Oscilloscope 2 channels

70 MHz, 2 ch, 2 GS/s

100 MHz, 2 ch, 2 GS/s

100 MHz, 2 ch, 4 GS/s
The DS4000 series digital oscilloscope is a versatile, high performance oscilloscope that incorporates many of today’s most advanced technologies and processes. Featuring bandwidths between 100MHz and 500MHz, sample rates up to 4GSa/s and up to 4 analog channels, the DS4000 is ideal for a wide variety of markets including communications, defense, aerospace, industrial electronics, R&D and educational fields. – 100 MHz bandwidth – 4 GSa/s sample rate – 2 Analog channels available – 140 million memory points, standard – 110,000 Waveforms per second – Original Ultravision technology – Hardware allows for real-time, continuous waveform recording and waveform analysis

500 MHz, 2MHh, 4GS/s
The DS4000 series digital oscilloscope is a versatile, high performance oscilloscope that incorporates many of today’s most advanced technologies and processes. Featuring bandwidths between 100MHz and 500MHz, sample rates up to 4GSa/s and up to 4 analog channels, the DS4000 is ideal for a wide variety of markets including communications, defense, aerospace, industrial electronics, R&D and educational fields. – 500 MHz bandwidth – 4 GSa/s sample rate – 2 Analog channels available – 140 million memory points, standard – 110,000 Waveforms per second – Original Ultravision technology – Hardware allows for real-time, continuous waveform recording and waveform analysis.

DSO with 600MHz bandwidth and 5GSa/s
The Rigol DS6062 is a very high quality two channel digital storage oscilloscope. It offers up to 5GSa/s real-time sample rate and up to 600MHz bandwidth. These high performances ensure not only to capture real-time instantaneous signal, but also to observe details of repeated signal. DS6062 have up to 120.000 wfms/s refresh rate, which enable users to capture instantaneous signal and abnormal signal more quickly, to enhance waveform capturing ability, and to expedite circuit debug course. The quality of the Rigol Oscilloscopes is comparable to Agilent and Tektronix oscilloscopes. Other advantages: 10.1″ color LCD, bright and vivid waveform display- versatile trigger modes: i.e. slope, alternative, rise&fall edge, enable users to stabilize signal more easily. In economical oscilloscope field, DS6062 have no doubt the highest performances, the most functions thus should be engineers’ best choice. Delivery including 2 probes (bandwidth 600MHz), USB cable, pc software, power adapter and manual. General Data Digital Oscilloscope Digital Oscilloscope Rigol DS6062 Display 10,1″ WVGA-Color-LCD Resolution 800 x 480 Pixel Interface 2x USB-host for i.e. USB sticks USB-Device for a PC connection or USB Pict-Bridge printerinterface LAN for network connectivity (LXI compilant) GPIB (IEE-488, General Purpose Interface Bus) using the optional USB-GPIB Module Trigger- and Calibrationoutput 10MHz reference clock In-/Out VGA interface to connect to an external monitor or projector Size in clarification Weight in clarification Supported operation systems in clarification Oscilloscope Functions Oscilloscope Functions Digital Oscilloscope Rigol DS6062 Channels 2 Real-time sample rate 5 GSa/s realtime Bandwidth 600 MHz Sampling Modus Normal, average, peak detect Mathematics userdefined, FFT (Fast Fourier Transform) FFT algorithm Rectangle, Hanning, Hamming, Blackman Signal Bus Decoding I²C, RS232, SPI, USB, CAN and FlexRay Signal Digital Oscilloscope Rigol DS6062 Input DC/AC coupling, up to 300 Vrms CAT I Real-time sample rate up to 5 GSa/s realtime Time base in clarification Memory 140Mpts (1 Channel) Filter Hardware LPF, HPF, BPF and BRF Vertical Digital Oscilloscope Rigol DS6062 Analog digital converter (A/D) With the resolution of 8 bits, make sampling on both channels synchronously. Sensitivity range (V/div) in clarification Displacement range in clarification Trigger Digital Oscilloscope Rigol DS6062 Trigger in clarification Signal system and line/field frequency (Video triggering mode) in clarification Triggerfunctions Edge, Pattern, Glitch, Puls width, Sequence, Slew rate, I²C, RS232/UART, CAN, FlexRay, USB, SPI, Video Measurement Digital Oscilloscope Rigol DS6062 Cursor measurement Manual, Track and Auto Measure modes Auto measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall time, Positive Width, Negative Width, Positive Duty Cycle, Negative Duty Cycle, Delay1-2 (rise), Delay1-2(fall)

200 MHz, 2 channel, 4 GS/s
MSO4000 Series is the new mainstream digital scope to meet the customer’s applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. – Bandwidth 200MHz – Sample Rate Analog channel up to 4 GSa/s, Digital Channel up to 1 GSa/s(MSO) – Standard Memory depth: Analog channel up to 140 Mpts, Digital Channel up to 28 Mpts(MSO) – 2 Analog Channels, 16 Digital channels(MSO) – Waveform capture rate Up to 110,000 waveforms per second, – Real Time Waveform Record, Replay & Analysis(Std. up to 200,000 frames) – Lower noise floor, the Min. vertical sensitivity is 1mV/div – Innovative “UltraVision” technology – A variety of Trigger functions – Support serial bus trigger(Std.) and decoding(Opt.) for both analog and digital channels – Complete Connectivity: USB Host& Device, LAN(LXI-C), VGA, AUX,USB-GPIB(Opt.) – 9 inch WVGA(800X480), 256 level intensity grading display
