Power Supply

Output Ratings

Output voltage: 0 to 60 V
Output current (40° C): 0 to 3.5 A
Maximum current (50° C/55° C): 3.2 A/3 A

Programming Accuracy at 25°C ±5°C

Voltage 0.06% + 26 mV
Current 0.15% + 4.1 mA

Ripple & Noise (20 Hz – 20 MHz)

Voltage rms: 500 µV
Voltage peak-to-peak: 5 mV
Current rms: 1.5 mA

Keysight high performance DC power supplies offer speed and accuracy for test optimization. The single output, 200 W, GPIB 6641A-6645A provide fast, low-noise outputs; analog control of output voltage and current; fan-speed control to minimize acoustic noise; as well as parallel and series connections of multiple units.

Keysight high performance DC power supplies offer speed and accuracy for test optimization. The single output, 500W GPIB 665x series provide fast, low-noise outputs; analog control of output voltage and current; and fan-speed control to minimize acoustic noise.

The Keysight 540W, single output 6654A is a fast and flexible power supply or automated testing, and is designed to increase test throughput with fast up- and downprogramm.

Output Ratings

Output voltage: 0 to 80 V
Output current (40°C): 0 to 6 A
Maximum current (50°C/55°C): 8.1 A/7.7 A

Programming Accuracy at 25°C ±5°C

Voltage 0.06% + 26 mV
Current 0.15% + 8 mA

Ripple & Noise from 20 Hz to 20 MHz
