Rigol DS6062

DSO with 600MHz bandwidth and 5GSa/s
The Rigol DS6062 is a very high quality two channel digital storage oscilloscope. It offers up to 5GSa/s real-time sample rate and up to 600MHz bandwidth. These high performances ensure not only to capture real-time instantaneous signal, but also to observe details of repeated signal. DS6062 have up to 120.000 wfms/s refresh rate, which enable users to capture instantaneous signal and abnormal signal more quickly, to enhance waveform capturing ability, and to expedite circuit debug course. The quality of the Rigol Oscilloscopes is comparable to Agilent and Tektronix oscilloscopes. Other advantages: 10.1″ color LCD, bright and vivid waveform display- versatile trigger modes: i.e. slope, alternative, rise&fall edge, enable users to stabilize signal more easily. In economical oscilloscope field, DS6062 have no doubt the highest performances, the most functions thus should be engineers’ best choice. Delivery including 2 probes (bandwidth 600MHz), USB cable, pc software, power adapter and manual. General Data Digital Oscilloscope Digital Oscilloscope Rigol DS6062 Display 10,1″ WVGA-Color-LCD Resolution 800 x 480 Pixel Interface 2x USB-host for i.e. USB sticks USB-Device for a PC connection or USB Pict-Bridge printerinterface LAN for network connectivity (LXI compilant) GPIB (IEE-488, General Purpose Interface Bus) using the optional USB-GPIB Module Trigger- and Calibrationoutput 10MHz reference clock In-/Out VGA interface to connect to an external monitor or projector Size in clarification Weight in clarification Supported operation systems in clarification Oscilloscope Functions Oscilloscope Functions Digital Oscilloscope Rigol DS6062 Channels 2 Real-time sample rate 5 GSa/s realtime Bandwidth 600 MHz Sampling Modus Normal, average, peak detect Mathematics userdefined, FFT (Fast Fourier Transform) FFT algorithm Rectangle, Hanning, Hamming, Blackman Signal Bus Decoding I²C, RS232, SPI, USB, CAN and FlexRay Signal Digital Oscilloscope Rigol DS6062 Input DC/AC coupling, up to 300 Vrms CAT I Real-time sample rate up to 5 GSa/s realtime Time base in clarification Memory 140Mpts (1 Channel) Filter Hardware LPF, HPF, BPF and BRF Vertical Digital Oscilloscope Rigol DS6062 Analog digital converter (A/D) With the resolution of 8 bits, make sampling on both channels synchronously. Sensitivity range (V/div) in clarification Displacement range in clarification Trigger Digital Oscilloscope Rigol DS6062 Trigger in clarification Signal system and line/field frequency (Video triggering mode) in clarification Triggerfunctions Edge, Pattern, Glitch, Puls width, Sequence, Slew rate, I²C, RS232/UART, CAN, FlexRay, USB, SPI, Video Measurement Digital Oscilloscope Rigol DS6062 Cursor measurement Manual, Track and Auto Measure modes Auto measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall time, Positive Width, Negative Width, Positive Duty Cycle, Negative Duty Cycle, Delay1-2 (rise), Delay1-2(fall)
