Showing 1–30 of 1386 results
-
Power Supply
METAF MCP M10-QR305 2x30V/5A 5V/1A DC Linear Adjustable Power Supply
The MCP M10-QR305 2x30V/5A 5V/1A DC Linear Adjustable Power Supply is a equipment with high stability, high reliability, low noise, its output voltage or current can be continuously adjusted, and its constant voltage and current can auto-conversion. This low cost and universal power supply can be used in many different areas, from test of R&D equipment to test of production lines.
Features:
– Output off function
– Triple independent DC outputs. Two adjustable and one fixed output
– Independent, series and parallel variety output
– Constant voltage and constant current
– Low ripple and noise
– Four LED displays with 3 digits, selectable for two sets output voltage and current display simultaneously
– 16 hours continuous output with full load
– Auto tracking outputIndependent output:
CH1: 0-30V/0-05A
CH2: 0-30V/0-05A
CH3: 5V/1ASerial output:
CH1+CH2: 0-60V/0-5AParallel output:
CH1+CH2: 0-30V/0-10ASpecification:
Line Regulation: CV 1X10^-4+3mV CC 2X10^-3+3mA CH3 5mV
Load Regulation: CV 1X10^-4+4mV CC 2X10^-3+3mA CH3 15mV
Ripple & Noise: CV 1mVrms CC 3mA rms CH3 2mV
Display Accuracy: ±(0.5%Rdg+2digits)
Input Voltage: 110~127VAC±10%, 220~240VAC±10%
Dimensions (L x W x D): 250x135x460mm
Weight: 8,2 kgSKU: n/a -
Oscilloscope 4 channles
RIGOL DHO1204
200 MHz, 4 analog channels and 1 EXT channel, Real-time sample rate up to 2 GSa/s, Memory Depth up to 100 Mpts (optional), 12-bit vertical resolution, Up to 1,500,000 wfms/s waveform capture rate, 10.1'' 1280*800 HD touch display
Analog channel bandwidth: 200 MHz
4 analog channels and 1 EXT channel
12-bit vertical resolution
Real-time sample rate up to 2 GSa/s
Ultra-low noise floor for cleaner signals, measuring small signals accurately
Memory Depth up to 100 Mpts (optional)
Vertical sensitivity range: 500 μV/div to 10 V/div
Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode
10.1'' 1280*800 HD touch display
User-friendly Flex Knobs, bringing smoother interaction
Standard photoelectric encoder operating knobs, effectively prolonging its service life
Standard USB Device & Host, LAN, and HDMI interfacesSKU: n/a€1,699.00 View Product -
Senza categoria
Purex 072065 Solder Fume Extract Arm
The fume extraction system is designed to protect personnel from harmful inhalation of dust and fumes generated by a wide variety of applications, such as tinning and filling, bonding and chemical treatments, soldering assembly, rework and repair
• Electronic automatic flow control
• Speed control
• VariColour signaling system
• Filtration of particles and gases smaller than 1 micron
• Robust main HEPA filter
• Robust high grade stainless steel construction
• Silent Whisper Stream operation
• Voltage 230 V AC. 50/60 Hz
• Wattage 140W
• Nominal sound level 60 dBA
DatasheetSKU: n/a -
Attenuator
FMI ROTARY ATTENUATOR 14110 + Qty 2 of 14094-NF10 + 14040 + 14270-20-04 + CASE
The Flann Mircrowave FMI 14110 is a rotary attenuator, with the following features and accessories:
– Frequency Range: 5.38 – 8.18 GHz.
– Attenuation Range: 0 – 60dB.– Qty. 2 of Flann Microwave 14094-NF10
– Flann Microwave 14040
– Flann Microwave 14270-20-04
– CaseSKU: n/a -
ELECTRICAL SAFETY ANALYZER
CHROMA 19032
I test di sicurezza elettrica sono un elemento importante nei test di qualità dei prodotti elettrici. Tutti i prodotti elettrici come adattatori, SMPS, cariche, elettrodomestici, prodotti informatici e prodotti video devono essere sottoposti a test di sicurezza elettrica.
La serie 19032 combina i test Hipot, Resistenza di isolamento (IR), Ground Bond (GB), Corrente di dispersione (LC) / LC LC / CC LC e Funzione dinamica. Il risparmio di spazio può arrivare fino al 50% dello spazio della linea di produzione, non acquistando più strumenti di test di sicurezza. Il 19032 è in grado di aumentare l’efficienza dei test di sicurezza elettrica durante la produzione e ridurre i costi di manodopera associati.
SKU: n/a -
Senza categoria
EWIG CR200 Crucible for the tinning and rewinding of copper wires
EWIG CR200 Crucible for the tinning and rewinding of copper wires
Compatible with lead-free alloys
Electronic regulation of power and temperature from 0 to 500 ° C
200W-230V ~ 2000 10 504
200W-230V ~ 2000 10 553SKU: n/a -
Termocamera
FLIR E4 INFRARED CAMERA WITH MSX
The FLIR E4 thermal imaging camera is an easy-to-use troubleshooting tools for building, electrical, and mechanical applications. Find hidden problems, take accurate temperature readings, and confirm repairs were done correctly with the help of the 4,800 (80 x 60) pixel infrared resolution and FLIR Multi-Spectral Dynamic Imaging (MSX®) enhancements.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E4 has the features you need to accurately identify problems.CRISP RESOLUTION
The E4 has a crisp, 4,800 pixel detector that is just the right size for your application as well as your budget.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E4 features FLIR's unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera's LCD.
SKU: 776€849.00 View Product -
Termocamera
FLIR E5 INFRARED CAMERA WITH MSX
The FLIR E5 is a powerful thermal imaging tool for troubleshooting electrical, mechanical, and building problems. Find hidden issues quickly, easily, and safely–without the need for direct contact with equipment–with this 10,800 (120 x 90) pixel infrared resolution, focus-free camera. By providing thermal images along with accurate temperature measurements, the E5 is the ideal budget-friendly replacement for old-school IR thermometers.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E5 has the features you need to accurately identify problems.CRISP RESOLUTION
With its crisp, 10,800 pixel detector and ±2% accuracy, the E5 offers the best image clarity at this affordable price.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E5 features FLIR's unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera's LCD.
SKU: 779€1,049.00 View Product -
Termocamera
FLIR E6 INFRARED CAMERA WITH MSX
The FLIR E6 is the ultimate, affordable thermal inspection tool. Gain the competitive advantage, take care of more customers, and blow them away with dramatic MSX thermal images that clearly reveal problems–from sources of energy loss and structural issues to overheating electrical and mechanical equipment. Fully automatic and focus-free with an intuitive interface, the E6 offers 19,200 (160 × 120) pixels resolution in a rugged, drop-tested package.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E6 has the features you need to accurately identify problems.CRISP RESOLUTION
With its crisp, 19,200 pixel detector and ±2% accuracy, the E6 offers the best image clarity at this affordable price.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E6 features FLIR’s unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera’s LCD.
SKU: 778€1,695.00 View Product -
Termocamera
FLIR E8 INFRARED CAMERA WITH MSX
Gain a competitive advantage with the FLIR E8–our affordable, high-resolution thermal imaging camera for electrical, mechanical, and building inspection. Find hidden electrical faults, mechanical issues, and sources of energy loss thanks to the E8's crisp 76,800 (320 x 240) pixel infrared resolution and FLIR Multi-Spectral Dynamic Imaging (MSX®) image enhancements. The E8 is fully automatic, focus-free, and built to last, so you can use it with confidence in even the most rugged environments.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E8 has the features you need to accurately identify problems.SUPERIOR RESOLUTION
With its outstanding 76,800 pixel detector and ±2% accuracy, the E8 offers best-in-class image clarity.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E8 features FLIR's unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera's LCD.
SKU: 777€2,995.00 View Product -
Multimeter, Voltmeter
FLUKE 8840A 5.5 DIGIT BENCH MULTIMETER
The 8840A is a Digital Multimeter, 5.5 Digit.
• 5.5 digit resolution
• DC Volts
• 200 mV to 1000 V ranges
• 200 mV to 700 V ranges
• 20 Hz to 100 kHz bandwidth
• 200 ohms to 20 megohm ranges
• 2- or 4-wire selectable
• 2000 mA range
• 2000 mA range
• 20 Hz to 5 kHz bandwidth
• 100, 120/220, 240 Vac ±10%; 50, 60, 400 Hz operation
• Weight: 8 lb; Size: 89 mm (3.5 in)H x 216 mm (8.5 in)W x 371 mm (14.6 in)D
• Highly Legible Vacuum Fluorescent Display
• Intuitively Easy Front Panel Operation
• Basic DC Accuracy of 0.005% for 1 Year
• Up to 100 Readings Per Second
• Built-In Self-Tests
DatasheetSKU: 584 -
Transmission Analyzers
HP 37721A Digital Transmission Analyzer opt. 001-003
The 37718A communications performance analyzer is a single-box portable multi-rate BER and jitter tester up to 2.5 Gb/s (OC-48/STM-16) for development, qualification and manufacture of SONET, SDH, ATM and POS network equipment, sub-assemblies, line cards and devices.
* ATM and POS test capability to 2.5 Gb/s
* Concatenated payloads at all synchronous rates up to 2.5 Gb/s
* SmartTest facility for fast test setup
* Automatic detection of mixed payload signal structures
* Accurate measurement of protection switching times (ring and linear networks)
* Jitter generation and measurement at all rates (1.5, 2, 8, 34, 45, 140, 52, 155, 622 and 2,488 Mb/s)
* Jitter testing to ITU-T and Telcordia recommendationsSKU: n/a -
Attenuator
HP 11708A 30 dB Attenuator Pad, 50 MHz
The HP 11708A 30 dB attenuator is supplied with 8480 series power sensors with the “D” suffix, for calibration with the power meter 0 dBm, 50 MHz reference.
* Frequency Range: 50 MHz
* Attenuation: 30 dB ± 0.05 dB
* 50 ohm impedance
* SWR: <1.05 at 50 MHzSKU: n/a -
Power Meter
HP438A Dual Sensor Power Meter
The HP 438A power meter is a dual-channel power meter designed specifically for ATE systems. The compact front panel saves critical rack space, while the dual-channel design allows simple and accurate measurements of the ratio and difference of power levels from two separate sensors. This meter is compatible with the 8480 series of power sensors.
GPIB capability is standard on the 438A. For U.S. Air Force Modular Automatic Test Equipment (MATE) system application, Option 700 provides the 438A with the internal capability to be controlled by the MATE Control Interface Intermediate Language (CIIL).
* Two power sensors for multi-port measurement
* Ratio mode for measuring gain compression
* Programmable high and low power limits for unattended power monitoring
* Frequency: 100 kHz to 26.5 GHz
* Power Range: -70 to +44 dBm
* Dynamic Range: 50 dB
* Measurement Modes: A, B, A-B, B-A, A/B, B/ASKU: 1061 -
Microwave Counter/Power Meter
HP 5347A – 20 GHz Microwave Counter/Power Meter
The HP 5347A 20 GHz Microwave Counter/Power Meter offers the convenience of a single instrument that makes frequency and power measurements with accuracy and resolution comparable to stand-alone instruments. As a true power meter, the HP 5347A offers excellent dynamic range, linearity, and accuracy. It uses the same proven power sensors as HP's standalone power meters. The high-performance frequency counter measures frequency from 10 Hz to 20 GHz.
With only five function keys, the HP 5347A is especially easy to use. Its rugged, lightweight package, along with an optional internal battery that provides up to two hours of cordless measurements, makes the HP 5347A ideal for taking portable measurements.
* True power meter performance
* Negligible power meter error
* Outstanding frequency measurements
* Built-in sensor calibration tables save time
* External DC operation for greater measurement flexibility
* Supports three HP power sensorsSKU: n/a -
Power Sensor
HP 84812A Peak Power Sensor, 0.5-18 GHz, -40 dBm to 20 dBm
The HP 84812A peak power sensor is compatible with the obsolete 8990/1A peak power analyzers and the obsolete 8992A digital video power analyzer. This sensor gives you outstanding measurement accuracy in demanding situations and includes automatic temperature sensing and correction.
* Outstanding measurement accuracy
* Automatic temperature sensing and correctionSKU: 941 -
Attenuator
HP 8494G Programmable Step Attenuator, DC to 4 GHz
The 8494G dc to 4 GHz programmable step attenuator offers exceptional repeatability and reliability. Attenuation is provided in 1 dB steps from 0 to 11 dB. Precision gold-plated leaf springs ensure long-life (over 5 million cycles) and very high attenuator repeatability (typically 0.01 dB). To improve measurement accuracy, NIST traceable data (SWR and attenuation) is available as Option UK6. A maximum switching time of 20 ms (including contact settling) speeds automatic testing. Custom step attenuator/switch combinations are possible. The Keysight 11716A/B/C interconnect kits provide quick connection of Keysight 8494/5/6/7 1 dB and 10 dB step attenuators in series for greater dynamic range with 1 dB steps.
* Frequency range: dc to 4 GHz
* Insertion loss at 0 dB: 0.6 dB + 0.09 dB/GHz
* Maximum SWR: 1.5
* Repeatability life: 0.03 dB max 5 million cycles per section, typical
* 5 million cycles per section
* Maximum RF input power: 1 W (average), 100 W (peak)
* Connector type: choice of Type-N female, SMA female, APC-7
* Programming connector: 12-pin Viking, optional 14-pin DIPSKU: n/a -
PEAK POWER SENSOR
HP 8991A Peak Power Meter
The HP 8991A peak power analyzer provides complete and accurate characterization of today's complex pulsed signals. It is capable of performing seven automatic timing measurements (rise time, fall time, pulse width, PRI, PRF, duty cycle, and delay) and five automatic power measurement (peak power, average power, pulse top/base amplitude, and overshoot) with push-button ease. Front-panel operation is intuitive and straightforward. Data entries can be typed in or made with the front panel knob; automatic measurements are made with simple keystroke. The 8990A offers two sensor channels plus two external triggering/oscilloscope channels, allowing the simultaneous measurement of modulating signals and detector power envelopes.
* Amplitude and time markers for measuring power exactly where its needed
* Two oscilloscope channels for measuring time delay between video and microwave pulse
* Versatile triggering enables the capturing of exclusive glitches
* Waveform math functions for measuring scalar pulse parameters
* Dynamic Range: >45 dB
* Minimum Pulse Width: 20 ns
* Rise Time: <5 ns * Sensor and Video Inputs: 1 and 4; 2 and 3SKU: n/a -
Power Supply
HP E3616A 60W Power Supply, 35V, 1.7A
Keysight basic DC power supplies offer essential features for a tight budget.
The single output, 30-60 W, E3610A-E3617A provide small, compact size for bench use; low-noise and excellent regulation; and dual-range outputs (E3610A/11A/12A).
The Keysight 60W, single output E3616A is a reliable and convenient power for benchtop use, and offers solid performance and a variety of basic and enhanced capabilities.Output Ratings (Maximum current is derated 1% per °C between 40° to 55°C)
> Range 1: 0 to 35 V, 0 to 1.7 A
> Range 2: NA
> Power (max): 60 WRipple & Noise from 20 Hz to 20 MHz
> Voltage rms: 200 µV
> Peak-to-Peak: 1 mVLoad & Line Regulation
> 0.01% + 2 mVMeter Resolution
> Voltage: 10 mV (0-20 V), 100 mV (>20 V)
> Current: 1 mASKU: n/a -
Power Supply
HP-Agilent/Keysight E3620A
50W Dual Output Power Supply, Two 25V, 1A
Keysight basic DC power supplies offer essential features for a tight budget.
The multiple output, 35-50 W, E3620A and E3630A provide dual and triple outputs; small, compact size for bench use; low-noise and excellent regulation; and overload indicator to monitor output.
The Keysight 50W, dual output E3620A has two clean, reliable outputs for general purpose application; and is compact, affordable for versatile benchtop testing.Output ratings (Maximum current is derated 3.3% per °C from 40°C to 55°C)
> Output 1: 0 to 25 V, 0 to 1 A
> Output 2: 0 to 25 V, 0 to 1 A
> Power (max): 50 WRipple & noise from 20 Hz to 20 MHz
> Normal Mode Voltage rms: 350 µV
> Peak-to-Peak: 1.5 mVLoad & line regulation
> 0.01% + 2mVMeter resolution
> Voltage: 10 mV (0-20 V), 100 mV, (>20 V)
> Current: 1 mASKU: 1102 -
Cable
HP-Agilent/Keysight 11730A Sensore di potenza / Cavo sorgente rumore SNS (1,5 m / 5 piedi)
The Keysight 11730A/B/C/D/E cables are used with the N8480/8480 and E-series power sensors (except the E9320 family of peak and average sensors). These cables are designed to reduce RFI effects on low power readings with an improved shielding design in the cable itself. Cables may be ordered individually or in pairs in any combination desired for single and dual-channel measurements. The Keysight 11730A/B/C can also be used in conjunction with the SNS series noise sources which are designed to operate with the NFA Series Noise Figure Analyzers
SKU: 336€0.00 View Product -
Electronic Load Module, Lightwave Switch
HP-Agilent/Keysight 86060B
These electronic loads are particularly suited for the lab bench. Entering commands manually using the front panel keypad is simpler because the channel does not need to be specified, as in a mainframe configuration. Extensive protection is included to help protect your valuable prototypes under test. This includes overvoltage, over current, over temperature, overpower, and reverse polarity.
The Keysight 6060B is a 300 W, single output electronic load, ideal for evaluation of DC power sources and power components in bench applications. The 6060B has built-in measurement functions that make it convenient for testing single output applications in areas such as research and development, production, and incoming inspection.
The Keysight 6060B loads are suitable for manufacturing test systems where maximizing speed is not critical. They use industry standard SCPI instructions, and also have VXI Plug & Play drivers to simplify system design. For the greatest speed and accuracy in programming and measurement, see the DC Electronic Loads.
SKU: 399€650.00 View Product
-
Power Supply
METAF MCP M10-QR305 2x30V/5A 5V/1A DC Linear Adjustable Power Supply
The MCP M10-QR305 2x30V/5A 5V/1A DC Linear Adjustable Power Supply is a equipment with high stability, high reliability, low noise, its output voltage or current can be continuously adjusted, and its constant voltage and current can auto-conversion. This low cost and universal power supply can be used in many different areas, from test of R&D equipment to test of production lines.
Features:
– Output off function
– Triple independent DC outputs. Two adjustable and one fixed output
– Independent, series and parallel variety output
– Constant voltage and constant current
– Low ripple and noise
– Four LED displays with 3 digits, selectable for two sets output voltage and current display simultaneously
– 16 hours continuous output with full load
– Auto tracking outputIndependent output:
CH1: 0-30V/0-05A
CH2: 0-30V/0-05A
CH3: 5V/1ASerial output:
CH1+CH2: 0-60V/0-5AParallel output:
CH1+CH2: 0-30V/0-10ASpecification:
Line Regulation: CV 1X10^-4+3mV CC 2X10^-3+3mA CH3 5mV
Load Regulation: CV 1X10^-4+4mV CC 2X10^-3+3mA CH3 15mV
Ripple & Noise: CV 1mVrms CC 3mA rms CH3 2mV
Display Accuracy: ±(0.5%Rdg+2digits)
Input Voltage: 110~127VAC±10%, 220~240VAC±10%
Dimensions (L x W x D): 250x135x460mm
Weight: 8,2 kg -
Oscilloscope 4 channles
RIGOL DHO1204
200 MHz, 4 analog channels and 1 EXT channel, Real-time sample rate up to 2 GSa/s, Memory Depth up to 100 Mpts (optional), 12-bit vertical resolution, Up to 1,500,000 wfms/s waveform capture rate, 10.1'' 1280*800 HD touch display
Analog channel bandwidth: 200 MHz
4 analog channels and 1 EXT channel
12-bit vertical resolution
Real-time sample rate up to 2 GSa/s
Ultra-low noise floor for cleaner signals, measuring small signals accurately
Memory Depth up to 100 Mpts (optional)
Vertical sensitivity range: 500 μV/div to 10 V/div
Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode
10.1'' 1280*800 HD touch display
User-friendly Flex Knobs, bringing smoother interaction
Standard photoelectric encoder operating knobs, effectively prolonging its service life
Standard USB Device & Host, LAN, and HDMI interfaces -
Senza categoria
Purex 072065 Solder Fume Extract Arm
The fume extraction system is designed to protect personnel from harmful inhalation of dust and fumes generated by a wide variety of applications, such as tinning and filling, bonding and chemical treatments, soldering assembly, rework and repair
• Electronic automatic flow control
• Speed control
• VariColour signaling system
• Filtration of particles and gases smaller than 1 micron
• Robust main HEPA filter
• Robust high grade stainless steel construction
• Silent Whisper Stream operation
• Voltage 230 V AC. 50/60 Hz
• Wattage 140W
• Nominal sound level 60 dBA
Datasheet -
Attenuator
FMI ROTARY ATTENUATOR 14110 + Qty 2 of 14094-NF10 + 14040 + 14270-20-04 + CASE
The Flann Mircrowave FMI 14110 is a rotary attenuator, with the following features and accessories:
– Frequency Range: 5.38 – 8.18 GHz.
– Attenuation Range: 0 – 60dB.– Qty. 2 of Flann Microwave 14094-NF10
– Flann Microwave 14040
– Flann Microwave 14270-20-04
– Case -
ELECTRICAL SAFETY ANALYZER
CHROMA 19032
I test di sicurezza elettrica sono un elemento importante nei test di qualità dei prodotti elettrici. Tutti i prodotti elettrici come adattatori, SMPS, cariche, elettrodomestici, prodotti informatici e prodotti video devono essere sottoposti a test di sicurezza elettrica.
La serie 19032 combina i test Hipot, Resistenza di isolamento (IR), Ground Bond (GB), Corrente di dispersione (LC) / LC LC / CC LC e Funzione dinamica. Il risparmio di spazio può arrivare fino al 50% dello spazio della linea di produzione, non acquistando più strumenti di test di sicurezza. Il 19032 è in grado di aumentare l’efficienza dei test di sicurezza elettrica durante la produzione e ridurre i costi di manodopera associati.
-
Termocamera
FLIR E4 INFRARED CAMERA WITH MSX
The FLIR E4 thermal imaging camera is an easy-to-use troubleshooting tools for building, electrical, and mechanical applications. Find hidden problems, take accurate temperature readings, and confirm repairs were done correctly with the help of the 4,800 (80 x 60) pixel infrared resolution and FLIR Multi-Spectral Dynamic Imaging (MSX®) enhancements.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E4 has the features you need to accurately identify problems.CRISP RESOLUTION
The E4 has a crisp, 4,800 pixel detector that is just the right size for your application as well as your budget.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E4 features FLIR's unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera's LCD.
-
Termocamera
FLIR E5 INFRARED CAMERA WITH MSX
The FLIR E5 is a powerful thermal imaging tool for troubleshooting electrical, mechanical, and building problems. Find hidden issues quickly, easily, and safely–without the need for direct contact with equipment–with this 10,800 (120 x 90) pixel infrared resolution, focus-free camera. By providing thermal images along with accurate temperature measurements, the E5 is the ideal budget-friendly replacement for old-school IR thermometers.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E5 has the features you need to accurately identify problems.CRISP RESOLUTION
With its crisp, 10,800 pixel detector and ±2% accuracy, the E5 offers the best image clarity at this affordable price.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E5 features FLIR's unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera's LCD.
-
Termocamera
FLIR E6 INFRARED CAMERA WITH MSX
The FLIR E6 is the ultimate, affordable thermal inspection tool. Gain the competitive advantage, take care of more customers, and blow them away with dramatic MSX thermal images that clearly reveal problems–from sources of energy loss and structural issues to overheating electrical and mechanical equipment. Fully automatic and focus-free with an intuitive interface, the E6 offers 19,200 (160 × 120) pixels resolution in a rugged, drop-tested package.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E6 has the features you need to accurately identify problems.CRISP RESOLUTION
With its crisp, 19,200 pixel detector and ±2% accuracy, the E6 offers the best image clarity at this affordable price.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E6 features FLIR’s unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera’s LCD.
-
Termocamera
FLIR E8 INFRARED CAMERA WITH MSX
Gain a competitive advantage with the FLIR E8–our affordable, high-resolution thermal imaging camera for electrical, mechanical, and building inspection. Find hidden electrical faults, mechanical issues, and sources of energy loss thanks to the E8's crisp 76,800 (320 x 240) pixel infrared resolution and FLIR Multi-Spectral Dynamic Imaging (MSX®) image enhancements. The E8 is fully automatic, focus-free, and built to last, so you can use it with confidence in even the most rugged environments.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E8 has the features you need to accurately identify problems.SUPERIOR RESOLUTION
With its outstanding 76,800 pixel detector and ±2% accuracy, the E8 offers best-in-class image clarity.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E8 features FLIR's unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera's LCD.
-
Multimeter, Voltmeter
FLUKE 8840A 5.5 DIGIT BENCH MULTIMETER
The 8840A is a Digital Multimeter, 5.5 Digit.
• 5.5 digit resolution
• DC Volts
• 200 mV to 1000 V ranges
• 200 mV to 700 V ranges
• 20 Hz to 100 kHz bandwidth
• 200 ohms to 20 megohm ranges
• 2- or 4-wire selectable
• 2000 mA range
• 2000 mA range
• 20 Hz to 5 kHz bandwidth
• 100, 120/220, 240 Vac ±10%; 50, 60, 400 Hz operation
• Weight: 8 lb; Size: 89 mm (3.5 in)H x 216 mm (8.5 in)W x 371 mm (14.6 in)D
• Highly Legible Vacuum Fluorescent Display
• Intuitively Easy Front Panel Operation
• Basic DC Accuracy of 0.005% for 1 Year
• Up to 100 Readings Per Second
• Built-In Self-Tests
Datasheet -
Transmission Analyzers
HP 37721A Digital Transmission Analyzer opt. 001-003
The 37718A communications performance analyzer is a single-box portable multi-rate BER and jitter tester up to 2.5 Gb/s (OC-48/STM-16) for development, qualification and manufacture of SONET, SDH, ATM and POS network equipment, sub-assemblies, line cards and devices.
* ATM and POS test capability to 2.5 Gb/s
* Concatenated payloads at all synchronous rates up to 2.5 Gb/s
* SmartTest facility for fast test setup
* Automatic detection of mixed payload signal structures
* Accurate measurement of protection switching times (ring and linear networks)
* Jitter generation and measurement at all rates (1.5, 2, 8, 34, 45, 140, 52, 155, 622 and 2,488 Mb/s)
* Jitter testing to ITU-T and Telcordia recommendations -
Attenuator
HP 11708A 30 dB Attenuator Pad, 50 MHz
The HP 11708A 30 dB attenuator is supplied with 8480 series power sensors with the “D” suffix, for calibration with the power meter 0 dBm, 50 MHz reference.
* Frequency Range: 50 MHz
* Attenuation: 30 dB ± 0.05 dB
* 50 ohm impedance
* SWR: <1.05 at 50 MHz -
Power Meter
HP438A Dual Sensor Power Meter
The HP 438A power meter is a dual-channel power meter designed specifically for ATE systems. The compact front panel saves critical rack space, while the dual-channel design allows simple and accurate measurements of the ratio and difference of power levels from two separate sensors. This meter is compatible with the 8480 series of power sensors.
GPIB capability is standard on the 438A. For U.S. Air Force Modular Automatic Test Equipment (MATE) system application, Option 700 provides the 438A with the internal capability to be controlled by the MATE Control Interface Intermediate Language (CIIL).
* Two power sensors for multi-port measurement
* Ratio mode for measuring gain compression
* Programmable high and low power limits for unattended power monitoring
* Frequency: 100 kHz to 26.5 GHz
* Power Range: -70 to +44 dBm
* Dynamic Range: 50 dB
* Measurement Modes: A, B, A-B, B-A, A/B, B/A -
Microwave Counter/Power Meter
HP 5347A – 20 GHz Microwave Counter/Power Meter
The HP 5347A 20 GHz Microwave Counter/Power Meter offers the convenience of a single instrument that makes frequency and power measurements with accuracy and resolution comparable to stand-alone instruments. As a true power meter, the HP 5347A offers excellent dynamic range, linearity, and accuracy. It uses the same proven power sensors as HP's standalone power meters. The high-performance frequency counter measures frequency from 10 Hz to 20 GHz.
With only five function keys, the HP 5347A is especially easy to use. Its rugged, lightweight package, along with an optional internal battery that provides up to two hours of cordless measurements, makes the HP 5347A ideal for taking portable measurements.
* True power meter performance
* Negligible power meter error
* Outstanding frequency measurements
* Built-in sensor calibration tables save time
* External DC operation for greater measurement flexibility
* Supports three HP power sensors -
Power Sensor
HP 84812A Peak Power Sensor, 0.5-18 GHz, -40 dBm to 20 dBm
The HP 84812A peak power sensor is compatible with the obsolete 8990/1A peak power analyzers and the obsolete 8992A digital video power analyzer. This sensor gives you outstanding measurement accuracy in demanding situations and includes automatic temperature sensing and correction.
* Outstanding measurement accuracy
* Automatic temperature sensing and correction -
Attenuator
HP 8494G Programmable Step Attenuator, DC to 4 GHz
The 8494G dc to 4 GHz programmable step attenuator offers exceptional repeatability and reliability. Attenuation is provided in 1 dB steps from 0 to 11 dB. Precision gold-plated leaf springs ensure long-life (over 5 million cycles) and very high attenuator repeatability (typically 0.01 dB). To improve measurement accuracy, NIST traceable data (SWR and attenuation) is available as Option UK6. A maximum switching time of 20 ms (including contact settling) speeds automatic testing. Custom step attenuator/switch combinations are possible. The Keysight 11716A/B/C interconnect kits provide quick connection of Keysight 8494/5/6/7 1 dB and 10 dB step attenuators in series for greater dynamic range with 1 dB steps.
* Frequency range: dc to 4 GHz
* Insertion loss at 0 dB: 0.6 dB + 0.09 dB/GHz
* Maximum SWR: 1.5
* Repeatability life: 0.03 dB max 5 million cycles per section, typical
* 5 million cycles per section
* Maximum RF input power: 1 W (average), 100 W (peak)
* Connector type: choice of Type-N female, SMA female, APC-7
* Programming connector: 12-pin Viking, optional 14-pin DIP -
PEAK POWER SENSOR
HP 8991A Peak Power Meter
The HP 8991A peak power analyzer provides complete and accurate characterization of today's complex pulsed signals. It is capable of performing seven automatic timing measurements (rise time, fall time, pulse width, PRI, PRF, duty cycle, and delay) and five automatic power measurement (peak power, average power, pulse top/base amplitude, and overshoot) with push-button ease. Front-panel operation is intuitive and straightforward. Data entries can be typed in or made with the front panel knob; automatic measurements are made with simple keystroke. The 8990A offers two sensor channels plus two external triggering/oscilloscope channels, allowing the simultaneous measurement of modulating signals and detector power envelopes.
* Amplitude and time markers for measuring power exactly where its needed
* Two oscilloscope channels for measuring time delay between video and microwave pulse
* Versatile triggering enables the capturing of exclusive glitches
* Waveform math functions for measuring scalar pulse parameters
* Dynamic Range: >45 dB
* Minimum Pulse Width: 20 ns
* Rise Time: <5 ns * Sensor and Video Inputs: 1 and 4; 2 and 3 -
Power Supply
HP E3616A 60W Power Supply, 35V, 1.7A
Keysight basic DC power supplies offer essential features for a tight budget.
The single output, 30-60 W, E3610A-E3617A provide small, compact size for bench use; low-noise and excellent regulation; and dual-range outputs (E3610A/11A/12A).
The Keysight 60W, single output E3616A is a reliable and convenient power for benchtop use, and offers solid performance and a variety of basic and enhanced capabilities.Output Ratings (Maximum current is derated 1% per °C between 40° to 55°C)
> Range 1: 0 to 35 V, 0 to 1.7 A
> Range 2: NA
> Power (max): 60 WRipple & Noise from 20 Hz to 20 MHz
> Voltage rms: 200 µV
> Peak-to-Peak: 1 mVLoad & Line Regulation
> 0.01% + 2 mVMeter Resolution
> Voltage: 10 mV (0-20 V), 100 mV (>20 V)
> Current: 1 mA -
Power Supply
HP-Agilent/Keysight E3620A
50W Dual Output Power Supply, Two 25V, 1A
Keysight basic DC power supplies offer essential features for a tight budget.
The multiple output, 35-50 W, E3620A and E3630A provide dual and triple outputs; small, compact size for bench use; low-noise and excellent regulation; and overload indicator to monitor output.
The Keysight 50W, dual output E3620A has two clean, reliable outputs for general purpose application; and is compact, affordable for versatile benchtop testing.Output ratings (Maximum current is derated 3.3% per °C from 40°C to 55°C)
> Output 1: 0 to 25 V, 0 to 1 A
> Output 2: 0 to 25 V, 0 to 1 A
> Power (max): 50 WRipple & noise from 20 Hz to 20 MHz
> Normal Mode Voltage rms: 350 µV
> Peak-to-Peak: 1.5 mVLoad & line regulation
> 0.01% + 2mVMeter resolution
> Voltage: 10 mV (0-20 V), 100 mV, (>20 V)
> Current: 1 mA -
Cable
HP-Agilent/Keysight 11730A Sensore di potenza / Cavo sorgente rumore SNS (1,5 m / 5 piedi)
The Keysight 11730A/B/C/D/E cables are used with the N8480/8480 and E-series power sensors (except the E9320 family of peak and average sensors). These cables are designed to reduce RFI effects on low power readings with an improved shielding design in the cable itself. Cables may be ordered individually or in pairs in any combination desired for single and dual-channel measurements. The Keysight 11730A/B/C can also be used in conjunction with the SNS series noise sources which are designed to operate with the NFA Series Noise Figure Analyzers
-
Electronic Load Module, Lightwave Switch
HP-Agilent/Keysight 86060B
These electronic loads are particularly suited for the lab bench. Entering commands manually using the front panel keypad is simpler because the channel does not need to be specified, as in a mainframe configuration. Extensive protection is included to help protect your valuable prototypes under test. This includes overvoltage, over current, over temperature, overpower, and reverse polarity.
The Keysight 6060B is a 300 W, single output electronic load, ideal for evaluation of DC power sources and power components in bench applications. The 6060B has built-in measurement functions that make it convenient for testing single output applications in areas such as research and development, production, and incoming inspection.
The Keysight 6060B loads are suitable for manufacturing test systems where maximizing speed is not critical. They use industry standard SCPI instructions, and also have VXI Plug & Play drivers to simplify system design. For the greatest speed and accuracy in programming and measurement, see the DC Electronic Loads.
-
Power Supply
METAF MCP M10-QR305 2x30V/5A 5V/1A DC Linear Adjustable Power Supply
The MCP M10-QR305 2x30V/5A 5V/1A DC Linear Adjustable Power Supply is a equipment with high stability, high reliability, low noise, its output voltage or current can be continuously adjusted, and its constant voltage and current can auto-conversion. This low cost and universal power supply can be used in many different areas, from test of R&D equipment to test of production lines.
Features:
– Output off function
– Triple independent DC outputs. Two adjustable and one fixed output
– Independent, series and parallel variety output
– Constant voltage and constant current
– Low ripple and noise
– Four LED displays with 3 digits, selectable for two sets output voltage and current display simultaneously
– 16 hours continuous output with full load
– Auto tracking outputIndependent output:
CH1: 0-30V/0-05A
CH2: 0-30V/0-05A
CH3: 5V/1ASerial output:
CH1+CH2: 0-60V/0-5AParallel output:
CH1+CH2: 0-30V/0-10ASpecification:
Line Regulation: CV 1X10^-4+3mV CC 2X10^-3+3mA CH3 5mV
Load Regulation: CV 1X10^-4+4mV CC 2X10^-3+3mA CH3 15mV
Ripple & Noise: CV 1mVrms CC 3mA rms CH3 2mV
Display Accuracy: ±(0.5%Rdg+2digits)
Input Voltage: 110~127VAC±10%, 220~240VAC±10%
Dimensions (L x W x D): 250x135x460mm
Weight: 8,2 kg -
Oscilloscope 4 channles
RIGOL DHO1204
200 MHz, 4 analog channels and 1 EXT channel, Real-time sample rate up to 2 GSa/s, Memory Depth up to 100 Mpts (optional), 12-bit vertical resolution, Up to 1,500,000 wfms/s waveform capture rate, 10.1'' 1280*800 HD touch display
Analog channel bandwidth: 200 MHz
4 analog channels and 1 EXT channel
12-bit vertical resolution
Real-time sample rate up to 2 GSa/s
Ultra-low noise floor for cleaner signals, measuring small signals accurately
Memory Depth up to 100 Mpts (optional)
Vertical sensitivity range: 500 μV/div to 10 V/div
Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode
10.1'' 1280*800 HD touch display
User-friendly Flex Knobs, bringing smoother interaction
Standard photoelectric encoder operating knobs, effectively prolonging its service life
Standard USB Device & Host, LAN, and HDMI interfaces€1,699.00 View Product -
Senza categoria
Purex 072065 Solder Fume Extract Arm
The fume extraction system is designed to protect personnel from harmful inhalation of dust and fumes generated by a wide variety of applications, such as tinning and filling, bonding and chemical treatments, soldering assembly, rework and repair
• Electronic automatic flow control
• Speed control
• VariColour signaling system
• Filtration of particles and gases smaller than 1 micron
• Robust main HEPA filter
• Robust high grade stainless steel construction
• Silent Whisper Stream operation
• Voltage 230 V AC. 50/60 Hz
• Wattage 140W
• Nominal sound level 60 dBA
Datasheet -
Attenuator
FMI ROTARY ATTENUATOR 14110 + Qty 2 of 14094-NF10 + 14040 + 14270-20-04 + CASE
The Flann Mircrowave FMI 14110 is a rotary attenuator, with the following features and accessories:
– Frequency Range: 5.38 – 8.18 GHz.
– Attenuation Range: 0 – 60dB.– Qty. 2 of Flann Microwave 14094-NF10
– Flann Microwave 14040
– Flann Microwave 14270-20-04
– Case -
ELECTRICAL SAFETY ANALYZER
CHROMA 19032
I test di sicurezza elettrica sono un elemento importante nei test di qualità dei prodotti elettrici. Tutti i prodotti elettrici come adattatori, SMPS, cariche, elettrodomestici, prodotti informatici e prodotti video devono essere sottoposti a test di sicurezza elettrica.
La serie 19032 combina i test Hipot, Resistenza di isolamento (IR), Ground Bond (GB), Corrente di dispersione (LC) / LC LC / CC LC e Funzione dinamica. Il risparmio di spazio può arrivare fino al 50% dello spazio della linea di produzione, non acquistando più strumenti di test di sicurezza. Il 19032 è in grado di aumentare l’efficienza dei test di sicurezza elettrica durante la produzione e ridurre i costi di manodopera associati.
-
Termocamera
FLIR E4 INFRARED CAMERA WITH MSX
The FLIR E4 thermal imaging camera is an easy-to-use troubleshooting tools for building, electrical, and mechanical applications. Find hidden problems, take accurate temperature readings, and confirm repairs were done correctly with the help of the 4,800 (80 x 60) pixel infrared resolution and FLIR Multi-Spectral Dynamic Imaging (MSX®) enhancements.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E4 has the features you need to accurately identify problems.CRISP RESOLUTION
The E4 has a crisp, 4,800 pixel detector that is just the right size for your application as well as your budget.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E4 features FLIR's unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera's LCD.
€849.00 View Product -
Termocamera
FLIR E5 INFRARED CAMERA WITH MSX
The FLIR E5 is a powerful thermal imaging tool for troubleshooting electrical, mechanical, and building problems. Find hidden issues quickly, easily, and safely–without the need for direct contact with equipment–with this 10,800 (120 x 90) pixel infrared resolution, focus-free camera. By providing thermal images along with accurate temperature measurements, the E5 is the ideal budget-friendly replacement for old-school IR thermometers.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E5 has the features you need to accurately identify problems.CRISP RESOLUTION
With its crisp, 10,800 pixel detector and ±2% accuracy, the E5 offers the best image clarity at this affordable price.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E5 features FLIR's unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera's LCD.
€1,049.00 View Product -
Termocamera
FLIR E6 INFRARED CAMERA WITH MSX
The FLIR E6 is the ultimate, affordable thermal inspection tool. Gain the competitive advantage, take care of more customers, and blow them away with dramatic MSX thermal images that clearly reveal problems–from sources of energy loss and structural issues to overheating electrical and mechanical equipment. Fully automatic and focus-free with an intuitive interface, the E6 offers 19,200 (160 × 120) pixels resolution in a rugged, drop-tested package.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E6 has the features you need to accurately identify problems.CRISP RESOLUTION
With its crisp, 19,200 pixel detector and ±2% accuracy, the E6 offers the best image clarity at this affordable price.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E6 features FLIR’s unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera’s LCD.
€1,695.00 View Product -
Termocamera
FLIR E8 INFRARED CAMERA WITH MSX
Gain a competitive advantage with the FLIR E8–our affordable, high-resolution thermal imaging camera for electrical, mechanical, and building inspection. Find hidden electrical faults, mechanical issues, and sources of energy loss thanks to the E8's crisp 76,800 (320 x 240) pixel infrared resolution and FLIR Multi-Spectral Dynamic Imaging (MSX®) image enhancements. The E8 is fully automatic, focus-free, and built to last, so you can use it with confidence in even the most rugged environments.
PROFESSIONAL MEASUREMENT FEATURES
From the hot/cold-spot measurements to the emissivity controls, E8 has the features you need to accurately identify problems.SUPERIOR RESOLUTION
With its outstanding 76,800 pixel detector and ±2% accuracy, the E8 offers best-in-class image clarity.THE POWER OF ONE BUTTON
A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.The E8 features FLIR's unique MSX that adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera's LCD.
€2,995.00 View Product -
Multimeter, Voltmeter
FLUKE 8840A 5.5 DIGIT BENCH MULTIMETER
The 8840A is a Digital Multimeter, 5.5 Digit.
• 5.5 digit resolution
• DC Volts
• 200 mV to 1000 V ranges
• 200 mV to 700 V ranges
• 20 Hz to 100 kHz bandwidth
• 200 ohms to 20 megohm ranges
• 2- or 4-wire selectable
• 2000 mA range
• 2000 mA range
• 20 Hz to 5 kHz bandwidth
• 100, 120/220, 240 Vac ±10%; 50, 60, 400 Hz operation
• Weight: 8 lb; Size: 89 mm (3.5 in)H x 216 mm (8.5 in)W x 371 mm (14.6 in)D
• Highly Legible Vacuum Fluorescent Display
• Intuitively Easy Front Panel Operation
• Basic DC Accuracy of 0.005% for 1 Year
• Up to 100 Readings Per Second
• Built-In Self-Tests
Datasheet -
Transmission Analyzers
HP 37721A Digital Transmission Analyzer opt. 001-003
The 37718A communications performance analyzer is a single-box portable multi-rate BER and jitter tester up to 2.5 Gb/s (OC-48/STM-16) for development, qualification and manufacture of SONET, SDH, ATM and POS network equipment, sub-assemblies, line cards and devices.
* ATM and POS test capability to 2.5 Gb/s
* Concatenated payloads at all synchronous rates up to 2.5 Gb/s
* SmartTest facility for fast test setup
* Automatic detection of mixed payload signal structures
* Accurate measurement of protection switching times (ring and linear networks)
* Jitter generation and measurement at all rates (1.5, 2, 8, 34, 45, 140, 52, 155, 622 and 2,488 Mb/s)
* Jitter testing to ITU-T and Telcordia recommendations -
Attenuator
HP 11708A 30 dB Attenuator Pad, 50 MHz
The HP 11708A 30 dB attenuator is supplied with 8480 series power sensors with the “D” suffix, for calibration with the power meter 0 dBm, 50 MHz reference.
* Frequency Range: 50 MHz
* Attenuation: 30 dB ± 0.05 dB
* 50 ohm impedance
* SWR: <1.05 at 50 MHz -
Power Meter
HP438A Dual Sensor Power Meter
The HP 438A power meter is a dual-channel power meter designed specifically for ATE systems. The compact front panel saves critical rack space, while the dual-channel design allows simple and accurate measurements of the ratio and difference of power levels from two separate sensors. This meter is compatible with the 8480 series of power sensors.
GPIB capability is standard on the 438A. For U.S. Air Force Modular Automatic Test Equipment (MATE) system application, Option 700 provides the 438A with the internal capability to be controlled by the MATE Control Interface Intermediate Language (CIIL).
* Two power sensors for multi-port measurement
* Ratio mode for measuring gain compression
* Programmable high and low power limits for unattended power monitoring
* Frequency: 100 kHz to 26.5 GHz
* Power Range: -70 to +44 dBm
* Dynamic Range: 50 dB
* Measurement Modes: A, B, A-B, B-A, A/B, B/A -
Microwave Counter/Power Meter
HP 5347A – 20 GHz Microwave Counter/Power Meter
The HP 5347A 20 GHz Microwave Counter/Power Meter offers the convenience of a single instrument that makes frequency and power measurements with accuracy and resolution comparable to stand-alone instruments. As a true power meter, the HP 5347A offers excellent dynamic range, linearity, and accuracy. It uses the same proven power sensors as HP's standalone power meters. The high-performance frequency counter measures frequency from 10 Hz to 20 GHz.
With only five function keys, the HP 5347A is especially easy to use. Its rugged, lightweight package, along with an optional internal battery that provides up to two hours of cordless measurements, makes the HP 5347A ideal for taking portable measurements.
* True power meter performance
* Negligible power meter error
* Outstanding frequency measurements
* Built-in sensor calibration tables save time
* External DC operation for greater measurement flexibility
* Supports three HP power sensors -
Power Sensor
HP 84812A Peak Power Sensor, 0.5-18 GHz, -40 dBm to 20 dBm
The HP 84812A peak power sensor is compatible with the obsolete 8990/1A peak power analyzers and the obsolete 8992A digital video power analyzer. This sensor gives you outstanding measurement accuracy in demanding situations and includes automatic temperature sensing and correction.
* Outstanding measurement accuracy
* Automatic temperature sensing and correction -
Attenuator
HP 8494G Programmable Step Attenuator, DC to 4 GHz
The 8494G dc to 4 GHz programmable step attenuator offers exceptional repeatability and reliability. Attenuation is provided in 1 dB steps from 0 to 11 dB. Precision gold-plated leaf springs ensure long-life (over 5 million cycles) and very high attenuator repeatability (typically 0.01 dB). To improve measurement accuracy, NIST traceable data (SWR and attenuation) is available as Option UK6. A maximum switching time of 20 ms (including contact settling) speeds automatic testing. Custom step attenuator/switch combinations are possible. The Keysight 11716A/B/C interconnect kits provide quick connection of Keysight 8494/5/6/7 1 dB and 10 dB step attenuators in series for greater dynamic range with 1 dB steps.
* Frequency range: dc to 4 GHz
* Insertion loss at 0 dB: 0.6 dB + 0.09 dB/GHz
* Maximum SWR: 1.5
* Repeatability life: 0.03 dB max 5 million cycles per section, typical
* 5 million cycles per section
* Maximum RF input power: 1 W (average), 100 W (peak)
* Connector type: choice of Type-N female, SMA female, APC-7
* Programming connector: 12-pin Viking, optional 14-pin DIP -
PEAK POWER SENSOR
HP 8991A Peak Power Meter
The HP 8991A peak power analyzer provides complete and accurate characterization of today's complex pulsed signals. It is capable of performing seven automatic timing measurements (rise time, fall time, pulse width, PRI, PRF, duty cycle, and delay) and five automatic power measurement (peak power, average power, pulse top/base amplitude, and overshoot) with push-button ease. Front-panel operation is intuitive and straightforward. Data entries can be typed in or made with the front panel knob; automatic measurements are made with simple keystroke. The 8990A offers two sensor channels plus two external triggering/oscilloscope channels, allowing the simultaneous measurement of modulating signals and detector power envelopes.
* Amplitude and time markers for measuring power exactly where its needed
* Two oscilloscope channels for measuring time delay between video and microwave pulse
* Versatile triggering enables the capturing of exclusive glitches
* Waveform math functions for measuring scalar pulse parameters
* Dynamic Range: >45 dB
* Minimum Pulse Width: 20 ns
* Rise Time: <5 ns * Sensor and Video Inputs: 1 and 4; 2 and 3 -
Power Supply
HP E3616A 60W Power Supply, 35V, 1.7A
Keysight basic DC power supplies offer essential features for a tight budget.
The single output, 30-60 W, E3610A-E3617A provide small, compact size for bench use; low-noise and excellent regulation; and dual-range outputs (E3610A/11A/12A).
The Keysight 60W, single output E3616A is a reliable and convenient power for benchtop use, and offers solid performance and a variety of basic and enhanced capabilities.Output Ratings (Maximum current is derated 1% per °C between 40° to 55°C)
> Range 1: 0 to 35 V, 0 to 1.7 A
> Range 2: NA
> Power (max): 60 WRipple & Noise from 20 Hz to 20 MHz
> Voltage rms: 200 µV
> Peak-to-Peak: 1 mVLoad & Line Regulation
> 0.01% + 2 mVMeter Resolution
> Voltage: 10 mV (0-20 V), 100 mV (>20 V)
> Current: 1 mA -
Power Supply
HP-Agilent/Keysight E3620A
50W Dual Output Power Supply, Two 25V, 1A
Keysight basic DC power supplies offer essential features for a tight budget.
The multiple output, 35-50 W, E3620A and E3630A provide dual and triple outputs; small, compact size for bench use; low-noise and excellent regulation; and overload indicator to monitor output.
The Keysight 50W, dual output E3620A has two clean, reliable outputs for general purpose application; and is compact, affordable for versatile benchtop testing.Output ratings (Maximum current is derated 3.3% per °C from 40°C to 55°C)
> Output 1: 0 to 25 V, 0 to 1 A
> Output 2: 0 to 25 V, 0 to 1 A
> Power (max): 50 WRipple & noise from 20 Hz to 20 MHz
> Normal Mode Voltage rms: 350 µV
> Peak-to-Peak: 1.5 mVLoad & line regulation
> 0.01% + 2mVMeter resolution
> Voltage: 10 mV (0-20 V), 100 mV, (>20 V)
> Current: 1 mA -
Cable
HP-Agilent/Keysight 11730A Sensore di potenza / Cavo sorgente rumore SNS (1,5 m / 5 piedi)
The Keysight 11730A/B/C/D/E cables are used with the N8480/8480 and E-series power sensors (except the E9320 family of peak and average sensors). These cables are designed to reduce RFI effects on low power readings with an improved shielding design in the cable itself. Cables may be ordered individually or in pairs in any combination desired for single and dual-channel measurements. The Keysight 11730A/B/C can also be used in conjunction with the SNS series noise sources which are designed to operate with the NFA Series Noise Figure Analyzers
€0.00 View Product -
Electronic Load Module, Lightwave Switch
HP-Agilent/Keysight 86060B
These electronic loads are particularly suited for the lab bench. Entering commands manually using the front panel keypad is simpler because the channel does not need to be specified, as in a mainframe configuration. Extensive protection is included to help protect your valuable prototypes under test. This includes overvoltage, over current, over temperature, overpower, and reverse polarity.
The Keysight 6060B is a 300 W, single output electronic load, ideal for evaluation of DC power sources and power components in bench applications. The 6060B has built-in measurement functions that make it convenient for testing single output applications in areas such as research and development, production, and incoming inspection.
The Keysight 6060B loads are suitable for manufacturing test systems where maximizing speed is not critical. They use industry standard SCPI instructions, and also have VXI Plug & Play drivers to simplify system design. For the greatest speed and accuracy in programming and measurement, see the DC Electronic Loads.
€650.00 View Product
