Showing 1–30 of 34 results
-
ADAPTOR
SUHNER 33_N-SMA-50-1/113 UE 22542421 RF/Coaxial Adaptor, Straight Adapter
The 33_N-SMA-50-1/113_UE is a RF/coaxial Straight Adapter with N-type plug to SMA jack connection. The N-type plug has PFA/PTFE insulator, gold-plated copper beryllium alloy body and a centre contact. The SMA jack has PFA/PTFE insulator, gold-plated copper beryllium alloy body and a centre contact.
* 50 Ω Impedance
* -65 to 165°C Operating temperature range
* frequency max. 18 GHz
* VSWR DC – 12.4 GHz ≤ 1.05 + 0.015 f (GHz)
SKU: n/a -
ADAPTOR
HUBER + SUHNER 33PC35-50-01-1/199 NE ADAPTOR PLUG/JACK 22644362
The HUBER + SUHNER 33PC35-50-01-1/199 NE is a Adaptor plug/jack PC 3.5 plug (male) / PC 3.5 jack (female).
It used for test and measurement applications precision adaptor* Interface 1: PC 3.5 plug (male)
* Interface 2: PC 3.5 jack (female)
* Impedance: 50 Ω
* Interface freq. Max: 33 GHz
* Frequency Range 1: 0 GHz to 18 GHz
* Frequency Range 2: 18 GHz to 26.5 GHz
* Return loss band 1: 28 dB
* Return loss band 2: 23 dB
* BATCH Nr 02.26942
* Manufacture code: 22644362
DatasheetSKU: n/a€50.00 View Product -
Cable
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – 1200mm
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – 1200mm SMA M- SMA M
The ENVIROFLEX 400 cable is suitable for a frequency range up to 6 GHz.
The RF line is flexible and recommended for wireless communication and HF applications.The Enviroflex cable family enables users to quickly switch from fluorine-containing cables to halogen-free alternatives. The materials used in the cable design – both for the dielectric and for the jacket – do not
include any fluorine-consisting plastics. The dimensions of the individual cable types are entirely compatible with the international RG standards. Standard connectors can be used without any restrictions with the Enviroflex cable family. HUBER+SUHNER´s control of various key technologies has proven to be an invaluable advantage.
DatasheetSKU: n/a -
Cable
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – 2m
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – COLOR BLACK SMA M- SMA M 2m
e ENVIROFLEX 400 cable is suitable for a frequency range up to 6 GHz.
The RF line is flexible and recommended for wireless communication and HF applications.
The Enviroflex cable family enables users to quickly switch from fluorine-containing cables to halogen-free alternatives. The materials used in the cable design – both for the dielectric and for the jacket – do not
include any fluorine-consisting plastics. The dimensions of the individual cable types are entirely compatible with the international RG standards. Standard connectors can be used without any restrictions with the Enviroflex cable family. HUBER+SUHNER´s control of various key technologies has proven to be an invaluable advantage.
DatasheetSKU: n/a
-
ADAPTOR
SUHNER 33_N-SMA-50-1/113 UE 22542421 RF/Coaxial Adaptor, Straight Adapter
The 33_N-SMA-50-1/113_UE is a RF/coaxial Straight Adapter with N-type plug to SMA jack connection. The N-type plug has PFA/PTFE insulator, gold-plated copper beryllium alloy body and a centre contact. The SMA jack has PFA/PTFE insulator, gold-plated copper beryllium alloy body and a centre contact.
* 50 Ω Impedance
* -65 to 165°C Operating temperature range
* frequency max. 18 GHz
* VSWR DC – 12.4 GHz ≤ 1.05 + 0.015 f (GHz)
-
ADAPTOR
HUBER + SUHNER 33PC35-50-01-1/199 NE ADAPTOR PLUG/JACK 22644362
The HUBER + SUHNER 33PC35-50-01-1/199 NE is a Adaptor plug/jack PC 3.5 plug (male) / PC 3.5 jack (female).
It used for test and measurement applications precision adaptor* Interface 1: PC 3.5 plug (male)
* Interface 2: PC 3.5 jack (female)
* Impedance: 50 Ω
* Interface freq. Max: 33 GHz
* Frequency Range 1: 0 GHz to 18 GHz
* Frequency Range 2: 18 GHz to 26.5 GHz
* Return loss band 1: 28 dB
* Return loss band 2: 23 dB
* BATCH Nr 02.26942
* Manufacture code: 22644362
Datasheet -
Cable
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – 1200mm
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – 1200mm SMA M- SMA M
The ENVIROFLEX 400 cable is suitable for a frequency range up to 6 GHz.
The RF line is flexible and recommended for wireless communication and HF applications.The Enviroflex cable family enables users to quickly switch from fluorine-containing cables to halogen-free alternatives. The materials used in the cable design – both for the dielectric and for the jacket – do not
include any fluorine-consisting plastics. The dimensions of the individual cable types are entirely compatible with the international RG standards. Standard connectors can be used without any restrictions with the Enviroflex cable family. HUBER+SUHNER´s control of various key technologies has proven to be an invaluable advantage.
Datasheet -
Cable
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – 2m
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – COLOR BLACK SMA M- SMA M 2m
e ENVIROFLEX 400 cable is suitable for a frequency range up to 6 GHz.
The RF line is flexible and recommended for wireless communication and HF applications.
The Enviroflex cable family enables users to quickly switch from fluorine-containing cables to halogen-free alternatives. The materials used in the cable design – both for the dielectric and for the jacket – do not
include any fluorine-consisting plastics. The dimensions of the individual cable types are entirely compatible with the international RG standards. Standard connectors can be used without any restrictions with the Enviroflex cable family. HUBER+SUHNER´s control of various key technologies has proven to be an invaluable advantage.
Datasheet
-
ADAPTOR
SUHNER 33_N-SMA-50-1/113 UE 22542421 RF/Coaxial Adaptor, Straight Adapter
The 33_N-SMA-50-1/113_UE is a RF/coaxial Straight Adapter with N-type plug to SMA jack connection. The N-type plug has PFA/PTFE insulator, gold-plated copper beryllium alloy body and a centre contact. The SMA jack has PFA/PTFE insulator, gold-plated copper beryllium alloy body and a centre contact.
* 50 Ω Impedance
* -65 to 165°C Operating temperature range
* frequency max. 18 GHz
* VSWR DC – 12.4 GHz ≤ 1.05 + 0.015 f (GHz)
-
ADAPTOR
HUBER + SUHNER 33PC35-50-01-1/199 NE ADAPTOR PLUG/JACK 22644362
The HUBER + SUHNER 33PC35-50-01-1/199 NE is a Adaptor plug/jack PC 3.5 plug (male) / PC 3.5 jack (female).
It used for test and measurement applications precision adaptor* Interface 1: PC 3.5 plug (male)
* Interface 2: PC 3.5 jack (female)
* Impedance: 50 Ω
* Interface freq. Max: 33 GHz
* Frequency Range 1: 0 GHz to 18 GHz
* Frequency Range 2: 18 GHz to 26.5 GHz
* Return loss band 1: 28 dB
* Return loss band 2: 23 dB
* BATCH Nr 02.26942
* Manufacture code: 22644362
Datasheet€50.00 View Product -
Cable
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – 1200mm
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – 1200mm SMA M- SMA M
The ENVIROFLEX 400 cable is suitable for a frequency range up to 6 GHz.
The RF line is flexible and recommended for wireless communication and HF applications.The Enviroflex cable family enables users to quickly switch from fluorine-containing cables to halogen-free alternatives. The materials used in the cable design – both for the dielectric and for the jacket – do not
include any fluorine-consisting plastics. The dimensions of the individual cable types are entirely compatible with the international RG standards. Standard connectors can be used without any restrictions with the Enviroflex cable family. HUBER+SUHNER´s control of various key technologies has proven to be an invaluable advantage.
Datasheet -
Cable
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – 2m
HUBER+SUHNER ENVIROFLEX 400 COAXIAL CABLE – COLOR BLACK SMA M- SMA M 2m
e ENVIROFLEX 400 cable is suitable for a frequency range up to 6 GHz.
The RF line is flexible and recommended for wireless communication and HF applications.
The Enviroflex cable family enables users to quickly switch from fluorine-containing cables to halogen-free alternatives. The materials used in the cable design – both for the dielectric and for the jacket – do not
include any fluorine-consisting plastics. The dimensions of the individual cable types are entirely compatible with the international RG standards. Standard connectors can be used without any restrictions with the Enviroflex cable family. HUBER+SUHNER´s control of various key technologies has proven to be an invaluable advantage.
Datasheet
