DC power supply with 3 independent output channels (+32 V / 3 A, +32 V / 3 A, +6 V / 5 A, DC, max 222 W). 4.3-inch LCD color touch screen. High resolution for measurement of 1 μA low range current. Low output ripple and noise <350 μVrms/2 mVpp. USB HOST, LAN, Digital I/O, and RS232 (standard)

3 electrically isolated independent channels with a maximum total power of up to 222 W
32 V/3 A || 32 V/3 A || 6 V/5 A (standard)
32 V/2 A || 32 V/2 A || 6 V/10 A (optional)
4.3-inch LCD color touch screen
Internal series/parallel connections for CH1 and CH2
High resolution for measurement of 1 μA low range current
Capability to measure and display wide dynamic ranges of current
Excellent programming/readback accuracy
Transient response time <50 μs
Front and rear output terminals
2-wire or 4-wire remote sense
A maximum of 512 arbitrary points with dwell time down to 1 ms; various built-in basic waveforms
Low output ripple and noise <350 μVrms/2 mVpp
Command processing time <10 ms
Automatic switchover between low and high range measurement
Timing output, energy consumption analysis (IoT), data logging and analysis
Capability to measure the minimum of 1 ms pulse current
Three rack-units (3U), 1/2-rack form factor
Software control
Over voltage, over current, and over temperature protection
Various interfaces available: USB HOST, LAN, Digital I/O, and RS232 (standard)

DC power supply with 2 outputs, 20V/5A || 5V/16A, with remote Sense, total power up to 180W

DP822A/DP822: 2 outputs, 20V/5A || 5V/16A, with remote Sense, total power up to 180W
Low ripple and noise:
DP832A/DP832/DP831A/DP831/DP822A/DP822/DP821A/DP821: <350uVrms/2mVpp
Excellent linear regulation rate and load regulation rate
Fast transient response time: <50μs
Some channels are isolated
Standard OVP/OCP/OTP protection functions
Standard timing output
Built-in V,A,W measurements and waveform display
Independent control for each channel
Support more advanced functions: timer and delay output(standard),
recorder/analyzer/monitor/trigger(standard for “+A” models and optional for other models)
5-inch TFT display
Various interfaces: USB Host&Device(standard), USB-GPIB (optional),
LAN/RS232/Digital IO(standard for “+A” models and optional for other models)
For DP822, the high-resolution setting, trigger, monitor, analyzer as well as the RS232 and LAN
communication functions are all optional functions.

The DP900 Series Power Supplies combine our new touch screen interface with new flexibility and higher speed functions designed for benchtop DC power analysis. The DP932A and DP932U are 3 channel completely isolated benchtop power supplies. Activate the high-speed arb function that allows you to update the power supply output at up to 10 times per second while quickly creating a repeating shape or pattern from the front panel. You can also combine channels 1 and 2 internally either in parallel or in series to expand the power envelope for your testing. No more cabling challenges since you can now get the current or voltage for both channels with one cable connection. The DP932A comes with all the capabilities enabled. The DP932U has optional resolution, digital IO, and arbitrary speed upgrades. The DP932U also comes with safety banana plugs in place of the binding posts on the DP932A. This combination of flexibility and capability makes the DP900 an important addition to any engineer’s bench.

Technical specifications:

– Excellent linear regulation and load regulation ratio
– Fast transient response time: <50us
– Standard OVP / OCP / OTP protection functions
– Standard timing output
– Integrated V, A, W measurements and waveform display
– Independent control for each channel
– 3.5 inch TFT display
