Pulse Pattern Generator
AGILENT-Hp/Keysight 81101A
The Keysight 81101A 50 MHz single-channel Pulse Generator is the economy, entry-level instrument of the 81100 family. All timing parameters (repetition rate, delay, width and transitions) are variable.
The instrument comprises a PLL oscillator that enables the repetition rate to be kept within 0.01% accuracy.
Double-pulses and pulse bursts are available. All pulses can be triggered externally when the PLL is turned off. Bursts can also be triggered by the internal PLL if it is not in use as the repetition-rate generator. An external width (pulse recovery) mode is available, too.
The selectable 50/1000 Ohm source resistance allows output amplitudes up to 10 or 20 Vpp respectively into a 50 Ohm load.
Single-channel pulse generator
50 MHz, 10 V from 50 Ohm into 50 Ohm
Triggerable / PLL operation selectable
Pulse / burst modes selectable
Variable transition times
BNC outputs, single-ended
DatasheetSKU: n/a -
Pulse Pattern Generator
TEKTRONIX PG 501
PULSE GENERATOR.
The PG501 provides simultaneous positive and negative 50 MHz output pulses with 5 ns rise and fall times and independently variable amplitudes from 0.5 V to 5 V into 50 Ω.
Front panel controls provide calibrated decade selection of pulse period from 20 ns to 20 ms, and duration from 10 ns to 10 ms. Uncalibrated pulse period from 20 ns to 0.2 s and duration from 10 ns to 0.1 s can be obtained with the variable control.
The PG501 has a gate input and a 10 ns pre-trigger output.SKU: n/a
-
