Showing 91–120 of 455 results
-
Digital Multimeter
HP-Agilent/Keysight 3458A
-8 ½ digits with 10 nV DC resolution -8-ppm 1 year dcV accuracy, optional 4-ppm -0.05 ppm dcV transfer accuracy -100,000 readings per second at 4 ½ digits -2- and 4-wire ohms measurements with offset compensation -Superior AC voltage measurements
- DISPONIBILE A STOCK
8½ Digit
SKU: 92 -
NOISE SOURCE
HP-AGILENT/KEYSIGHT 346C
HP 346C Noise Source, 10 MHz to 26.5 GHz, nominal ENR 15 dB
The HP 346C noise source is the ideal companion to Keysight's noise figure solutions. Since it is broadband (10 MHz to 26.5 GHz), it eliminates the necessity for several sources at different frequency bands. The low SWR of the noise source reduces a major source of measurement uncertainty; reflections of test signals. Option K01 is a coaxial noise source and features coverage from 1 to 50 GHz with a 2.4 mm coaxial connector.
• Frequency range: 10 MHz to 26.5 GHz
• VSWR: < 1.35:1 • Connectors: BNC (f) input bias / 3.5 mm (m) • Low SWR for reducing noise figure measurement uncertainty • Individually calibrated ENR values at specific frequencies DatasheetSKU: 75 -
Module
HP-Agilent/Keysight 34905A
The HP 34905A RF multiplexer module for the 34970A/34972A Data Acquisition/Switch Unit offers broadband switching capabilities for high-frequency and pulsed signals. Use it to route test signals between your device under test and your signal generator, oscilloscope, spectrum analyzer, or other instrumentation.
The RF multiplexers are arranged as two independent 1 x 4 multiplexers, each with a common shield and a switched center conductor. Connections can be made directly to SMB inputs with 2 GHz usable bandwidth, or to the BNC-to-SMB adapters provided with 1 GHz bandwidth. Multiple banks may be cascaded together for applications requiring even larger topologies– create a stubless 16:1 multiplexer in a single frame.
Key Features & Specifications:
– Dual 4 Channel RF Multiplexer
– 2 GHz bandwidth, 50 Ohm
– Cascade together for up to 16:1 multiplexerSKU: 1143 -
Module
HP-Agilent/Keysight 34906A
The HP 34906A RF multiplexer module for the 34970A/34972A Data Acquisition/Switch Unit offers broadband switching capabilities for high-frequency and pulsed signals. Use it to route test signals between your device under test and your signal generator, oscilloscope, spectrum analyzer, or other instrumentation. The RF multiplexers are arranged as two independent 1 x 4 multiplexers, each with a common shield and a switched center conductor. Connections can be made directly to SMB inputs with 2 GHz usable bandwidth, or to the BNC-to-SMB adapters provided with 1 bandwidth. Multiple banks may be cascaded together for applications requiring even larger topologies–create a stubless 16:1 multiplexer in a single frame.
Key Features & Specifications:
– Dual 4 Channel RF Multiplexer
– 2 GHz bandwidth, 75 Ohm
– Cascade together for up to 16:1 multiplexer
– BNC to SMB adapter cables includedSKU: 1144 -
40-Channel Armature Multiplexer
HP-Agilent/Keysight 34921A
34921A 40-Channel Armature Multiplexer for 34980A The Keysight 34921A module for the 34980A Multifunction Switch/Measure Unit is the most versatile multiplexer for general purpose scanning. It has low thermal offset characteristics and a built-in thermocouple reference on the terminal block, making it ideal for temperature measurements directly to the internal DMM. The dense, multi-function switching with 100 channel/second scan rates addresses a broad spectrum of data acquisition applications. Four additional fused inputs (44 channels total) route up to 1A of current to the internal DMM, allowing AC and DC current measurements without the need for external shunt resistors. Standard 50-pin Dsub connectors allow for use with standard cables, terminal blocks, or mass interconnect solutions. – 40 2-wire channels – 300V, 1A switch- 2A carry current – 100 ch/s scanning – Mix 2- or 4-wire configurations – Built-in thermocouple reference junction – 4 current channels – Latching armature relays, with relay counter
SKU: 1006 -
Multifunction Switch/Measure Unit
HP-Agilent/Keysight 34980A
The Agilent 34980A is a flexible, reliable switching and data acquisition platform with more than 20 modules to help you customize your test system.
Key Features & Specifications:
– Eight-slot mainframe, choice of 21-plug-in modules 34980A Multifunction Switch/Measure Unit Summary
– Built-in DMM with 6½ digits (22 bits) of resolution
– Scan rates of up to 1000 channels/second
– Standard LAN, USB, and GPIB connectivity to PC, LXI compliant
– Easy remote access with built-in Web interface
– Up to 560 2-wire mux or 4096 matrix cross-points in one mainframeSKU: 1015 -
RF Impedance/Material Analyzer
HP-Agilent/Keysight 4291B
Four component test fixtures (DUT size: 0.5 mm to 20 mm)
Independent parameter selection in 2 channels
Direct read-out permittivity, permeability (option)
Two material fixtures (operating temperature: -55deg C to + 200deg C)
Versatile analysis (temperature, cole-cole plot, relaxation time)
Sweep parameters (frequency, ac level, dc bias, temperature)The Keysight 4291B RF impedance / material analyzer provides a total solution for high-accuracy and easy measurement of surface-mount components and dielectric / magnetic materials. The Keysight 4291B uses a direct current-voltage measurement technique, opposing the reflection measurement technique, for more accurate impedance measurement over wide impedance range.
Basic impedance accuracy is +/- 0.8%. High Q accuracy enables low-loss component analysis. An internal synthesizer sweeps frequency from 1 MHz to 1.8 GHz with 1 mHz resolution. A 1.8-m error-less cable connects the analyzer to a test station so you can extend your test point away from the analyzer without losing accuracy. Advanced calibration and error compensation function eliminate measurement error factors in fixtures and assure high accuracy and repeatability at DUT / MUT.
The Hp 4291B also provides automatic level control and monitor of test signals by using IBASIC programming function; devices can be measured under a constant voltage or current. Measure bias dependent impedance characteristics with optional dc bias (up to 40 V and 100 mA). At the push of a button, the built-in Equivalent Circuit Analysis Function automatically calculates the circuit constant values of five circuit models.
The Hp 4291B has two measurement channels; each channel can be set to measure a single (e.g. Z) or dual (e.g. Z-theta) impedance parameter. The color TFT with split-display can show both active traces and memory traces (stored in RAM). A built-in floppy disk drive stores programs and test data in either LIF or MS-DOS format. With built-in IBASIC, you can control external test equipment such as a temperature chamber or wafer prober directly from the Keysight 4291B. You do not need a separate instrument controller.
Material Evaluation
The Hp 4291B enables easy and sophisticated material evaluation and improves material evaluation quality and efficiency. The Hp 4291B provides the total dielectric / magnetic material measurement solutions in wide frequency range (1 MHz to 1 GHz).
DatasheetSKU: n/a
-
