RIGOL DP2031

DC power supply with 3 independent output channels (+32 V / 3 A, +32 V / 3 A, +6 V / 5 A, DC, max 222 W). 4.3-inch LCD color touch screen. High resolution for measurement of 1 μA low range current. Low output ripple and noise <350 μVrms/2 mVpp. USB HOST, LAN, Digital I/O, and RS232 (standard)

3 electrically isolated independent channels with a maximum total power of up to 222 W
32 V/3 A || 32 V/3 A || 6 V/5 A (standard)
32 V/2 A || 32 V/2 A || 6 V/10 A (optional)
4.3-inch LCD color touch screen
Internal series/parallel connections for CH1 and CH2
High resolution for measurement of 1 μA low range current
Capability to measure and display wide dynamic ranges of current
Excellent programming/readback accuracy
Transient response time <50 μs
Front and rear output terminals
2-wire or 4-wire remote sense
A maximum of 512 arbitrary points with dwell time down to 1 ms; various built-in basic waveforms
Low output ripple and noise <350 μVrms/2 mVpp
Command processing time <10 ms
Automatic switchover between low and high range measurement
Timing output, energy consumption analysis (IoT), data logging and analysis
Capability to measure the minimum of 1 ms pulse current
Three rack-units (3U), 1/2-rack form factor
Software control
Over voltage, over current, and over temperature protection
Various interfaces available: USB HOST, LAN, Digital I/O, and RS232 (standard)
