AGILENT-Hp/Keysight 6644A

Output Ratings

Output voltage: 0 to 60 V
Output current (40° C): 0 to 3.5 A
Maximum current (50° C/55° C): 3.2 A/3 A

Programming Accuracy at 25°C ±5°C

Voltage 0.06% + 26 mV
Current 0.15% + 4.1 mA

Ripple & Noise (20 Hz – 20 MHz)

Voltage rms: 500 µV
Voltage peak-to-peak: 5 mV
Current rms: 1.5 mA

Keysight high performance DC power supplies offer speed and accuracy for test optimization. The single output, 200 W, GPIB 6641A-6645A provide fast, low-noise outputs; analog control of output voltage and current; fan-speed control to minimize acoustic noise; as well as parallel and series connections of multiple units.

The Keysight 210W, GPIB, single output 6644A is a versatile programmable supply designed to maximize test throughput during design verification or on the production line, and is fully programmable to help reduce test time through a variety of automated capabilities.
Datasheet
