetSKU: n/a -
Power Supply
KEYSIGHT N8940A
KEYSIGHT N8940A Alimentatore CC con autoranging, 80 V, 170 A, 5000 W, 400 V CA.
La serie Keysight N8900 offre alimentazione CC programmabile a uscita singola programmabile da 5 kW, 10 kW e 15 kW per applicazioni ATE che richiedono la giusta quantità di prestazioni al giusto prezzo. La caratteristica di uscita a regolazione automatica degli alimentatori serie N8900 consente una flessibilità senza precedenti offrendo una vasta gamma di combinazioni di tensione e corrente a piena potenza. Gli alimentatori con caratteristiche di uscita “rettangolari” o tradizionali forniscono piena potenza con una sola combinazione di tensione e corrente. Solo un N8900 fa il lavoro di più alimentatori. È come avere molti alimentatori in uno!
La serie N8900 offre potenza di uscita stabile, misurazioni di tensione e corrente incorporate e tensione e corrente di uscita con autorangolazione da 80 V a 1500 V e da 10 A a 510 A. Questi alimentatori offrono molte funzionalità pronte per il sistema come interfacce I / O standard multiple per semplificare e accelerare lo sviluppo del sistema di test e il design compatto 3U per risparmiare spazio nel rack. Se è necessaria più potenza, è possibile mettere in parallelo più unità N8900 per creare un “unico” alimentatore con> 100 kW di potenza totale in uscita. Il controllo master / slave incorporato consente la programmazione come se fosse solo un grande alimentatore; non è necessario programmare ciascuna fornitura singolarmente.Uscita autoranging – fa il lavoro di più alimentatori!
Potenza di uscita massima di 5 kW, 10 kW e 15 kW
Fino a 1500 V e fino a 510 A
14 diverse combinazioni di tensione, corrente e potenza disponibili in 208 V CA o 400 V CA (28 modelli in totale)
La giusta quantità di prestazioni al giusto prezzo
Unità facilmente parallele per creare un “unico” alimentatore con> 100 kW di potenza
Misura di tensione e corrente incorporata
Alta densità di potenza, 15 kW in soli 3U (5,25 “/ 13,34 cm)
Protezione da sovratensione, sovracorrente e sovratemperatura
Interfacce LAN (LXI Core), USB, GPIB e analogiche tutte standardValori nominali DC
Voltaggio: da 0 a 80 V.
Corrente: da 0 a 170 A
Potenza: 5000 W.Ingresso AC
Intervallo di tensione: 360-440 V CA.
Accuratezza della programmazione
Tensione: 0,1% del fondo scala
Corrente: 0,2% del fondo scala
Scheda TecnicaSKU: n/a -
Power Supply
H10S CLT-100
Exclusive power supply is required for DC screwdrivers.
● Exclusive power supply converts the electric current from AC outlet (on the primary side) to low-voltage output (HI: DC30V) or (LOW: about DC20V) to supply it to the screwdriver.
● Safe and quiet rotation.
● Please always use HIOS screwdriver in combination with HIOS power supply for safe screw tightening.
● Stable power supply with multiple inputs (AC100V to 240V).
(Not applicable to CLT-100 and MC-70L)SKU: n/a€120.00 View Product -
Fucntion/Arbitrary Waveform Generatr
RIGOL DG2102
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
DatasheetSKU: n/a€890.00 View Product -
Function/Arbitrary Waveform Generator
RIGOL DG2072
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
DatasheetSKU: n/a€720.00 View Product
-
Attenuator
M/A-COM EUROTEC 2082-6042-10
RF Attenuator – Coaxial from XMA
Connectors SMA Male (Plug)/ SMA Female (Jack)
18 GHz, 500 W
The overall length of the XMA SMA Coaxial Attenuators are .86 inch for 3, 6 and 10 dB and 1.02 Inches for 20 and 30 dB.
The body is passivated stainless steel round body design with an operating temp range of -65c to +125c.
The maximum VSWR is < 1.15:1 @ DC-4GHz, <1.25:1 @ 4-12.3 GHz and <1.35 @ 12.4-18. Datasheet -
Attenuator
HUBER SUHNER 6803.01.A + HUBER SUHNER 6806.01.A
HUBER+SUHNER 6803.01.A
RF Attenuator 50 Ω, 4 GHz, 3 dB
Connectors (side 1 / side 2) BNC plug (male) / BNC jack (femaleHUBER+SUHNER 6806.01.A
RF Attenuator 50 Ω, 4 GHz, 6 dB
Connectors (side 1 / side 2) BNC plug (male) / BNC jack (female)
Datasheet 6806.01.A
Datasheet 6803.01.A -
Power Sensor
HP-Agilent/Keysight R8486A
HP AGILENT KEYSIGHT R8486A Thermocouple Waveguide Power Sensor 26.5 GHz to 40 GHz
The R8486A power sensor is designed for use with the EPM series, EPM-P series, 70100A, E1416A, 435A/B, 436A, 437A, 438A series power meters. The R8486A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• 50 MHz calibration port
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST) millimeter-wave sensor calibration
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 26.5 GHz to 40 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -10 dBm to +20 dBm)
• UG-599/U waveguide flange
Datasheet -
Power Sensor
AGILENT – Hp/Keysight 8487A
HP AGILENT KEYSIGHT 8487A POWER SENSOR 50 MHz to 50 GHz
The 8487A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters. The 8487A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 50 MHz to 50 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• 2.4 mm(m) connector
Scheda Tecnica -
Power Sensor
HP-Agilent/Keysight 8485A
HP AGILENT KEYSIGHT 8485A POWER SENSOR 50 MHz to 26.5 GHz
The 8485A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters. The 8485A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 50 MHz to 26.5 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• 3.5 mm(m) connector
Datasheet -
Power Sensor
HP-Agilent/Keysight 8481A
HP AGILENT KEYSIGHT 8481A POWER SENSOR 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
The 8481A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 10 MHz to 18 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• N (m) connector -
ADAPTOR
HUBER + SUHNER 33PC35-50-01-1/199 NE ADAPTOR PLUG/JACK 22644362
The HUBER + SUHNER 33PC35-50-01-1/199 NE is a Adaptor plug/jack PC 3.5 plug (male) / PC 3.5 jack (female).
It used for test and measurement applications precision adaptor* Interface 1: PC 3.5 plug (male)
* Interface 2: PC 3.5 jack (female)
* Impedance: 50 Ω
* Interface freq. Max: 33 GHz
* Frequency Range 1: 0 GHz to 18 GHz
* Frequency Range 2: 18 GHz to 26.5 GHz
* Return loss band 1: 28 dB
* Return loss band 2: 23 dB
* BATCH Nr 02.26942
* Manufacture code: 22644362
Datasheet -
Rohde & Schwarz ESHS10
R&S ESHS10 EMI Test Receivers, 10: 9 kHz to 30 MHz
The receivers ESHS 10 is suitables for measuring electromagnetic interference in line with commercial standards:
• CISPR16, VDE0876 and ANSI C63.2
• EN55011 to 55022, ETS, FCC, VCCI and VDE 0871 to 0879 and ANSI C63.4The instruments are ideal for routine tasks in industry such as development and approval tests in line with commercial standards. Featuring mains-independent battery powering, they are also suitable for mobile applications at EMC service providers, test houses and safety standard authorities.
Superior circuit design
• High measurement accuracy, typical error 0.5 dB
• Wide dynamic range, typical noise figure 7 dB with preamplifier, third-order intercept point 20 dBm (without preamplifier)
• Calibrated attenuator with high pulse loading capacity, switchable in 10-dB steps from 0 to 120 dB
• Comprehensive preselection filters
• Switchable preamplifier with wide dynamic range
• Crystal-stabilized, fast synthesizer with high resolution and sweep mode for fast frequency scanning
• High-level mixer with high oscillator rejection
• Delay-equalized IF filtersDemodulation
• Parallel detectors for average, peak and quasi-peak indication
• 60 dB operating range also for quasipeak and average value indication
• Highly linear envelope detector with more than 70 dB dynamic range
• AM and A0 demodulators (ESVS also FM)
• Logarithmic amplifier with more than 70 dB dynamic range
• Peak indication with automatic consideration of IF bandwidth correction values for broadband interference measurements
• Automatic overload detection in mixer stages and in test channel by permanently activated peak detectorsPowerful processor system
• Manual operation or internal or external processor control
• Flash EPROMs for convenient and fast firmware update through PC
• Macros for automatic and semiautomatic test runs
• Automatic level calibration
• Automatic consideration of frequencydependent transducer factors
• All built-in functions fully programmable via IEC/IEE bus
• Fast measurement in external trigger mode; output of up to 5000 values/s via IEC/IEEE bus, up to 400 values/s including frequency change within certain frequency bands
• 12-bit A/D converter with short conversion time, measurement time selectable between 1 ms and 100 s
• High measurement accuracy thanks to automatic total calibration
• Automatic monitoring of all synthesizer loops and supply voltages during operationOptimum result display and printout
• Measurement of voltage, field strength, current and pulse spectral density with display of relevant units
• Indication of result on analog meter or digital display with 0.1 dB resolution
• Output of results as lists and diagrams on printer including limit linesFurther features
• Digital level indication on LCD and analog level indication on moving-coil meter taking into account transducer factors and their units
• Numerous interfaces for driving or feeding additional devices
• AC supply as well as battery powering for mobile applications
Datasheet -
-
Power Supply
HP-Agilent/Keysight 6645A
HP high performance DC power supplies offer speed and accuracy for test optimization. The single output, 200 W, GPIB 6641A-6645A provide fast, low-noise outputs; analog control of output voltage and current; fan-speed control to minimize acoustic noise; as well as parallel and series connections of multiple units.
The HP 180W, GPIB, single output 6645A is a versatile programmable supply designed to maximize test throughput during design verification or on the production line, and is fully programmable to help reduce test time through a variety of automated capabilities.
Output Ratings
Output voltage: 0 to 120 V
Output current (40° C): 0 to 1.5 A
Maximum current (50° C/55° C): 1.4 A/1.3 AProgramming Accuracy at 25°C ±5°C
Voltage 0.06% + 51 mV
Current 0.15% + 1.7 mARipple & Noise (20 Hz – 20 MHz)
Voltage rms: 700 µV
Voltage peak-to-peak: 7 mV
Current rms: 1 mA
Datasheet -
CHROMA 2327 VIDEO PATTERN GENERATOR, WITH REMOTE KEYPAD A225003
Chroma 2227/2327 Video Pattern Generators not only combine the signals of analog (250MHz) and digital (165MHz) to provide the VESA standard video signal source for LCD Monitor/CRT Monitor, it also integrates the TV (NTSC / PAL/SECAM) signal to fit in the multimedia display applications for the newly risen LCD TV, PDP TV, LCOS TV and DLP RPTV industries. Users can utilize the software application, VPG PLUS, either on PC or on the Video Pattern Generator itself to edit various timing parameters, patterns and test procedures. Its complete test functions can fully meet the requirements for R&D, production test and quality assurance in all video related industries.
Analog/TMDS/SDTV/HDTV Signals Support The 2227/2327 Video Pattern Generators equipped with microprocessor and precision Phase Locked Loop (PLL) circuit have accuracy up to 25PPM/1PPM after calibration are featured in high accuracy, high stability and high speed. Moreover, all of its horizontal timing parameters are in one-pixel resolution, which can provide the video signal with 256-color per pixel. For analog signal output, its pixel frequency can up to 250MHz and the RGB signals meet the RS-343A standard. It also supports Y/R-Y/B-Y, Y/Pb/Pr, Y/Cb/Cr and sync signals for tri-level output to fulfill the test requirements for HDTV.
The digital signal is in TMDS output with pixel frequency from 25~165MHz and test screen resolution up to UXGA. Its DVI-I Connector containing digital, analog and DDC2B signals meet the DDWG DVI standard. In addition Electrostatic Discharge (ESD) and Surge are designed for protection.
As to the TV output spec, the image and chromaticity of 2227/2327 meet the regulations of NTSC/PAL/SECAM, which the output signals include VBS composite signal with BNC and Y/C (Luminance/Chrominance) image/chromaticity separation signal with S-Video output connector.
Chroma 2227/2327 Video Pattern Generators have built in rich timing files and various patterns selections to increase the product usage as well as to decrease the engineer workload for setting operation. The embedded NVRAM memory device and optional memory card allow users to save the data files of accomplished settings for recall. The parameters for output patterns and timings can be programmed by PC via RS232C and loaded to memory card via the 22xx Series VPGs, meanwhile the operation sequences can be programmed and controlled by VPGplus on PC via RS232C interface. VPGplus provides a convenient operating environment for VPG users. Users can set the VPG parameters for the data of timing, pattern, program and icon, etc.
Following the rising market of multi-media display the competition and demand for product quality are getting more and more sever as consumers often request and search for higher pixels with less bad cells as well as low cost video display products before purchasing. Under this circumstance, the Chroma 2227/2327 Video Pattern Generators with high resolution test quality can meet the multi-media display applications at present, and the features described above make the Video Pattern Generator a indispensable testing tool for the RD engineers and production manufacturers.
Key Features:
* Analog pixel rate 250MHz* TMDS pixel rate 165MHz
* TV NTSC/PAL/SECAM signal support
* S-Video / VBS composite output
* 2 level SDTV & 3 level HDTV Format
* HDCP V.1.0 support
* Closed Caption function support
* V-Chip function support
* Y/Pb/Pr,Y/Cb/Cr,Y/R-Y/B-Y output
* One-pixel resolution
* Display size up to 4096×2048 max
* Picture for BMP format support
* DDC2B Read / Write
* PC remote control
* Storing data with memory cards
* Supporting Gamma calibration
* ESD circuit protection built-in
Datasheet -
Oscilloscope 2 channels
RIGOL MSO5152-E
MSO5000-E series digital oscilloscope is a high-performance oscilloscope model designed based on RIGOL UltraVision II technology. With a 9-inch capacitive multitouch screen, the MSO5000-E series integrates 7 independent instruments into one, delivering super sample bandwidth ratio, extremely high memory depth, and other excellent specifications. It is compact and portable in design, and all of the MSO5000-E series products support multiple channels, and the upgrade of the analysis software. As it integrates many functions of multiple instruments, different user groups can have more choices in selecting their desired product based on their needs, helping them save their budget to a large extent while enjoying the superior test support and user experience.
* Analog bandwidth: 150 MHz
* 2 analog channels, 1 EXT channel, and a standard configuration of 16 digital channels (required to purchase the probe)
* Up to 4 GSa/s real-time sample rate
* Up to 100 Mpts memory depth (option)
* High waveform capture rate (over 300,000 wfm/s)
* Auto measurement of 41 waveform parameters; full-memory hardware measurement function
* A variety of serial protocol triggers and decodes
* Up to 450,000 frames of hardware real-time and ceaseless waveforms recording and playback functions
* Independent search, navigation keys, and event table
* Built-in advanced power analysis software (option)
* Integrates 7 independent instruments into 1, including a digital oscilloscope, a logic analyzer, a spectrum analyzer, an arbitrary waveform generator, a digital voltmeter, a frequency counter and totalizer, and a protocol analyzer
* 9-inch capacitive multi-touch screen, 256-level intensity grading display, with color persistence
* Multiple interfaces available: USB HOST&DEVICE, LAN(LXI), HDMI, TRIG OUT, and USB-GPIB
* Web Control remote command
* Unique online version upgrade
* Novel and delicate industrial design, easy to operate -
DC Electronic Load
Höcherl & Hackl PLI 2112 / H&H PLI2112
Höcherl & Hackl PLI 2112 Electronic Load
The PLI series of electronic loads provide a comfortable operation by a graphical user interface. The PLI series highlight is the extensive variety of standard interfaces. Apart from Ethernet, USB, RS-232 and Analog interface there is a standard CAN interface. Programming is done in SCPI syntax.
The units provide constant current mode, constant voltage mode, constant power mode and constant resistance mode. In addition, protections for current and voltage can be set in any mode. A static data acquisition function allows to store measurement data on an external USB flash drive. Dynamic operation can be configured by up to 300 list point settings. The Electronic Load saves the synchronously acquired measurement data with timestamp. A configurable trigger model controls data acquisition, static and dynamic settings.
Special applications, such as fuel cell tests, need to load the DUT down to almost 0 V. For these purposes we supply a range of models with an integrated zero-volt supply.– Voltage: 120 V
– Current: 60 A
– Power: 2100 W
Datasheet -
Digital Multimeter
FLUKE 8846A
Digital Multimeter Fluke 8846A, 1000V1000V ca, 10A ca, CAT I, CAT II True RMS
The Fluke 8845A and 8846A 6.5 digit precision CAT II 600 V multimeters have the precision and versatility to handle your most demanding measurements, on the bench or in a system. These meters are both high performance and feature rich, yet also remarkably easy to use. These digital multimeters perform the functions you would expect to see in a multifunction DMM, including measuring volts, ohms, and amps. Basic V dc accuracy of up to 0.0024 %, 10 A current range, and a wide ohms range give you an unbeatable combination of measurement capability. You can also use the 8845A and 8846A to measure temperature, capacitance, period, and frequency—the functions of a counter, capacitance meter, and thermometer are built in for unparalleled versatility. Extend the meters’ utility even more with their graphical display modes, including TrendplotTM paperless recorder mode, statistics and histograms—features you won’t find on other multimeters. Of course, these meters are also durable and dependable, features you expect from any Fluke meter. This unique combination of features and performance makes the 8845A and 8846A an unbeatable value for a wide variety of applications, including manufacturing test, research and development, and service.
Datasheet -
Power Supply
TDK-Lambda GEN-60-40-1P230
Programmable Lab Power Supply 0-60 V DC 0-40 A
This 2400 W lab power supply sets new standards. They are currently the most powerful 1 HU lab power supplies on the market. Another advantage is that you can stack one device on top of another which means that it needs no air slit either above or below and can actually get by on 1 HU.
Output voltages of up to 60 V and output currents of up to 40 A can be adjusted directly on the device or remotely via the built-in RS232/RS485 interface. All important functions can also be programmed via analogue inputs (control voltage 0 5V, 0-10V, control current 4-20 mA or via external resistor; relevant drivers are available for the digital control e.g., via LabView and LabWindows). High-resolution 16-bit A/D and D/A converters enable very precise settings and programming; the dial controls on the device can be switched between coarse and fine adjustment.
A dual digital display shows the current values, and various status information (andOver Voltage Protection, Under Voltage Limit, overload mode, address settings again), and a monitor output provides corresponding analog voltages (0 – 5 V or 0 – 10 V) for an external monitoring The device can naturally be operated as a constant voltage as well as a constant current source and can, if necessary, automatically switch between these operating modes. Several devices can be switched serially or in parallel. This GEN/H model is half the structural shape of 19″ racks.
Datasheet -
Power Supply
KEYSIGHT N8940A
KEYSIGHT N8940A Alimentatore CC con autoranging, 80 V, 170 A, 5000 W, 400 V CA.
La serie Keysight N8900 offre alimentazione CC programmabile a uscita singola programmabile da 5 kW, 10 kW e 15 kW per applicazioni ATE che richiedono la giusta quantità di prestazioni al giusto prezzo. La caratteristica di uscita a regolazione automatica degli alimentatori serie N8900 consente una flessibilità senza precedenti offrendo una vasta gamma di combinazioni di tensione e corrente a piena potenza. Gli alimentatori con caratteristiche di uscita “rettangolari” o tradizionali forniscono piena potenza con una sola combinazione di tensione e corrente. Solo un N8900 fa il lavoro di più alimentatori. È come avere molti alimentatori in uno!
La serie N8900 offre potenza di uscita stabile, misurazioni di tensione e corrente incorporate e tensione e corrente di uscita con autorangolazione da 80 V a 1500 V e da 10 A a 510 A. Questi alimentatori offrono molte funzionalità pronte per il sistema come interfacce I / O standard multiple per semplificare e accelerare lo sviluppo del sistema di test e il design compatto 3U per risparmiare spazio nel rack. Se è necessaria più potenza, è possibile mettere in parallelo più unità N8900 per creare un “unico” alimentatore con> 100 kW di potenza totale in uscita. Il controllo master / slave incorporato consente la programmazione come se fosse solo un grande alimentatore; non è necessario programmare ciascuna fornitura singolarmente.Uscita autoranging – fa il lavoro di più alimentatori!
Potenza di uscita massima di 5 kW, 10 kW e 15 kW
Fino a 1500 V e fino a 510 A
14 diverse combinazioni di tensione, corrente e potenza disponibili in 208 V CA o 400 V CA (28 modelli in totale)
La giusta quantità di prestazioni al giusto prezzo
Unità facilmente parallele per creare un “unico” alimentatore con> 100 kW di potenza
Misura di tensione e corrente incorporata
Alta densità di potenza, 15 kW in soli 3U (5,25 “/ 13,34 cm)
Protezione da sovratensione, sovracorrente e sovratemperatura
Interfacce LAN (LXI Core), USB, GPIB e analogiche tutte standardValori nominali DC
Voltaggio: da 0 a 80 V.
Corrente: da 0 a 170 A
Potenza: 5000 W.Ingresso AC
Intervallo di tensione: 360-440 V CA.
Accuratezza della programmazione
Tensione: 0,1% del fondo scala
Corrente: 0,2% del fondo scala
Scheda Tecnica -
Power Supply
H10S CLT-100
Exclusive power supply is required for DC screwdrivers.
● Exclusive power supply converts the electric current from AC outlet (on the primary side) to low-voltage output (HI: DC30V) or (LOW: about DC20V) to supply it to the screwdriver.
● Safe and quiet rotation.
● Please always use HIOS screwdriver in combination with HIOS power supply for safe screw tightening.
● Stable power supply with multiple inputs (AC100V to 240V).
(Not applicable to CLT-100 and MC-70L) -
Fucntion/Arbitrary Waveform Generatr
RIGOL DG2102
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
Datasheet -
Function/Arbitrary Waveform Generator
RIGOL DG2072
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
Datasheet
-
Attenuator
M/A-COM EUROTEC 2082-6042-10
RF Attenuator – Coaxial from XMA
Connectors SMA Male (Plug)/ SMA Female (Jack)
18 GHz, 500 W
The overall length of the XMA SMA Coaxial Attenuators are .86 inch for 3, 6 and 10 dB and 1.02 Inches for 20 and 30 dB.
The body is passivated stainless steel round body design with an operating temp range of -65c to +125c.
The maximum VSWR is < 1.15:1 @ DC-4GHz, <1.25:1 @ 4-12.3 GHz and <1.35 @ 12.4-18. Datasheet -
Attenuator
HUBER SUHNER 6803.01.A + HUBER SUHNER 6806.01.A
HUBER+SUHNER 6803.01.A
RF Attenuator 50 Ω, 4 GHz, 3 dB
Connectors (side 1 / side 2) BNC plug (male) / BNC jack (femaleHUBER+SUHNER 6806.01.A
RF Attenuator 50 Ω, 4 GHz, 6 dB
Connectors (side 1 / side 2) BNC plug (male) / BNC jack (female)
Datasheet 6806.01.A
Datasheet 6803.01.A -
Power Sensor
HP-Agilent/Keysight R8486A
HP AGILENT KEYSIGHT R8486A Thermocouple Waveguide Power Sensor 26.5 GHz to 40 GHz
The R8486A power sensor is designed for use with the EPM series, EPM-P series, 70100A, E1416A, 435A/B, 436A, 437A, 438A series power meters. The R8486A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• 50 MHz calibration port
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST) millimeter-wave sensor calibration
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 26.5 GHz to 40 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -10 dBm to +20 dBm)
• UG-599/U waveguide flange
Datasheet -
Power Sensor
AGILENT – Hp/Keysight 8487A
HP AGILENT KEYSIGHT 8487A POWER SENSOR 50 MHz to 50 GHz
The 8487A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters. The 8487A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 50 MHz to 50 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• 2.4 mm(m) connector
Scheda Tecnica -
Power Sensor
HP-Agilent/Keysight 8485A
HP AGILENT KEYSIGHT 8485A POWER SENSOR 50 MHz to 26.5 GHz
The 8485A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters. The 8485A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 50 MHz to 26.5 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• 3.5 mm(m) connector
Datasheet -
Power Sensor
HP-Agilent/Keysight 8481A
HP AGILENT KEYSIGHT 8481A POWER SENSOR 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
The 8481A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 10 MHz to 18 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• N (m) connector -
ADAPTOR
HUBER + SUHNER 33PC35-50-01-1/199 NE ADAPTOR PLUG/JACK 22644362
The HUBER + SUHNER 33PC35-50-01-1/199 NE is a Adaptor plug/jack PC 3.5 plug (male) / PC 3.5 jack (female).
It used for test and measurement applications precision adaptor* Interface 1: PC 3.5 plug (male)
* Interface 2: PC 3.5 jack (female)
* Impedance: 50 Ω
* Interface freq. Max: 33 GHz
* Frequency Range 1: 0 GHz to 18 GHz
* Frequency Range 2: 18 GHz to 26.5 GHz
* Return loss band 1: 28 dB
* Return loss band 2: 23 dB
* BATCH Nr 02.26942
* Manufacture code: 22644362
Datasheet€50.00 View Product -
Rohde & Schwarz ESHS10
R&S ESHS10 EMI Test Receivers, 10: 9 kHz to 30 MHz
The receivers ESHS 10 is suitables for measuring electromagnetic interference in line with commercial standards:
• CISPR16, VDE0876 and ANSI C63.2
• EN55011 to 55022, ETS, FCC, VCCI and VDE 0871 to 0879 and ANSI C63.4The instruments are ideal for routine tasks in industry such as development and approval tests in line with commercial standards. Featuring mains-independent battery powering, they are also suitable for mobile applications at EMC service providers, test houses and safety standard authorities.
Superior circuit design
• High measurement accuracy, typical error 0.5 dB
• Wide dynamic range, typical noise figure 7 dB with preamplifier, third-order intercept point 20 dBm (without preamplifier)
• Calibrated attenuator with high pulse loading capacity, switchable in 10-dB steps from 0 to 120 dB
• Comprehensive preselection filters
• Switchable preamplifier with wide dynamic range
• Crystal-stabilized, fast synthesizer with high resolution and sweep mode for fast frequency scanning
• High-level mixer with high oscillator rejection
• Delay-equalized IF filtersDemodulation
• Parallel detectors for average, peak and quasi-peak indication
• 60 dB operating range also for quasipeak and average value indication
• Highly linear envelope detector with more than 70 dB dynamic range
• AM and A0 demodulators (ESVS also FM)
• Logarithmic amplifier with more than 70 dB dynamic range
• Peak indication with automatic consideration of IF bandwidth correction values for broadband interference measurements
• Automatic overload detection in mixer stages and in test channel by permanently activated peak detectorsPowerful processor system
• Manual operation or internal or external processor control
• Flash EPROMs for convenient and fast firmware update through PC
• Macros for automatic and semiautomatic test runs
• Automatic level calibration
• Automatic consideration of frequencydependent transducer factors
• All built-in functions fully programmable via IEC/IEE bus
• Fast measurement in external trigger mode; output of up to 5000 values/s via IEC/IEEE bus, up to 400 values/s including frequency change within certain frequency bands
• 12-bit A/D converter with short conversion time, measurement time selectable between 1 ms and 100 s
• High measurement accuracy thanks to automatic total calibration
• Automatic monitoring of all synthesizer loops and supply voltages during operationOptimum result display and printout
• Measurement of voltage, field strength, current and pulse spectral density with display of relevant units
• Indication of result on analog meter or digital display with 0.1 dB resolution
• Output of results as lists and diagrams on printer including limit linesFurther features
• Digital level indication on LCD and analog level indication on moving-coil meter taking into account transducer factors and their units
• Numerous interfaces for driving or feeding additional devices
• AC supply as well as battery powering for mobile applications
Datasheet -
-
Power Supply
HP-Agilent/Keysight 6645A
HP high performance DC power supplies offer speed and accuracy for test optimization. The single output, 200 W, GPIB 6641A-6645A provide fast, low-noise outputs; analog control of output voltage and current; fan-speed control to minimize acoustic noise; as well as parallel and series connections of multiple units.
The HP 180W, GPIB, single output 6645A is a versatile programmable supply designed to maximize test throughput during design verification or on the production line, and is fully programmable to help reduce test time through a variety of automated capabilities.
Output Ratings
Output voltage: 0 to 120 V
Output current (40° C): 0 to 1.5 A
Maximum current (50° C/55° C): 1.4 A/1.3 AProgramming Accuracy at 25°C ±5°C
Voltage 0.06% + 51 mV
Current 0.15% + 1.7 mARipple & Noise (20 Hz – 20 MHz)
Voltage rms: 700 µV
Voltage peak-to-peak: 7 mV
Current rms: 1 mA
Datasheet -
CHROMA 2327 VIDEO PATTERN GENERATOR, WITH REMOTE KEYPAD A225003
Chroma 2227/2327 Video Pattern Generators not only combine the signals of analog (250MHz) and digital (165MHz) to provide the VESA standard video signal source for LCD Monitor/CRT Monitor, it also integrates the TV (NTSC / PAL/SECAM) signal to fit in the multimedia display applications for the newly risen LCD TV, PDP TV, LCOS TV and DLP RPTV industries. Users can utilize the software application, VPG PLUS, either on PC or on the Video Pattern Generator itself to edit various timing parameters, patterns and test procedures. Its complete test functions can fully meet the requirements for R&D, production test and quality assurance in all video related industries.
Analog/TMDS/SDTV/HDTV Signals Support The 2227/2327 Video Pattern Generators equipped with microprocessor and precision Phase Locked Loop (PLL) circuit have accuracy up to 25PPM/1PPM after calibration are featured in high accuracy, high stability and high speed. Moreover, all of its horizontal timing parameters are in one-pixel resolution, which can provide the video signal with 256-color per pixel. For analog signal output, its pixel frequency can up to 250MHz and the RGB signals meet the RS-343A standard. It also supports Y/R-Y/B-Y, Y/Pb/Pr, Y/Cb/Cr and sync signals for tri-level output to fulfill the test requirements for HDTV.
The digital signal is in TMDS output with pixel frequency from 25~165MHz and test screen resolution up to UXGA. Its DVI-I Connector containing digital, analog and DDC2B signals meet the DDWG DVI standard. In addition Electrostatic Discharge (ESD) and Surge are designed for protection.
As to the TV output spec, the image and chromaticity of 2227/2327 meet the regulations of NTSC/PAL/SECAM, which the output signals include VBS composite signal with BNC and Y/C (Luminance/Chrominance) image/chromaticity separation signal with S-Video output connector.
Chroma 2227/2327 Video Pattern Generators have built in rich timing files and various patterns selections to increase the product usage as well as to decrease the engineer workload for setting operation. The embedded NVRAM memory device and optional memory card allow users to save the data files of accomplished settings for recall. The parameters for output patterns and timings can be programmed by PC via RS232C and loaded to memory card via the 22xx Series VPGs, meanwhile the operation sequences can be programmed and controlled by VPGplus on PC via RS232C interface. VPGplus provides a convenient operating environment for VPG users. Users can set the VPG parameters for the data of timing, pattern, program and icon, etc.
Following the rising market of multi-media display the competition and demand for product quality are getting more and more sever as consumers often request and search for higher pixels with less bad cells as well as low cost video display products before purchasing. Under this circumstance, the Chroma 2227/2327 Video Pattern Generators with high resolution test quality can meet the multi-media display applications at present, and the features described above make the Video Pattern Generator a indispensable testing tool for the RD engineers and production manufacturers.
Key Features:
* Analog pixel rate 250MHz* TMDS pixel rate 165MHz
* TV NTSC/PAL/SECAM signal support
* S-Video / VBS composite output
* 2 level SDTV & 3 level HDTV Format
* HDCP V.1.0 support
* Closed Caption function support
* V-Chip function support
* Y/Pb/Pr,Y/Cb/Cr,Y/R-Y/B-Y output
* One-pixel resolution
* Display size up to 4096×2048 max
* Picture for BMP format support
* DDC2B Read / Write
* PC remote control
* Storing data with memory cards
* Supporting Gamma calibration
* ESD circuit protection built-in
Datasheet -
Oscilloscope 2 channels
RIGOL MSO5152-E
MSO5000-E series digital oscilloscope is a high-performance oscilloscope model designed based on RIGOL UltraVision II technology. With a 9-inch capacitive multitouch screen, the MSO5000-E series integrates 7 independent instruments into one, delivering super sample bandwidth ratio, extremely high memory depth, and other excellent specifications. It is compact and portable in design, and all of the MSO5000-E series products support multiple channels, and the upgrade of the analysis software. As it integrates many functions of multiple instruments, different user groups can have more choices in selecting their desired product based on their needs, helping them save their budget to a large extent while enjoying the superior test support and user experience.
* Analog bandwidth: 150 MHz
* 2 analog channels, 1 EXT channel, and a standard configuration of 16 digital channels (required to purchase the probe)
* Up to 4 GSa/s real-time sample rate
* Up to 100 Mpts memory depth (option)
* High waveform capture rate (over 300,000 wfm/s)
* Auto measurement of 41 waveform parameters; full-memory hardware measurement function
* A variety of serial protocol triggers and decodes
* Up to 450,000 frames of hardware real-time and ceaseless waveforms recording and playback functions
* Independent search, navigation keys, and event table
* Built-in advanced power analysis software (option)
* Integrates 7 independent instruments into 1, including a digital oscilloscope, a logic analyzer, a spectrum analyzer, an arbitrary waveform generator, a digital voltmeter, a frequency counter and totalizer, and a protocol analyzer
* 9-inch capacitive multi-touch screen, 256-level intensity grading display, with color persistence
* Multiple interfaces available: USB HOST&DEVICE, LAN(LXI), HDMI, TRIG OUT, and USB-GPIB
* Web Control remote command
* Unique online version upgrade
* Novel and delicate industrial design, easy to operate€899.00 View Product -
DC Electronic Load
Höcherl & Hackl PLI 2112 / H&H PLI2112
Höcherl & Hackl PLI 2112 Electronic Load
The PLI series of electronic loads provide a comfortable operation by a graphical user interface. The PLI series highlight is the extensive variety of standard interfaces. Apart from Ethernet, USB, RS-232 and Analog interface there is a standard CAN interface. Programming is done in SCPI syntax.
The units provide constant current mode, constant voltage mode, constant power mode and constant resistance mode. In addition, protections for current and voltage can be set in any mode. A static data acquisition function allows to store measurement data on an external USB flash drive. Dynamic operation can be configured by up to 300 list point settings. The Electronic Load saves the synchronously acquired measurement data with timestamp. A configurable trigger model controls data acquisition, static and dynamic settings.
Special applications, such as fuel cell tests, need to load the DUT down to almost 0 V. For these purposes we supply a range of models with an integrated zero-volt supply.– Voltage: 120 V
– Current: 60 A
– Power: 2100 W
Datasheet -
Digital Multimeter
FLUKE 8846A
Digital Multimeter Fluke 8846A, 1000V1000V ca, 10A ca, CAT I, CAT II True RMS
The Fluke 8845A and 8846A 6.5 digit precision CAT II 600 V multimeters have the precision and versatility to handle your most demanding measurements, on the bench or in a system. These meters are both high performance and feature rich, yet also remarkably easy to use. These digital multimeters perform the functions you would expect to see in a multifunction DMM, including measuring volts, ohms, and amps. Basic V dc accuracy of up to 0.0024 %, 10 A current range, and a wide ohms range give you an unbeatable combination of measurement capability. You can also use the 8845A and 8846A to measure temperature, capacitance, period, and frequency—the functions of a counter, capacitance meter, and thermometer are built in for unparalleled versatility. Extend the meters’ utility even more with their graphical display modes, including TrendplotTM paperless recorder mode, statistics and histograms—features you won’t find on other multimeters. Of course, these meters are also durable and dependable, features you expect from any Fluke meter. This unique combination of features and performance makes the 8845A and 8846A an unbeatable value for a wide variety of applications, including manufacturing test, research and development, and service.
Datasheet -
Power Supply
TDK-Lambda GEN-60-40-1P230
Programmable Lab Power Supply 0-60 V DC 0-40 A
This 2400 W lab power supply sets new standards. They are currently the most powerful 1 HU lab power supplies on the market. Another advantage is that you can stack one device on top of another which means that it needs no air slit either above or below and can actually get by on 1 HU.
Output voltages of up to 60 V and output currents of up to 40 A can be adjusted directly on the device or remotely via the built-in RS232/RS485 interface. All important functions can also be programmed via analogue inputs (control voltage 0 5V, 0-10V, control current 4-20 mA or via external resistor; relevant drivers are available for the digital control e.g., via LabView and LabWindows). High-resolution 16-bit A/D and D/A converters enable very precise settings and programming; the dial controls on the device can be switched between coarse and fine adjustment.
A dual digital display shows the current values, and various status information (andOver Voltage Protection, Under Voltage Limit, overload mode, address settings again), and a monitor output provides corresponding analog voltages (0 – 5 V or 0 – 10 V) for an external monitoring The device can naturally be operated as a constant voltage as well as a constant current source and can, if necessary, automatically switch between these operating modes. Several devices can be switched serially or in parallel. This GEN/H model is half the structural shape of 19″ racks.
Datasheet -
Power Supply
KEYSIGHT N8940A
KEYSIGHT N8940A Alimentatore CC con autoranging, 80 V, 170 A, 5000 W, 400 V CA.
La serie Keysight N8900 offre alimentazione CC programmabile a uscita singola programmabile da 5 kW, 10 kW e 15 kW per applicazioni ATE che richiedono la giusta quantità di prestazioni al giusto prezzo. La caratteristica di uscita a regolazione automatica degli alimentatori serie N8900 consente una flessibilità senza precedenti offrendo una vasta gamma di combinazioni di tensione e corrente a piena potenza. Gli alimentatori con caratteristiche di uscita “rettangolari” o tradizionali forniscono piena potenza con una sola combinazione di tensione e corrente. Solo un N8900 fa il lavoro di più alimentatori. È come avere molti alimentatori in uno!
La serie N8900 offre potenza di uscita stabile, misurazioni di tensione e corrente incorporate e tensione e corrente di uscita con autorangolazione da 80 V a 1500 V e da 10 A a 510 A. Questi alimentatori offrono molte funzionalità pronte per il sistema come interfacce I / O standard multiple per semplificare e accelerare lo sviluppo del sistema di test e il design compatto 3U per risparmiare spazio nel rack. Se è necessaria più potenza, è possibile mettere in parallelo più unità N8900 per creare un “unico” alimentatore con> 100 kW di potenza totale in uscita. Il controllo master / slave incorporato consente la programmazione come se fosse solo un grande alimentatore; non è necessario programmare ciascuna fornitura singolarmente.Uscita autoranging – fa il lavoro di più alimentatori!
Potenza di uscita massima di 5 kW, 10 kW e 15 kW
Fino a 1500 V e fino a 510 A
14 diverse combinazioni di tensione, corrente e potenza disponibili in 208 V CA o 400 V CA (28 modelli in totale)
La giusta quantità di prestazioni al giusto prezzo
Unità facilmente parallele per creare un “unico” alimentatore con> 100 kW di potenza
Misura di tensione e corrente incorporata
Alta densità di potenza, 15 kW in soli 3U (5,25 “/ 13,34 cm)
Protezione da sovratensione, sovracorrente e sovratemperatura
Interfacce LAN (LXI Core), USB, GPIB e analogiche tutte standardValori nominali DC
Voltaggio: da 0 a 80 V.
Corrente: da 0 a 170 A
Potenza: 5000 W.Ingresso AC
Intervallo di tensione: 360-440 V CA.
Accuratezza della programmazione
Tensione: 0,1% del fondo scala
Corrente: 0,2% del fondo scala
Scheda Tecnica -
Power Supply
H10S CLT-100
Exclusive power supply is required for DC screwdrivers.
● Exclusive power supply converts the electric current from AC outlet (on the primary side) to low-voltage output (HI: DC30V) or (LOW: about DC20V) to supply it to the screwdriver.
● Safe and quiet rotation.
● Please always use HIOS screwdriver in combination with HIOS power supply for safe screw tightening.
● Stable power supply with multiple inputs (AC100V to 240V).
(Not applicable to CLT-100 and MC-70L)€120.00 View Product -
Fucntion/Arbitrary Waveform Generatr
RIGOL DG2102
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
Datasheet€890.00 View Product -
Function/Arbitrary Waveform Generator
RIGOL DG2072
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
Datasheet€720.00 View Product
