HP-Agilent/Keysight E3632A

DC power supplies basic programmable Keysight E3631A, E3632A, E3633A and E3634A offer users the performance of system power supplies at a very competitive price. All models offer clean power, excellent regulation, and fast transient response with integrated GPIB and RS-232 interfaces. While affordability is a key attribute, these power supplies have the quality and reliability needed to meet the most demanding applications, such as in R&D project verification, production testing and QA verification.

The E3632A-E3634A, 120-200W GPIB, single output device offers dual range outputs, compact size and contained for bench use; reduced output ripple and noise; and integrated and basic programmable sensing capabilities with GPIB and RS232 interface. Agilent's E3632A 120W, GPIB, Single Output Device is a high performance power supply optimized for basic and manual automated testing; in addition, with a combination of benchtop features and system functionality, it is designed to improve measurement quality and reduce test time.

DC power supplies Keysight offer essential features for a limited budget. The E3632A-E3634A, 120-200W GPIB, single output device offers dual range outputs, compact size and contained for bench use; reduced output ripple and noise; and integrated and basic programmable sensing capabilities with GPIB and RS232 interface. The Keysight 120W, GPIB, single output E3633A device is a high performance power supply optimized for manual and basic automated testing; in addition, with a combination of benchtop features and system functionality, it is designed to improve measurement quality and reduce test time.

Features
Output ratings
Range 1: 0 to 15 V, 7 A
Range 2: 0 to 30 V, 4 A

Programming accuracy at 25 ° C ± 5 ° C

Voltage: 0.05% + 10mV
Current: 0.2% +10 mA

Ripple & noise (20 Hz to 20 MHz)
Normal-mode voltage
Normal-mode current
Common-mode current

Readback accuracy at 25 ° C ± 5 ° C
Voltage: 0.05% + 5mV
Current: 0.15% + 5 mA
Datasheet
