CHATILLON DFM-100

Chatillon DFM-100 Digital Force Gauge with Integral Loadcell, DFM Series, tensile or compression measurement, 100 lb x 0.1 lb 50 kg x 0.05 kg 500 N x 0.5 N. A remarkably cost effective digital force gauge offering digital accuracy, versatility and extreme ease of use. Four element keypad controls basic functions: ZERO, UNITS, PEAK, *. Offers fast, easy operator training for both production floor and laboratory environments. Its affordable price, rugged all-metal design and interval sampling rate of 1000 samples per second makes the DFM perfect for a wide variety of peak applications. – Internal digital sampling rate of 1000 samples per second. – Tension/compression modes are indicated by “T” for tension or “C” for compression upon force application. – Selectable units of measurement: lb, kg or N. – Display update rate of 8 times per second. – Rechargeable battery with Peak and Low Battery indicator on display. – Continuous AC operation available for 110 VAC or 220 VAC. – Die cast, powder coated metal reversible housing. Split housing design permits upright display whether gauge is hand held or test stand mounted. – Easy to read 1/2″ high LCD display with 4-1/2 digits for forced value. On the display, indicators show units, mode, peak and low battery. – 4 button keypad with separate on/off switch. – Rear mounting hole patterns: (2) #10-32 thread holes for light duty stands
