Showing 91–120 of 1386 results
-
Tester DI Radiazone Di Campo Elettromagnetico
LUTRON EMF-823
Measuring Tesla Range x Accuracy: 20 micro Tesla x 0.01 micro Tesla, 200 micro Tesla x 0.1 micro Tesla, 2000 micro Tesla x 1 micro Tesla; Accuracy: ± (4 % + 3 d) – 20 micro Tesla, ± (5 % + 3 d) – 200 micro Tesla, ± (10 % + 5 d) – 2000 micro Tesla
Milli-Gauss Range x Resolution: 200 milli Gauss x 0.1 milli Gauss, 2000 milli Gauss x 1 milli Gauss, 20000 milli Gauss x 10 milli Gauss; Accuracy: 200 milli Gauss range, 2000 milli Gauss range, 20000 milli Gauss range.
Sampling Time: Approx. 0.4 second; Band width: 30 Hz to 300 Hz; Number of Axes: Single axis.
Operating Temperature: 0°C to 50 °C; Operating Humidity: Less than 80% RH
Accessories: Operation Manual, EMF MeteSKU: n/a -
Power Detectore
GIGA-TRONICS 16936
The 16936 is a 18.5 GHz rf sensor from Gigatronics. Electronic test equipment sensors measure the power of waveforms, such as multi-tone and modulated radiofrequency (RF) waveforms. Sensors gather highly accurate modulation measurements using diode detectors.
The Gigatronics 16936 Peak Power Sensor was built for use with the Gigatronics 8501, 8501A, 8502, and 8502A power-meters. The 16936 provides both pulsed and cw measurements.Features of the Gigatronics 16936 sensor include:
Frequency range: 750 MHz to 18.5 GHz
Peak Measurement range: -20 dBm to +20 dBm
CW Measurement range: -40 dBm to +20 dBm
50 ohm input impedance
N (m) connector
DatasheetSKU: n/a -
Clamp Meter
EXTECH EX840
AC/DC Clamp-On Meter/Digital MultiMeter with built-in Infrared Thermometer
This CAT IV True RMS clamp meter features a built-in IR thermometer with laser pointer for non-contact surface measurements from -58 to 518 °F (-50 to 270 °C). Clamp measures AC current up to 1000 Amp with a maximum resolution of 0.1 Amp. The 1.7-inch jaw fits around conductors up to 750MCM. Peak hold captures motor inrush currents and other surges. Data hold and auto power off functions. Other functions include AC/DC Voltage, resistance, Type K thermometer, capacitance and frequency. Complete with test leads, Type K temperature probe, 9 Volt battery and case.
SKU: n/a -
Digital Radiocommunication Tester
ROHDE & SCHWARZ CMD60
The Digital Radiocommunication Tester is an advanced top-class instrument for measurements on base stations (BTS) and BTS modules.
The LCD display with softkeys on both sides allows menu-guided convenient callup of test routines.
These testers combine compact size with high measurement accuracy and speed. They are suitable both for stationary and mobile use and feature great ease of operation and high reliability. Operation is extremely easy and requires no detailed GSM knowledge.
CMD allows measurements on transmitters and receivers of base stations without affecting telephone calls in progress.
The Rohde & Schwarz CMD60 addresses all aspects of test and measurement applications from production and service to development and quality assurance. It comes equipped with remote control via IEEE488/IEC625 bus + RS232, automated regression and stress testing of DUT, and automatic go/no go testing of fixed and portable part.Additional Features:
High production output at low investment for test equipment
The R&S® CMD60 can be remote controlled via IEC/IEEE-bus interface using SCPI-compatible commands.
Comprehensive test capabilities implemented in one single unit.
Comprehensive in-depth measurements based on ETSI Rec. CTR06
Automatic regression and stress tests
The tester supplies a great number of DECT-specific signals such as bit clock, TX/RX enable, to control the module under test
Comprehensive audio tests
Ergonomic user interface and relaxed manual operation due to a large bright LCD (requires noDECT-specific knowledge) strictly separated from the expert user interface for configuration
Integrated tools such as a scope display for power and FM demodulation versus time ease troubleshootingSKU: n/a -
Power Meter
ANRITSU MA2437A
The ML2437A Power Meter combines the advantages of thermal meter accuracy, diode meter speed, and peak power meter display graphics. The result is a single instrument that samples at more than 35K per second and achieves 90 dB dynamic range with a single sensor. This meter includes graphics display capability as a standard feature. The ruggedized housing and optional high-capacity NiMH battery bring laboratory quality accuracy to field service applications. ML2437A has one input.
DatasheetSKU: n/a -
Oscilloscope 2 channels
RIGOL DS1102Z-E
The DS1000Z-E Series identifies cost-effective, high-performance digital oscilloscopes. It is designed to meet different needs and finds applications for development, testing and education activities.
It covers all fields attributable to the traditional digital oscilloscope market.
Technical specifications:
ModelDS1102Z-E
Bandwidth100 MHz
Analog Channels2
Sample Rate1GSa / s (Single-channel), 500MSa / s (Dual-channel),
Max Memory Depth24Mpts (standard, single channel), 12 Mpts (dual-channel)
Max. Waveform Capture rate30,000 wfms / s
Real Time waveform Record and ReplayUp to 60,000 Frames
Std. ProbesTwo PVP2350 350 MHz passive HighZ probes
DatasheetSKU: n/a€255.00 View Product -
Power Sensor
HP-Agilent/Keysight 8487D
Il sensore di potenza a diodo 8487D misura la potenza media nell'intervallo di frequenza da 50 MHz a 50 GHz e l'intervallo di potenza da -70 a -20 dBm (intervallo dinamico 50 dB).
L'attenuatore Keysight 11708A 30 dB viene fornito con sensori di potenza serie 8480 con il suffisso “D”, per la calibrazione con misuratore di potenza 0 dBm, riferimento 50 MHz.
SWR eccellente per ridurre l'incertezza di mancata corrispondenza
Calibrazione e tracciabilità accurate alla calibrazione del sensore a onde millimetriche del National Institute of Standards and Technology (NIST)
Compatibile con misuratori di potenza EPM (nuovo N1913A / 14A, E4418B / 19B), EPM-P (E4416A / 17A) e serie P (N1911A / 12A), oltre al misuratore di potenza E1416A VXI e fuori produzione 70100A e 43X
Misurazioni di potenza media accurate oltre -70 a -20 dBm
Gamma di frequenza da 50 MHz a 50 GHz
Elemento di rilevamento della potenza del diodo
DatasheetSKU: n/a -
Oscilloscope 2 channels
TEKTRONIX TBS1102C
The TBS1000C Series Digital Storage Oscilloscope offers affordable performance in a compact design. It is designed to meet the needs of today's educational institutions, embedded design engineers, and maker community. The instrument includes a 7-inch WVGA color display with up to 1 GS/s sample rate, bandwidths from 50 MHz to 200 MHz and a five-year warranty. The instrument comes with an innovative courseware system that integrates the lab exercises with step-by-step instructions for use, by the students.
Features:
7-inch WVGA color display with 15 horizontal divisions that shows 50% more signal
32 automated measurements
Dual window FFT with simultaneous time and frequency domain views
Trigger frequency counter
Pan and Zoom capability
Multi-language user interface with support for 10 languages in the user
interface and front panel overlay
Small footprint and light weight
Fanless design contributes to low noise operationSKU: n/a -
Fucntion/Arbitrary Waveform Generatr
HP-Agilent/Keysight 33120A
The 33120A function generator has a proven legacy, 15 MHz bandwidth, arbitrary waveforms & modulation capability. DDS technology provides precise adjustment and frequency stability.
15 MHz sine & square waveforms
Ramp, triangle, noise & DC waveforms
12-bit, 40 MSa/s, 16,000 points arbitrary waveforms
AM (int/ext), FM (int), FSK (internal/external), burst (int/extl)
Linear & logarithmic sweeps and burst operation
IntuiLink software plus GPIB & RS-232 interfaces included
Option 001 provides improved stability & a multiple-unit link
DatasheetSKU: n/a -
Power Sensor
AGILENT-Hp/Keysight 8481A
HP AGILENT KEYSIGHT POWER SENSOR 8481A 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM Series, EPM-P Series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
8481A offers extraordinary precision, stability and lower SWR.
• Excellent SWR to reduce mismatch uncertainty
• Accurately calibrated and traceable to the US National Institute of Standards and Technology (NIST).
• Compatible with EPM, EPM-P, and P Series power meters, as well as E1416A VXI and discontinued 70100A and 43X power switches
• Accurate average power measurements over -30 to +20 dBm
• Frequency range from 10 MHz to 18 GHz
• Element sensitive to the power of the thermocouple
• Measurement range: 1 µW to 100 mW (-30 dBm to +20 dBm)
• impedance 50 ohm
• Connector N (m)SKU: n/a -
Current Probe Amplifiter, Mainframe
TEKTRONIX TM502A+AM503+A6303
Tektronix AM503 Current Probe Amplifier
The AM503 Current Probe Amplifier allows display of current on any oscilloscope having 10 mV/div sensitivity, 50 ohm or 1 megohm input, and at least 100 MHz bandwidth. It is compatible with A6302, A6303, P6302, P6303 current probes. It requires a TM500 or TM5000 series mainframe for operation.
Features:Allows for current display on any oscilloscope
Maximum input current: 20A for 6302; 100A for 6303
Bandwidth: >50 MHz 6302; >15 MHz 6303
Rise time: <7 ns 6302; <23 ns 6303
Deflection factor: 1 mA/div to 5 A/div for 6302; 20 mA/div to 50 A/div for 6303
Weight: 4 lb; Size: single width moduleSKU: n/a -
Microwave Network Analyzer
HP-Agilent/Keysight 85107B , 8510C , 85102B , 85101C , 8517B
HP 85107B 230 MICROWAVE NETWORK ANALYZER, 45 MHz to 50 GHz.
Complete with:
HP 8510C NETWORK ANALYZER
HP 85102B IF / DETECTOR
HP 8517B S-PARAMETER TEST SET 45 MHz-50GHz OPT 007
HP 85133-60016 2.4mm (f) FLEXIBLE TEST PORT CABLE Qty.2
HP 83651B SYNTHESIZED SWEEPER 10MHz – 50GHz 8360B Qty.1
ACCESSORIES:
Qty.1 INTELLIGENT INTERFACES MICROPRINT45CH VARIABLE RESOLUTION HP-GL / COLOR / SPEED MODES HP-IP TO PARALLEL INTERFACE CONVERTER;
Qty.1x WG K420 GPIB CABLE;
Qty.2x HP 10833A GPIB CABLE;
Qty.1x HP 08510-60101 IF INTERCONNECT DISPLAY;
Qty.1x HP 08510-60102 TEST SET – IF INTERCONNECT;
Qty.2x HP 10503A BNC CABLE;
Qty.1x HP 8710-1764 8lb-in;
Qty.1x HP 8710-1770 9/16 – 1/2;
Qty.1x HUBER & SUHNER SUCOFLEX 104P FLEXIBLE MICROWAVE CABLE ASSEMBLY;
Qty.5x ADAPTER.
DatasheetSKU: n/a -
SMAPLING MODULE
TEKTRONIX 80E04
I moduli 80E10, 80E08 e 80E04 sono moduli di campionamento Time Domain Reflectometry (TDR) a doppio canale, che forniscono fino a 12 ps di incidente e 15 ps di tempo di salita riflesso nell'80E10 (18 ps di incidente in 80E08 e 23 ps di incidente in 80E04). Ciascun canale di questi moduli è in grado di generare un passo veloce per l'uso in modalità TDR e la parte di acquisizione del modulo di campionamento monitora il passo incidente e l'eventuale energia riflessa.
La polarità del passo di ogni canale può essere selezionata indipendentemente. Ciò consente il test TDR o S-parameter di modo comune o differenziale di due linee accoppiate, oltre al test indipendente di linee isolate. La generazione di passi indipendenti per ciascun canale consente misurazioni differenziali reali, che garantiscono l'accuratezza della misurazione per i dispositivi differenziali.
L'80E10 e l'80E08 sono sistemi di campionamento remoto indipendenti da 2 metri di fattore di forma ridotto e completamente integrati, che consentono la posizione del campionatore vicino al DUT e garantiscono la migliore fedeltà del segnale. Un extender opzionale da 2 metri è disponibile per l'80E04.
I moduli caratterizzano la diafonia utilizzando i passaggi TDR per pilotare una linea (o coppia di linee per la diafonia differenziale) mentre
monitorare una seconda linea (o coppia di linee) con l'altro canale (o un altro modulo per la diafonia differenziale). La funzione “filtro” sui mainframe della serie 8200 e 8000 può essere utilizzata con misurazioni TDR o diafonia per caratterizzare le prestazioni del sistema previste con frequenze di taglio inferiori.Tutti i moduli hanno un passo incidente indipendente e un raddrizzamento del ricevitore per rimuovere l'effetto dei dispositivi di misurazione e delle sonde, consentendo un disinserimento più rapido e semplice dei dispositivi di prova. I moduli di campionamento 80E10 forniscono un tempo di salita dell'acquisizione di 7 ps, con una larghezza di banda equivalente selezionabile dall'utente fino a 50 GHz (con impostazioni di 50, 40 e 30 GHz). La larghezza di banda di campionamento 80E08 è 30 GHz (selezionabile dall'utente con impostazioni 30 e 20 GHz) e la larghezza di banda di campionamento 80E04 è 20 GHz. Le sonde TDR differenziali a passo variabile P8018 da 20 GHz single-ended e P80318 da 18 GHz offrono prestazioni e conformità eccellenti, garantendo misurazioni del backplane e del pacchetto facili e accurate.
Quando l'utente utilizza questi moduli con il software Tektronix IConnect® TDR e VNA, può acquisire fino a 1.000.000 di punti dati e ottenere fino a 50 GHz differenziali, in modalità mista e parametri S single-ended.
Scheda TecnicaSKU: n/a -
Power Meter, Power Sensor
ANRITSU ML2437A + ANRITSU MA2473A
The ML2437A Power Meter combines the advantages of thermal meter accuracy, diode meter speed, and peak power meter display graphics. The result is a single instrument that samples at more than 35K per second and achieves 90 dB dynamic range with a single sensor. This meter includes graphics display capability as a standard feature. The ruggedized housing and optional high-capacity NiMH battery bring laboratory quality accuracy to field service applications. ML2437A has one input.
The MA2473A is a used 32 GHz 0.1 Watt RF Sensor from Anritsu. Electronic test equipment sensors measure the power of waveforms, such as multi-tone and modulated radiofrequency (RF) waveforms. Sensors gather highly accurate modulation measurements using diode detectors.
Additional Features:Frequency Range 10 MHz – 32 GHz
Dynamic Range -70 to +20
SWR <1.90; 10 - 50 MHz,<1.17; 50 - 150 MHz,<1.12; 0.15 - 2 GHz,<1.22; 2 - 12.4 GHz,<1.25; 12.4 - 18 GHz, <1.35; 18 - 32 GHz,<1.50; 32 - 40 GHz,<1.63; 40 - 50 GHz RF Connector Type K (m) Sensor linearity 1.8%, <18 GHz 2.5%, <40 GHz 3.5%, <50 GHz Rise time-1(ms) <0.004 DatasheetSKU: n/a -
Signal Generator
HP-Agilent/Keysight 83650A
The Agilent 83650A synthesized sweeper is the standard of excellence for applications requiring the high performance and accuracy of a synthesized source and the speed and versatility of a sweep oscillator. Synthesized broadband frequency coverage and precise 1 Hz frequency resolution (Opt 008) are generated by indirect synthesis, enabling the Agilent 83650A to achieve low single-sideband phase noise performance. It delivers excellent harmonic performance with harmonics at least 50 dB below the carrier from 2.0 to 26.5 GHz, and at least 40 dB below the carrier above 26.5 GHz.
Features:
Scan modulation to simulate antenna scan patterns
Accurate fixed and swept frequency offset for two-tone measurement
User flatness correction for leveling at remote points in the test system
General purpose source for use in component test, receiver test and for frequency conversion
Sweep Modes: Step, List, Ramp
Maximum Power: +10 dBm 26.5 GHz
Maximum Power: +2.5 dBm >40 GHz
Power Sweep Range: -20 dBm to maximum power
Phase Noise (50 GHz at 10 KHz): -68 dBc
Max FM Deviation (locked): +/- 8 MHz
DatasheetSKU: n/a -
Mainframe
HP-Agilent/Keysight 66000A
The Hp 66000A modular power system simplifies test-system assembly, cabling, programming, debugging and operation. The 66000A is 4 U, 8 slot mainframe that accepts 1 to 8 modules below in any combination. Modules are ordered separately.
Features:High density: eight slots in 7 inches of rack space
Output sequencing
Low ripple and noise
High-accuracy read-back of voltage and current over GPIB
Standard Commands for Programmable Instruments (SCPI)
Optional keyboard and display unit
Serial link to connect two mainframes at one GPIB address
Optional isolation and polarity-reversal relays
Built-in self-test
DatasheetSKU: n/a
-
