RIGOL DG4202

DG4000 series is a multifunctional generator that combines many functions in one, including Function Generator, Arbitrary Waveform Generator, Pulse Generator, Harmonic Generator, Analog/Digital Modulator and Counter. All the models have two channels with complete equivalent functions and precisely adjustable phases.
The Rigol DG4162 is two channel function / arbitary waveform generator to create high quality signals up to 160 MHz (Sine). Beside the analog output, the device includes an USB-Host- and an USB-device and a LAN interface.
The Rigol Function-generators have a sophisticated and easy to use interface and offer multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.

•         Maximum output frequency: 200MHz, 160MHz, 100MHz, 60MHz
•          500MSa/s sample rate, 14 bit vertical resolution
•          Dual channel outputs with identical performance
•          2ppm high-frequency stability
•         -115dBc/Hz low phase noise
•         Versatile analog and digital modulation functions
•         150 built-in waveforms
•          7digits/s, 200MHz built-in Counter
•         Harmonic generator that can generate up to 16th order of harmonic (Std.)
•          Powerful waveform editing PC software
•          Connectivity: USB Host & Device, LAN
•         7 inch LCD display (800 × 480)

Datasheet
