RIGOL RSA3015N

For all new order of RSA3000N versions (not valid for RSA3000E versions) we providing free of charge EMI
and Pre-Amplifier Option (RSA3000-EMI and RSA3000-PA)

The RSA3000 series, real-time spectrum analyzer integrates in a single instrument four measurement modes to face in the most complete way all the demands posed by the recent and increasingly sophisticated RF test requirements.
In addition to the traditional GPSA mode, EMI, RTSA and VNA modes are offered. This tool reduces the time and cost of RF test development and with its performance greatly improves the development and testing of RF products. The user interface is clear and allows you to operate in different ways, buttons on the front panel, touch screen, mouse and keyboard. Remote communication interfaces are also available.
It is a very versatile tool and can be used with excellent results indifferently in education, in R&D, in industrial production.

Features:

-Ultra real technology
Average Display Noise Level (DANL): <-161 dBm (typical)
Phase noise: <-102 dBc / Hz (typical)
– Level measurement uncertainty: <1.0 dB
-4.5 GHz tracking generator
– Up to 40 MHz of bandwidth for real-time analysis
-Multiple measurement modes
-Various advanced measurement functions
-EMI measurement application (option)
– Vector network analyzer application
-Multiple trigger modes and trigger masks
-Density, spectrogram and other display modes
– PC software options
-10.1 '' capacitive multi-touch screen; support tactile gestures
-USB, LAN, HDMI and other communication and display interfaces

Datasheet
