Showing 1–30 of 230 results
-
Oscilloscope 4 channles
RIGOL DHO1204
200 MHz, 4 analog channels and 1 EXT channel, Real-time sample rate up to 2 GSa/s, Memory Depth up to 100 Mpts (optional), 12-bit vertical resolution, Up to 1,500,000 wfms/s waveform capture rate, 10.1'' 1280*800 HD touch display
Analog channel bandwidth: 200 MHz
4 analog channels and 1 EXT channel
12-bit vertical resolution
Real-time sample rate up to 2 GSa/s
Ultra-low noise floor for cleaner signals, measuring small signals accurately
Memory Depth up to 100 Mpts (optional)
Vertical sensitivity range: 500 μV/div to 10 V/div
Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode
10.1'' 1280*800 HD touch display
User-friendly Flex Knobs, bringing smoother interaction
Standard photoelectric encoder operating knobs, effectively prolonging its service life
Standard USB Device & Host, LAN, and HDMI interfacesSKU: n/a€1,699.00 View Product -
-
Signal Generator
RIGOL 821 PRO
1 channel function / arbitrary waveform generator with 25 MHz bandwidth, 625 MSa/s and 2 Mpts（8Mpts opt.) memory,EU Cable
• Max. sample rate: 625 MSa/s
• Max. output frequency: 25 MHz
• 16-bit vertical resolution
• Arbitrary waveform editing function with a max. Arb waveform length of 2 Mpts/CH (8 Mpts/CH
optional)
• Built-in high-order harmonic generator (max. 20th order)
• Independent signal frequency measurement channel with a max. frequency of 500 MHz
• USB and LAN interfaces for remote connection
• Type-C power interface for powering the instrument with mobile power source, satisfying
testing requirements in the field
• Standard Web Control function for easier remote cooperationSKU: n/a€365.00 View Product -
DC Electronic Load
Rigol DL3031
The Rigol DL3031 is a cost-effective programmable DC electronic load max. 150V, 60A, 350W. With USB Host, USB Device and RS232 interface. LAN is available as an option. with performance specifications that rival any instrument in its class. With a user-friendly interface including graphical charting, the DL3000 series provides various interfaces for remote communication to meet your diversified test requirements. Test power systems and batteries with configurable static, transient, and advanced application modes.
SKU: 1298€959.00 View Product -
Digital Multimeter
Rigol DM3068
The Rigol DM3068 is a high quality digital benchtop multimeter from the DM3060 series with a very high sampling rate of up to max. 10 kSa/s. The Rigol multimeter comes with very well designed and easy to use controls which also offer comprehensive ease-of-use functions for all measurement tasks. The menu structure is very intuitive to use. The device helps you obtain precise measurement results in a wide range of applications. The LCD with its 256×64 pixels is highly legible and provides a good overview of the many individual functions. It has a maximum resolution of 6½ digits (maximum display value 2.400.000). Delivery including 2 probes, USB cable, pc software, power cable, 2 replacement fuses and manual. Function Max. Reading 2.400.000 (6½ digits) LCD 90 mm × 25 mm (256x64Pixel) Sampling rate 10 kSa/s Memory Depth (volatile) 512k readings (History) Memory Depth (non volatile) 10 groups of 5000 readings 5 groups of 5000 readings (Sensordata) Connections RS-232, USB Device, USB Host, Ext.Trig., VM Comp, 10/100MBit LAN, GPIB Details Rigol DM3068 Digital Multimeter Power supply 230 V / 50 Hz / 110 V / 60 Hz mains connection Safety standard CAT II/600 V Dimensions 290.5 mm × 231.6 mm × 107.0 mm (11.44″ × 9.12″ × 4.21″) Weight without accessories / packaging 2500 g (5.512 lbs) Weight with accessories / packaging 4465 g (9.844 lbs) Warranty 3 years
6 1/2 digit true RMS precision table multimeterSKU: 185€695.00 View Product -
Power Supply
Rigol DP821A
The Rigol DP821A is a very high quality programmable laboratory power supply with two switchable outputs (60 V/1 A and 8 V/10 A) and a maximum power output of 140 W.
Like all Rigol devices, the power supply features a very well constructed and easy to use interface, which also offers comprehensive ease-of-use functions, such as programmable voltage curves. The menu has an intuitive structure.
The Rigol DP821A features a relative large (8.9 cm / 3.5″) and easy to read TFT color display. In addition to the normal digital displays for voltage, current, and power, these values can also be displayed as signal curves. A timer control can be used to set the output signal to different values in up to 2048 steps.
DatascheetSKU: 739€647.00 View Product -
Oscilloscope 4 channles
Rigol DS1054Z
The DS1000Z Series is the new economic level Digital Oscilloscope from Rigol to meet the customer's applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The DS1000Z 4 channel oscilloscopes come in 70 or 100 MHz versions with a 7 inch display and Rigol's UltraVision technology as well as a host of options. Add the optional analysis, decoding, deep memory, and integrated 2 channel waveform generator for a powerful 4 channel scope at an exceptional price. 50MHz Bandwidth, 4 channels 1G Sa/s Real-time Sample Rate 12Mpts (Std.) and 24Mpts (Opt.) Memory Depth Innovative “UltraVision” technology Up to 30,000wfms/s Waveform Capture Rate 7 Inch WVGA (800×480), multiple intensity levels waveform display
50MHz, 4 channel, 1GS/s
DatasheetSKU: 856€285.00€335.00View Product -
Oscilloscope 2 channels
Rigol DS2102A
100 MHz, standard 50 Ω input, 2 analog channel, 2 GSa/s, Memory depth up to 56 Mpts, Up to 52,000 wfms/s, Up to 65,000 frames hardware real-time waveform record, playback and analysis functions (standard), UltraVision, USB Host&Device, LAN (LXI), AUX, USB-GPIB (optional), 8 inch TFT (800×480) WVGA, Up to 256 levels intensity grading waveform display
Analog channel bandwidth: 100 MHz
2 analog channels
Real-time Sample Rate: analog channel up to 2 GSa/s
Memory Depth: analog channel up to 14 Mpts (standard)/56 Mpts (optional)
Up to 52,000 wfms/s waveform capture rate
Up to 65,000 frames hardware real-time waveform record, playback and
analysis functions (standard)
Innovative “UltraVision” technology
A variety of trigger and bus decoding functions (Parallel, RS232, I2C, SPI, CAN)
Low noise floor, vertical scale range: 1 mV/div to 10 V/div
Complete connectivity: USB Host&Device, LAN (LXI), AUX, USB-GPIB (optional)
Compact size, lightweight, easy to use
8 inch TFT (800×480) WVGA, Up to 256 levels intensity grading waveform displaySKU: 784€569.00 View Product -
Oscilloscope
RIGOL DS7014 DIGITAL OSCILLOSCOPE 100 MHz, 4 CHANNEL
MSO7000/DS7000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL. Integrating 6 independent instruments into one, the MSO7000/DS7000 series is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The MSO7000/DS7000 series digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The MSO7000/DS7000 series offers you a flexible and economical solution to address your actual needs.
SKU: n/a€2,190.00 View Product -
Oscilloscope
RIGOL DS7024 DIGITAL OSCILLOSCOPE 200 MHz, 4 CHANNEL
MSO7000/DS7000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL. Integrating 6 independent instruments into one, the MSO7000/DS7000 series is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The MSO7000/DS7000 series digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The MSO7000/DS7000 series offers you a flexible and economical solution to address your actual needs.
SKU: n/a€2,990.00 View Product -
Spectrum Analyzer
Rigol DSA875
The Rigol DSA875 is a compact and light weight Spectrum Analyzer with premium performance for portable applications. The use of digital IF (intermediate frequency) technology guarantees reliability and performance to meet the most demanding RF applications. The very large display (20.3 cm / 8″) of the Rigol DSA875 Spectrum Analyzer provides a resolution of 800×480 pixels allowing a very good overview of all its comfortable functions like Auto Tune, Auto Range, Auto Scale and Auto Couple. These functions enable the analyzer to acquire signals and match parameters automatically, compared to the manual process necessary with a traditional analyzer. The Rigol Spectrum Analyzers have a sophisticated and easy to use user interface offering multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
DatasheetSKU: 863€5,590.00 View Product -
Oscilloscope 2 channels
RIGOL MSO5102 OSCILLOSCOPE 100 MHz, 2 CHANNEL
The MSO5000 Series Oscilloscopes combine best in class sampling and memory depth with our modern, flexible User Interface enabled by our new UltraVision II architecture and innovative Phoenix Chipset. With 70 to 350 MHz models each with 2 or 4 analog channels, the MSO5000 Series brings innovative flexibility and capability to the engineer’s bench. Analyze your critical signals with zone triggering, 7 instruments in 1, Enhanced FFTs, color grading, and histograms all supported by the high sample rate, deep memory, and full memory measurements.
MSO5000 series digital oscilloscope is a high-performance oscilloscope model designed based on RIGOL UltraVision II technology. With a 9-inch capacitive multi-touch screen, the MSO5000 series integrates 7 independent instruments into one, delivering super sample bandwidth ratio, extremely high memory depth, and other excellent specifications. It is compact and portable in design, and all of the MSO series products support multiple channels, bandwidths, and the upgrade of the analysis software. As it integrates many functions of multiple instruments, different user groups can have more choices in selecting their desired product based on their needs, helping them save their budget to a large extent while enjoying the superior test support and user experience.
SKU: n/a€1,009.00 View Product -
Oscilloscope 4 channles
RIGOL MSO8064
The Rigol MSO8064 is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL.
Integrating 6 independent instruments into one, the Rigol MSO8064 is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today’s inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The Rigol MSO8064 digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The Rigol MSO8064 offers you a flexible and economical solution to address your actual needs.
SKU: n/a€7,190.00 View Product -
Oscilloscope 4 channles
RIGOL MSO8104
The Rigol MSO8104 is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL.
Integrating 6 independent instruments into one, the Rigol MSO8104 is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The Rigol MSO8104 digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The Rigol MSO8104 offers you a flexible and economical solution to address your actual needs.
DatasheetSKU: n/a€8,990.00 View Product -
Logic Probe
RIGOL PLA2216 LOGIC PROBE
The PLA2216 is Logic Probe for MSO5000 Series Oscilloscopes. Includes cable, leads and grabber clips.
Being a high-performance active logic probe, PLA2216 connects the digital signals under test to the MSO5000 series digital oscilloscope to realize the logic analyzer function.
The 16 digital channels (D0-D15) of PLA2216 are divided into two channel groups (D0-D7 and D8-D15) each of which includes signal interfaces and ground interfaces. All the channels are marked with different numbers on the label of the probe input to identify different channels. PLA2216 provides 16 input signal leads and 16 ground leads to realize flexible connection of signals and reference ground.SKU: n/a€299.00 View Product -
Probe
DS1000Z PLUS OSCILLOSCOPE LOGIC PROBE RPL1116
Set of digital logic probes (RPL1116, 16 channel + 16 ground) for the MSO option of the Rigol DS1000Z-Plus series.
Insert it into front logic interface of DS1000Z Plus, then customer can use it. No extra License is needed
User's Guide / Datasheet downloads are available.
Set of digital logic probes (RPL1116, 16 channel + 16 ground) for the MSO option of the Rigol DS1000Z-Plus series.
Insert it into front logic interface of DS1000Z Plus, then customer can use it. No extra License is needed
SKU: n/a€190.00 View Product -
Spectrum Analyzer - Analizzatore di Spettro
RIGOL CK106A
The mechanical calibration set for the VNA of the Rigol RSAxxxxN spectrum analysers. This set is designed for frequencies up to 6.5 GHz.
The set consists of:
-Open load (N male)
-Short load (N male)
-Load (N male)-Through adapter (N female – N female)
SKU: n/a€909.00 View Product -
Spectrum Analyzer - Analizzatore di Spettro
RIGOL CK106E
Accessory for the RSA3000 and RSA5000 “N” series.
High Performance Network Analysis Calibration Kit (Frequency Range: DC to 1.5GHz).
Vector Network Analysis (VNA) requires proper calibration. The CK106A and CK106E models are kits suitable for the Rigol RSA3000 and RSA5000, “N” series real time spectrum analyzers, ie for the models offering this option.
SKU: n/a€319.00 View Product -
Waveform Generator
RIGOL DG1022
The Rigol DG1022 is a 2 channel Function / Arbitrary Waveform Generator to create high quality signals up to 20 MHz (Sine). Beside the two analog outputs, the device includes a 200 MHz frequency counter, an USB-Host- and an USB-device interface.
The Rigol Function-generators have a sophisticated and easy to use interface and offer multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
DatasheetSKU: n/a€269.00 View Product -
Waveform Generator
RIGOL DG1022A
The Rigol DG1022A is a 2 channel Function / Arbitrary Waveform Generator to create high quality signals up to 15 MHz (Sine). Beside the two analog outputs, the device includes a 200 MHz frequency counter, an USB-Host- and an USB-device interface.
The Rigol Function-generators have a sophisticated and easy to use interface and offer multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
DatasheetSKU: n/a€559.00 View Product -
Waveform Generator
Rigol DG1032Z
DG1000Z series function/arbitrary waveform generator is a multi-functional generator that combines many functions in one, including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonics Generator, Analog/Digital Modulator and Counter. As a multi-functional, high performance and portable generator, it will be a new selection in education, R&D, production, test and etc.
– Innovative SiFi (Signal Fidelity): generate arb waveform point-by-point, restore signal distortionless, precisely adjustable sample rate and low jitter (200ps)
– Arbitrary waveform memory: 8Mpts (standard), 16Mpts (optional)
– Standard 2 full functional channels can be used as two independent generators
– ±1ppm frequency stability, -125dBc/Hz phase noise
– Built-in 8 orders harmonics generator – Built-in 7 digits/s full function frequency counter with 200MHz bandwidth
– Up to 160 built-in waveforms
– 200MSa/s sample rate, 14bits vertical resolution
– Convenient arbitrary waveform editing interface – Versatile modulation types: AM, FM, PM, ASK, FSK, PSK and PWM
– Standard waveform summing function
– Standard channel track function – Standard interfaces: USB Host& Device, LAN(LXI Core Device 2011) – 3.5 inches TFT color displaySKU: 740€460.00 View Product -
Waveform Generator
Rigol DG1062Z
DG1000Z series function/arbitrary waveform generator is a multi-functional generator that combines many functions in one, including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonics Generator, Analog/Digital Modulator and Counter. As a multi-functional, high performance and portable generator, it will be a new selection in education, R&D, production, test and etc. – Innovative SiFi (Signal Fidelity): generate arb waveform point-by-point, restore signal distortionless, precisely adjustable sample rate and low jitter (200ps) – Arbitrary waveform memory: 8Mpts (standard), 16Mpts (optional) – Standard 2 full functional channels can be used as two independent generators – ±1ppm frequency stability, -125dBc/Hz phase noise – Built-in 8 orders harmonics generator – Built-in 7 digits/s full function frequency counter with 200MHz bandwidth – Up to 160 built-in waveforms – 200MSa/s sample rate, 14bits vertical resolution – Convenient arbitrary waveform editing interface – Versatile modulation types: AM, FM, PM, ASK, FSK, PSK and PWM – Standard waveform summing function – Standard channel track function – Standard interfaces: USB Host& Device, LAN(LXI Core Device 2011) – 3.5 inches TFT color display
60 MHz, 14 bit, 200 MS/sSKU: 741€590.00 View Product -
Function/Arbitrary Waveform Generator
RIGOL DG2052
ARBITRARY WAVEFORM FUNCTION GENERATOR, 50 MHZ.
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
DatasheetSKU: n/a€530.00 View Product -
Function/Arbitrary Waveform Generator
RIGOL DG2072
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
DatasheetSKU: n/a€720.00 View Product -
Fucntion/Arbitrary Waveform Generatr
RIGOL DG2102
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
DatasheetSKU: n/a€890.00 View Product -
Waveform Generator
RIGOL DG4062
DG4000 series is a multifunctional generator that combines many functions in one, including Function Generator, Arbitrary Waveform Generator, Pulse Generator, Harmonic Generator, Analog/Digital Modulator and Counter. All the models have two channels with complete equivalent functions and precisely adjustable phases.
Maximum output frequency: 200MHz, 160MHz, 100MHz, 60MHz
500MSa/s sample rate, 14 bit vertical resolution
Dual channel outputs with identical performance
2ppm high-frequency stability
-115dBc/Hz low phase noise Versatile analog and digital modulation functions 150 built-in waveforms
7digits/s, 200MHz built-in Counter
Harmonic generator that can generate up to 16th order of harmonic (Std.)
Powerful waveform editing PC software
Connectivity: USB Host & Device, LAN
7 inch LCD display (800 × 480)
DatasheetSKU: 226€739.00€819.00View Product
-
Oscilloscope 4 channles
RIGOL DHO1204
200 MHz, 4 analog channels and 1 EXT channel, Real-time sample rate up to 2 GSa/s, Memory Depth up to 100 Mpts (optional), 12-bit vertical resolution, Up to 1,500,000 wfms/s waveform capture rate, 10.1'' 1280*800 HD touch display
Analog channel bandwidth: 200 MHz
4 analog channels and 1 EXT channel
12-bit vertical resolution
Real-time sample rate up to 2 GSa/s
Ultra-low noise floor for cleaner signals, measuring small signals accurately
Memory Depth up to 100 Mpts (optional)
Vertical sensitivity range: 500 μV/div to 10 V/div
Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode
10.1'' 1280*800 HD touch display
User-friendly Flex Knobs, bringing smoother interaction
Standard photoelectric encoder operating knobs, effectively prolonging its service life
Standard USB Device & Host, LAN, and HDMI interfaces -
-
Signal Generator
RIGOL 821 PRO
1 channel function / arbitrary waveform generator with 25 MHz bandwidth, 625 MSa/s and 2 Mpts（8Mpts opt.) memory,EU Cable
• Max. sample rate: 625 MSa/s
• Max. output frequency: 25 MHz
• 16-bit vertical resolution
• Arbitrary waveform editing function with a max. Arb waveform length of 2 Mpts/CH (8 Mpts/CH
optional)
• Built-in high-order harmonic generator (max. 20th order)
• Independent signal frequency measurement channel with a max. frequency of 500 MHz
• USB and LAN interfaces for remote connection
• Type-C power interface for powering the instrument with mobile power source, satisfying
testing requirements in the field
• Standard Web Control function for easier remote cooperation -
DC Electronic Load
Rigol DL3031
The Rigol DL3031 is a cost-effective programmable DC electronic load max. 150V, 60A, 350W. With USB Host, USB Device and RS232 interface. LAN is available as an option. with performance specifications that rival any instrument in its class. With a user-friendly interface including graphical charting, the DL3000 series provides various interfaces for remote communication to meet your diversified test requirements. Test power systems and batteries with configurable static, transient, and advanced application modes.
-
Digital Multimeter
Rigol DM3068
The Rigol DM3068 is a high quality digital benchtop multimeter from the DM3060 series with a very high sampling rate of up to max. 10 kSa/s. The Rigol multimeter comes with very well designed and easy to use controls which also offer comprehensive ease-of-use functions for all measurement tasks. The menu structure is very intuitive to use. The device helps you obtain precise measurement results in a wide range of applications. The LCD with its 256×64 pixels is highly legible and provides a good overview of the many individual functions. It has a maximum resolution of 6½ digits (maximum display value 2.400.000). Delivery including 2 probes, USB cable, pc software, power cable, 2 replacement fuses and manual. Function Max. Reading 2.400.000 (6½ digits) LCD 90 mm × 25 mm (256x64Pixel) Sampling rate 10 kSa/s Memory Depth (volatile) 512k readings (History) Memory Depth (non volatile) 10 groups of 5000 readings 5 groups of 5000 readings (Sensordata) Connections RS-232, USB Device, USB Host, Ext.Trig., VM Comp, 10/100MBit LAN, GPIB Details Rigol DM3068 Digital Multimeter Power supply 230 V / 50 Hz / 110 V / 60 Hz mains connection Safety standard CAT II/600 V Dimensions 290.5 mm × 231.6 mm × 107.0 mm (11.44″ × 9.12″ × 4.21″) Weight without accessories / packaging 2500 g (5.512 lbs) Weight with accessories / packaging 4465 g (9.844 lbs) Warranty 3 years
6 1/2 digit true RMS precision table multimeter -
Power Supply
Rigol DP821A
The Rigol DP821A is a very high quality programmable laboratory power supply with two switchable outputs (60 V/1 A and 8 V/10 A) and a maximum power output of 140 W.
Like all Rigol devices, the power supply features a very well constructed and easy to use interface, which also offers comprehensive ease-of-use functions, such as programmable voltage curves. The menu has an intuitive structure.
The Rigol DP821A features a relative large (8.9 cm / 3.5″) and easy to read TFT color display. In addition to the normal digital displays for voltage, current, and power, these values can also be displayed as signal curves. A timer control can be used to set the output signal to different values in up to 2048 steps.
Datascheet -
Oscilloscope 4 channles
Rigol DS1054Z
The DS1000Z Series is the new economic level Digital Oscilloscope from Rigol to meet the customer's applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The DS1000Z 4 channel oscilloscopes come in 70 or 100 MHz versions with a 7 inch display and Rigol's UltraVision technology as well as a host of options. Add the optional analysis, decoding, deep memory, and integrated 2 channel waveform generator for a powerful 4 channel scope at an exceptional price. 50MHz Bandwidth, 4 channels 1G Sa/s Real-time Sample Rate 12Mpts (Std.) and 24Mpts (Opt.) Memory Depth Innovative “UltraVision” technology Up to 30,000wfms/s Waveform Capture Rate 7 Inch WVGA (800×480), multiple intensity levels waveform display
50MHz, 4 channel, 1GS/s
Datasheet -
Oscilloscope 2 channels
Rigol DS2102A
100 MHz, standard 50 Ω input, 2 analog channel, 2 GSa/s, Memory depth up to 56 Mpts, Up to 52,000 wfms/s, Up to 65,000 frames hardware real-time waveform record, playback and analysis functions (standard), UltraVision, USB Host&Device, LAN (LXI), AUX, USB-GPIB (optional), 8 inch TFT (800×480) WVGA, Up to 256 levels intensity grading waveform display
Analog channel bandwidth: 100 MHz
2 analog channels
Real-time Sample Rate: analog channel up to 2 GSa/s
Memory Depth: analog channel up to 14 Mpts (standard)/56 Mpts (optional)
Up to 52,000 wfms/s waveform capture rate
Up to 65,000 frames hardware real-time waveform record, playback and
analysis functions (standard)
Innovative “UltraVision” technology
A variety of trigger and bus decoding functions (Parallel, RS232, I2C, SPI, CAN)
Low noise floor, vertical scale range: 1 mV/div to 10 V/div
Complete connectivity: USB Host&Device, LAN (LXI), AUX, USB-GPIB (optional)
Compact size, lightweight, easy to use
8 inch TFT (800×480) WVGA, Up to 256 levels intensity grading waveform display -
Oscilloscope
RIGOL DS7014 DIGITAL OSCILLOSCOPE 100 MHz, 4 CHANNEL
MSO7000/DS7000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL. Integrating 6 independent instruments into one, the MSO7000/DS7000 series is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The MSO7000/DS7000 series digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The MSO7000/DS7000 series offers you a flexible and economical solution to address your actual needs.
-
Oscilloscope
RIGOL DS7024 DIGITAL OSCILLOSCOPE 200 MHz, 4 CHANNEL
MSO7000/DS7000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL. Integrating 6 independent instruments into one, the MSO7000/DS7000 series is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The MSO7000/DS7000 series digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The MSO7000/DS7000 series offers you a flexible and economical solution to address your actual needs.
-
Spectrum Analyzer
Rigol DSA875
The Rigol DSA875 is a compact and light weight Spectrum Analyzer with premium performance for portable applications. The use of digital IF (intermediate frequency) technology guarantees reliability and performance to meet the most demanding RF applications. The very large display (20.3 cm / 8″) of the Rigol DSA875 Spectrum Analyzer provides a resolution of 800×480 pixels allowing a very good overview of all its comfortable functions like Auto Tune, Auto Range, Auto Scale and Auto Couple. These functions enable the analyzer to acquire signals and match parameters automatically, compared to the manual process necessary with a traditional analyzer. The Rigol Spectrum Analyzers have a sophisticated and easy to use user interface offering multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
Datasheet -
Oscilloscope 2 channels
RIGOL MSO5102 OSCILLOSCOPE 100 MHz, 2 CHANNEL
The MSO5000 Series Oscilloscopes combine best in class sampling and memory depth with our modern, flexible User Interface enabled by our new UltraVision II architecture and innovative Phoenix Chipset. With 70 to 350 MHz models each with 2 or 4 analog channels, the MSO5000 Series brings innovative flexibility and capability to the engineer’s bench. Analyze your critical signals with zone triggering, 7 instruments in 1, Enhanced FFTs, color grading, and histograms all supported by the high sample rate, deep memory, and full memory measurements.
MSO5000 series digital oscilloscope is a high-performance oscilloscope model designed based on RIGOL UltraVision II technology. With a 9-inch capacitive multi-touch screen, the MSO5000 series integrates 7 independent instruments into one, delivering super sample bandwidth ratio, extremely high memory depth, and other excellent specifications. It is compact and portable in design, and all of the MSO series products support multiple channels, bandwidths, and the upgrade of the analysis software. As it integrates many functions of multiple instruments, different user groups can have more choices in selecting their desired product based on their needs, helping them save their budget to a large extent while enjoying the superior test support and user experience.
-
Oscilloscope 4 channles
RIGOL MSO8064
The Rigol MSO8064 is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL.
Integrating 6 independent instruments into one, the Rigol MSO8064 is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today’s inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The Rigol MSO8064 digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The Rigol MSO8064 offers you a flexible and economical solution to address your actual needs.
-
Oscilloscope 4 channles
RIGOL MSO8104
The Rigol MSO8104 is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL.
Integrating 6 independent instruments into one, the Rigol MSO8104 is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The Rigol MSO8104 digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The Rigol MSO8104 offers you a flexible and economical solution to address your actual needs.
Datasheet -
Logic Probe
RIGOL PLA2216 LOGIC PROBE
The PLA2216 is Logic Probe for MSO5000 Series Oscilloscopes. Includes cable, leads and grabber clips.
Being a high-performance active logic probe, PLA2216 connects the digital signals under test to the MSO5000 series digital oscilloscope to realize the logic analyzer function.
The 16 digital channels (D0-D15) of PLA2216 are divided into two channel groups (D0-D7 and D8-D15) each of which includes signal interfaces and ground interfaces. All the channels are marked with different numbers on the label of the probe input to identify different channels. PLA2216 provides 16 input signal leads and 16 ground leads to realize flexible connection of signals and reference ground. -
Probe
DS1000Z PLUS OSCILLOSCOPE LOGIC PROBE RPL1116
Set of digital logic probes (RPL1116, 16 channel + 16 ground) for the MSO option of the Rigol DS1000Z-Plus series.
Insert it into front logic interface of DS1000Z Plus, then customer can use it. No extra License is needed
User's Guide / Datasheet downloads are available.
Set of digital logic probes (RPL1116, 16 channel + 16 ground) for the MSO option of the Rigol DS1000Z-Plus series.
Insert it into front logic interface of DS1000Z Plus, then customer can use it. No extra License is needed
-
Spectrum Analyzer - Analizzatore di Spettro
RIGOL CK106A
The mechanical calibration set for the VNA of the Rigol RSAxxxxN spectrum analysers. This set is designed for frequencies up to 6.5 GHz.
The set consists of:
-Open load (N male)
-Short load (N male)
-Load (N male)-Through adapter (N female – N female)
-
Spectrum Analyzer - Analizzatore di Spettro
RIGOL CK106E
Accessory for the RSA3000 and RSA5000 “N” series.
High Performance Network Analysis Calibration Kit (Frequency Range: DC to 1.5GHz).
Vector Network Analysis (VNA) requires proper calibration. The CK106A and CK106E models are kits suitable for the Rigol RSA3000 and RSA5000, “N” series real time spectrum analyzers, ie for the models offering this option.
-
Waveform Generator
RIGOL DG1022
The Rigol DG1022 is a 2 channel Function / Arbitrary Waveform Generator to create high quality signals up to 20 MHz (Sine). Beside the two analog outputs, the device includes a 200 MHz frequency counter, an USB-Host- and an USB-device interface.
The Rigol Function-generators have a sophisticated and easy to use interface and offer multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
Datasheet -
Waveform Generator
RIGOL DG1022A
The Rigol DG1022A is a 2 channel Function / Arbitrary Waveform Generator to create high quality signals up to 15 MHz (Sine). Beside the two analog outputs, the device includes a 200 MHz frequency counter, an USB-Host- and an USB-device interface.
The Rigol Function-generators have a sophisticated and easy to use interface and offer multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
Datasheet -
Waveform Generator
Rigol DG1032Z
DG1000Z series function/arbitrary waveform generator is a multi-functional generator that combines many functions in one, including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonics Generator, Analog/Digital Modulator and Counter. As a multi-functional, high performance and portable generator, it will be a new selection in education, R&D, production, test and etc.
– Innovative SiFi (Signal Fidelity): generate arb waveform point-by-point, restore signal distortionless, precisely adjustable sample rate and low jitter (200ps)
– Arbitrary waveform memory: 8Mpts (standard), 16Mpts (optional)
– Standard 2 full functional channels can be used as two independent generators
– ±1ppm frequency stability, -125dBc/Hz phase noise
– Built-in 8 orders harmonics generator – Built-in 7 digits/s full function frequency counter with 200MHz bandwidth
– Up to 160 built-in waveforms
– 200MSa/s sample rate, 14bits vertical resolution
– Convenient arbitrary waveform editing interface – Versatile modulation types: AM, FM, PM, ASK, FSK, PSK and PWM
– Standard waveform summing function
– Standard channel track function – Standard interfaces: USB Host& Device, LAN(LXI Core Device 2011) – 3.5 inches TFT color display -
Waveform Generator
Rigol DG1062Z
DG1000Z series function/arbitrary waveform generator is a multi-functional generator that combines many functions in one, including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonics Generator, Analog/Digital Modulator and Counter. As a multi-functional, high performance and portable generator, it will be a new selection in education, R&D, production, test and etc. – Innovative SiFi (Signal Fidelity): generate arb waveform point-by-point, restore signal distortionless, precisely adjustable sample rate and low jitter (200ps) – Arbitrary waveform memory: 8Mpts (standard), 16Mpts (optional) – Standard 2 full functional channels can be used as two independent generators – ±1ppm frequency stability, -125dBc/Hz phase noise – Built-in 8 orders harmonics generator – Built-in 7 digits/s full function frequency counter with 200MHz bandwidth – Up to 160 built-in waveforms – 200MSa/s sample rate, 14bits vertical resolution – Convenient arbitrary waveform editing interface – Versatile modulation types: AM, FM, PM, ASK, FSK, PSK and PWM – Standard waveform summing function – Standard channel track function – Standard interfaces: USB Host& Device, LAN(LXI Core Device 2011) – 3.5 inches TFT color display
60 MHz, 14 bit, 200 MS/s -
Function/Arbitrary Waveform Generator
RIGOL DG2052
ARBITRARY WAVEFORM FUNCTION GENERATOR, 50 MHZ.
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
Datasheet -
Function/Arbitrary Waveform Generator
RIGOL DG2072
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
Datasheet -
Fucntion/Arbitrary Waveform Generatr
RIGOL DG2102
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
Datasheet -
Waveform Generator
RIGOL DG4062
DG4000 series is a multifunctional generator that combines many functions in one, including Function Generator, Arbitrary Waveform Generator, Pulse Generator, Harmonic Generator, Analog/Digital Modulator and Counter. All the models have two channels with complete equivalent functions and precisely adjustable phases.
Maximum output frequency: 200MHz, 160MHz, 100MHz, 60MHz
500MSa/s sample rate, 14 bit vertical resolution
Dual channel outputs with identical performance
2ppm high-frequency stability
-115dBc/Hz low phase noise Versatile analog and digital modulation functions 150 built-in waveforms
7digits/s, 200MHz built-in Counter
Harmonic generator that can generate up to 16th order of harmonic (Std.)
Powerful waveform editing PC software
Connectivity: USB Host & Device, LAN
7 inch LCD display (800 × 480)
Datasheet
-
Oscilloscope 4 channles
RIGOL DHO1204
200 MHz, 4 analog channels and 1 EXT channel, Real-time sample rate up to 2 GSa/s, Memory Depth up to 100 Mpts (optional), 12-bit vertical resolution, Up to 1,500,000 wfms/s waveform capture rate, 10.1'' 1280*800 HD touch display
Analog channel bandwidth: 200 MHz
4 analog channels and 1 EXT channel
12-bit vertical resolution
Real-time sample rate up to 2 GSa/s
Ultra-low noise floor for cleaner signals, measuring small signals accurately
Memory Depth up to 100 Mpts (optional)
Vertical sensitivity range: 500 μV/div to 10 V/div
Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode
10.1'' 1280*800 HD touch display
User-friendly Flex Knobs, bringing smoother interaction
Standard photoelectric encoder operating knobs, effectively prolonging its service life
Standard USB Device & Host, LAN, and HDMI interfaces€1,699.00 View Product -
€3,295.00 View Product
-
Signal Generator
RIGOL 821 PRO
1 channel function / arbitrary waveform generator with 25 MHz bandwidth, 625 MSa/s and 2 Mpts（8Mpts opt.) memory,EU Cable
• Max. sample rate: 625 MSa/s
• Max. output frequency: 25 MHz
• 16-bit vertical resolution
• Arbitrary waveform editing function with a max. Arb waveform length of 2 Mpts/CH (8 Mpts/CH
optional)
• Built-in high-order harmonic generator (max. 20th order)
• Independent signal frequency measurement channel with a max. frequency of 500 MHz
• USB and LAN interfaces for remote connection
• Type-C power interface for powering the instrument with mobile power source, satisfying
testing requirements in the field
• Standard Web Control function for easier remote cooperation€365.00 View Product -
DC Electronic Load
Rigol DL3031
The Rigol DL3031 is a cost-effective programmable DC electronic load max. 150V, 60A, 350W. With USB Host, USB Device and RS232 interface. LAN is available as an option. with performance specifications that rival any instrument in its class. With a user-friendly interface including graphical charting, the DL3000 series provides various interfaces for remote communication to meet your diversified test requirements. Test power systems and batteries with configurable static, transient, and advanced application modes.
€959.00 View Product -
Digital Multimeter
Rigol DM3068
The Rigol DM3068 is a high quality digital benchtop multimeter from the DM3060 series with a very high sampling rate of up to max. 10 kSa/s. The Rigol multimeter comes with very well designed and easy to use controls which also offer comprehensive ease-of-use functions for all measurement tasks. The menu structure is very intuitive to use. The device helps you obtain precise measurement results in a wide range of applications. The LCD with its 256×64 pixels is highly legible and provides a good overview of the many individual functions. It has a maximum resolution of 6½ digits (maximum display value 2.400.000). Delivery including 2 probes, USB cable, pc software, power cable, 2 replacement fuses and manual. Function Max. Reading 2.400.000 (6½ digits) LCD 90 mm × 25 mm (256x64Pixel) Sampling rate 10 kSa/s Memory Depth (volatile) 512k readings (History) Memory Depth (non volatile) 10 groups of 5000 readings 5 groups of 5000 readings (Sensordata) Connections RS-232, USB Device, USB Host, Ext.Trig., VM Comp, 10/100MBit LAN, GPIB Details Rigol DM3068 Digital Multimeter Power supply 230 V / 50 Hz / 110 V / 60 Hz mains connection Safety standard CAT II/600 V Dimensions 290.5 mm × 231.6 mm × 107.0 mm (11.44″ × 9.12″ × 4.21″) Weight without accessories / packaging 2500 g (5.512 lbs) Weight with accessories / packaging 4465 g (9.844 lbs) Warranty 3 years
6 1/2 digit true RMS precision table multimeter€695.00 View Product -
Power Supply
Rigol DP821A
The Rigol DP821A is a very high quality programmable laboratory power supply with two switchable outputs (60 V/1 A and 8 V/10 A) and a maximum power output of 140 W.
Like all Rigol devices, the power supply features a very well constructed and easy to use interface, which also offers comprehensive ease-of-use functions, such as programmable voltage curves. The menu has an intuitive structure.
The Rigol DP821A features a relative large (8.9 cm / 3.5″) and easy to read TFT color display. In addition to the normal digital displays for voltage, current, and power, these values can also be displayed as signal curves. A timer control can be used to set the output signal to different values in up to 2048 steps.
Datascheet€647.00 View Product -
Oscilloscope 4 channles
Rigol DS1054Z
The DS1000Z Series is the new economic level Digital Oscilloscope from Rigol to meet the customer's applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The DS1000Z 4 channel oscilloscopes come in 70 or 100 MHz versions with a 7 inch display and Rigol's UltraVision technology as well as a host of options. Add the optional analysis, decoding, deep memory, and integrated 2 channel waveform generator for a powerful 4 channel scope at an exceptional price. 50MHz Bandwidth, 4 channels 1G Sa/s Real-time Sample Rate 12Mpts (Std.) and 24Mpts (Opt.) Memory Depth Innovative “UltraVision” technology Up to 30,000wfms/s Waveform Capture Rate 7 Inch WVGA (800×480), multiple intensity levels waveform display
50MHz, 4 channel, 1GS/s
Datasheet€285.00€335.00View Product -
Oscilloscope 2 channels
Rigol DS2102A
100 MHz, standard 50 Ω input, 2 analog channel, 2 GSa/s, Memory depth up to 56 Mpts, Up to 52,000 wfms/s, Up to 65,000 frames hardware real-time waveform record, playback and analysis functions (standard), UltraVision, USB Host&Device, LAN (LXI), AUX, USB-GPIB (optional), 8 inch TFT (800×480) WVGA, Up to 256 levels intensity grading waveform display
Analog channel bandwidth: 100 MHz
2 analog channels
Real-time Sample Rate: analog channel up to 2 GSa/s
Memory Depth: analog channel up to 14 Mpts (standard)/56 Mpts (optional)
Up to 52,000 wfms/s waveform capture rate
Up to 65,000 frames hardware real-time waveform record, playback and
analysis functions (standard)
Innovative “UltraVision” technology
A variety of trigger and bus decoding functions (Parallel, RS232, I2C, SPI, CAN)
Low noise floor, vertical scale range: 1 mV/div to 10 V/div
Complete connectivity: USB Host&Device, LAN (LXI), AUX, USB-GPIB (optional)
Compact size, lightweight, easy to use
8 inch TFT (800×480) WVGA, Up to 256 levels intensity grading waveform display€569.00 View Product -
Oscilloscope
RIGOL DS7014 DIGITAL OSCILLOSCOPE 100 MHz, 4 CHANNEL
MSO7000/DS7000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL. Integrating 6 independent instruments into one, the MSO7000/DS7000 series is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The MSO7000/DS7000 series digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The MSO7000/DS7000 series offers you a flexible and economical solution to address your actual needs.
€2,190.00 View Product -
Oscilloscope
RIGOL DS7024 DIGITAL OSCILLOSCOPE 200 MHz, 4 CHANNEL
MSO7000/DS7000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL. Integrating 6 independent instruments into one, the MSO7000/DS7000 series is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The MSO7000/DS7000 series digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The MSO7000/DS7000 series offers you a flexible and economical solution to address your actual needs.
€2,990.00 View Product -
Spectrum Analyzer
Rigol DSA875
The Rigol DSA875 is a compact and light weight Spectrum Analyzer with premium performance for portable applications. The use of digital IF (intermediate frequency) technology guarantees reliability and performance to meet the most demanding RF applications. The very large display (20.3 cm / 8″) of the Rigol DSA875 Spectrum Analyzer provides a resolution of 800×480 pixels allowing a very good overview of all its comfortable functions like Auto Tune, Auto Range, Auto Scale and Auto Couple. These functions enable the analyzer to acquire signals and match parameters automatically, compared to the manual process necessary with a traditional analyzer. The Rigol Spectrum Analyzers have a sophisticated and easy to use user interface offering multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
Datasheet€5,590.00 View Product -
Oscilloscope 2 channels
RIGOL MSO5102 OSCILLOSCOPE 100 MHz, 2 CHANNEL
The MSO5000 Series Oscilloscopes combine best in class sampling and memory depth with our modern, flexible User Interface enabled by our new UltraVision II architecture and innovative Phoenix Chipset. With 70 to 350 MHz models each with 2 or 4 analog channels, the MSO5000 Series brings innovative flexibility and capability to the engineer’s bench. Analyze your critical signals with zone triggering, 7 instruments in 1, Enhanced FFTs, color grading, and histograms all supported by the high sample rate, deep memory, and full memory measurements.
MSO5000 series digital oscilloscope is a high-performance oscilloscope model designed based on RIGOL UltraVision II technology. With a 9-inch capacitive multi-touch screen, the MSO5000 series integrates 7 independent instruments into one, delivering super sample bandwidth ratio, extremely high memory depth, and other excellent specifications. It is compact and portable in design, and all of the MSO series products support multiple channels, bandwidths, and the upgrade of the analysis software. As it integrates many functions of multiple instruments, different user groups can have more choices in selecting their desired product based on their needs, helping them save their budget to a large extent while enjoying the superior test support and user experience.
€1,009.00 View Product -
Oscilloscope 4 channles
RIGOL MSO8064
The Rigol MSO8064 is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL.
Integrating 6 independent instruments into one, the Rigol MSO8064 is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today’s inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The Rigol MSO8064 digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The Rigol MSO8064 offers you a flexible and economical solution to address your actual needs.
€7,190.00 View Product -
Oscilloscope 4 channles
RIGOL MSO8104
The Rigol MSO8104 is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL.
Integrating 6 independent instruments into one, the Rigol MSO8104 is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The Rigol MSO8104 digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The Rigol MSO8104 offers you a flexible and economical solution to address your actual needs.
Datasheet€8,990.00 View Product -
Logic Probe
RIGOL PLA2216 LOGIC PROBE
The PLA2216 is Logic Probe for MSO5000 Series Oscilloscopes. Includes cable, leads and grabber clips.
Being a high-performance active logic probe, PLA2216 connects the digital signals under test to the MSO5000 series digital oscilloscope to realize the logic analyzer function.
The 16 digital channels (D0-D15) of PLA2216 are divided into two channel groups (D0-D7 and D8-D15) each of which includes signal interfaces and ground interfaces. All the channels are marked with different numbers on the label of the probe input to identify different channels. PLA2216 provides 16 input signal leads and 16 ground leads to realize flexible connection of signals and reference ground.€299.00 View Product -
Probe
DS1000Z PLUS OSCILLOSCOPE LOGIC PROBE RPL1116
Set of digital logic probes (RPL1116, 16 channel + 16 ground) for the MSO option of the Rigol DS1000Z-Plus series.
Insert it into front logic interface of DS1000Z Plus, then customer can use it. No extra License is needed
User's Guide / Datasheet downloads are available.
Set of digital logic probes (RPL1116, 16 channel + 16 ground) for the MSO option of the Rigol DS1000Z-Plus series.
Insert it into front logic interface of DS1000Z Plus, then customer can use it. No extra License is needed
€190.00 View Product -
Spectrum Analyzer - Analizzatore di Spettro
RIGOL CK106A
The mechanical calibration set for the VNA of the Rigol RSAxxxxN spectrum analysers. This set is designed for frequencies up to 6.5 GHz.
The set consists of:
-Open load (N male)
-Short load (N male)
-Load (N male)-Through adapter (N female – N female)
€909.00 View Product -
Spectrum Analyzer - Analizzatore di Spettro
RIGOL CK106E
Accessory for the RSA3000 and RSA5000 “N” series.
High Performance Network Analysis Calibration Kit (Frequency Range: DC to 1.5GHz).
Vector Network Analysis (VNA) requires proper calibration. The CK106A and CK106E models are kits suitable for the Rigol RSA3000 and RSA5000, “N” series real time spectrum analyzers, ie for the models offering this option.
€319.00 View Product -
Waveform Generator
RIGOL DG1022
The Rigol DG1022 is a 2 channel Function / Arbitrary Waveform Generator to create high quality signals up to 20 MHz (Sine). Beside the two analog outputs, the device includes a 200 MHz frequency counter, an USB-Host- and an USB-device interface.
The Rigol Function-generators have a sophisticated and easy to use interface and offer multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
Datasheet€269.00 View Product -
Waveform Generator
RIGOL DG1022A
The Rigol DG1022A is a 2 channel Function / Arbitrary Waveform Generator to create high quality signals up to 15 MHz (Sine). Beside the two analog outputs, the device includes a 200 MHz frequency counter, an USB-Host- and an USB-device interface.
The Rigol Function-generators have a sophisticated and easy to use interface and offer multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
Datasheet€559.00 View Product -
Waveform Generator
Rigol DG1032Z
DG1000Z series function/arbitrary waveform generator is a multi-functional generator that combines many functions in one, including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonics Generator, Analog/Digital Modulator and Counter. As a multi-functional, high performance and portable generator, it will be a new selection in education, R&D, production, test and etc.
– Innovative SiFi (Signal Fidelity): generate arb waveform point-by-point, restore signal distortionless, precisely adjustable sample rate and low jitter (200ps)
– Arbitrary waveform memory: 8Mpts (standard), 16Mpts (optional)
– Standard 2 full functional channels can be used as two independent generators
– ±1ppm frequency stability, -125dBc/Hz phase noise
– Built-in 8 orders harmonics generator – Built-in 7 digits/s full function frequency counter with 200MHz bandwidth
– Up to 160 built-in waveforms
– 200MSa/s sample rate, 14bits vertical resolution
– Convenient arbitrary waveform editing interface – Versatile modulation types: AM, FM, PM, ASK, FSK, PSK and PWM
– Standard waveform summing function
– Standard channel track function – Standard interfaces: USB Host& Device, LAN(LXI Core Device 2011) – 3.5 inches TFT color display€460.00 View Product -
Waveform Generator
Rigol DG1062Z
DG1000Z series function/arbitrary waveform generator is a multi-functional generator that combines many functions in one, including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonics Generator, Analog/Digital Modulator and Counter. As a multi-functional, high performance and portable generator, it will be a new selection in education, R&D, production, test and etc. – Innovative SiFi (Signal Fidelity): generate arb waveform point-by-point, restore signal distortionless, precisely adjustable sample rate and low jitter (200ps) – Arbitrary waveform memory: 8Mpts (standard), 16Mpts (optional) – Standard 2 full functional channels can be used as two independent generators – ±1ppm frequency stability, -125dBc/Hz phase noise – Built-in 8 orders harmonics generator – Built-in 7 digits/s full function frequency counter with 200MHz bandwidth – Up to 160 built-in waveforms – 200MSa/s sample rate, 14bits vertical resolution – Convenient arbitrary waveform editing interface – Versatile modulation types: AM, FM, PM, ASK, FSK, PSK and PWM – Standard waveform summing function – Standard channel track function – Standard interfaces: USB Host& Device, LAN(LXI Core Device 2011) – 3.5 inches TFT color display
60 MHz, 14 bit, 200 MS/s€590.00 View Product -
Function/Arbitrary Waveform Generator
RIGOL DG2052
ARBITRARY WAVEFORM FUNCTION GENERATOR, 50 MHZ.
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
Datasheet€530.00 View Product -
Function/Arbitrary Waveform Generator
RIGOL DG2072
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
Datasheet€720.00 View Product -
Fucntion/Arbitrary Waveform Generatr
RIGOL DG2102
Engineers who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG2000 Series generators. With frequencies up to 100 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG2000 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market. The hybrid touch interface and industrial design make it the perfect choice for your lab while standard Ethernet and USB make it the choice for engineers who need to programmatically control their instrument.
* Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
* 16 Mpts memory depth per channel for arbitrary waveforms
* Standard dual-channel with the same performance, equivalent to two independent signal sources * High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
* Built-in high-order harmonic generator (at most 8-order harmonics)
* Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
* Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
* Sample rate up to 250 MSa/s, vertical resolution 16 bits
* Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
* Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
* Standard waveform combine function, capable of outputting specifi ed waveforms combined with the basic waveforms
* Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
* Standard interface: USB Host&Device and LAN (LXI Core 2011 Device); USB-GPIB function supported
* 4.3'' TFT color touch screen
* RS232, PRBS, and Dual-tone outputs supported
Datasheet€890.00 View Product -
Waveform Generator
RIGOL DG4062
DG4000 series is a multifunctional generator that combines many functions in one, including Function Generator, Arbitrary Waveform Generator, Pulse Generator, Harmonic Generator, Analog/Digital Modulator and Counter. All the models have two channels with complete equivalent functions and precisely adjustable phases.
Maximum output frequency: 200MHz, 160MHz, 100MHz, 60MHz
500MSa/s sample rate, 14 bit vertical resolution
Dual channel outputs with identical performance
2ppm high-frequency stability
-115dBc/Hz low phase noise Versatile analog and digital modulation functions 150 built-in waveforms
7digits/s, 200MHz built-in Counter
Harmonic generator that can generate up to 16th order of harmonic (Std.)
Powerful waveform editing PC software
Connectivity: USB Host & Device, LAN
7 inch LCD display (800 × 480)
Datasheet€739.00€819.00View Product
