Showing 61–90 of 538 results
-
RF Plug
HP-Agilent/Keysight 83545A

The HP 83545A was designed to be used in the 8350 Mainframe
This unit is a RF Sweep Oscillator Plug-in offers high performance 5.9 to 12.4GHz frequency coverage with exceptionally high output power.
In addition, the 83545A provides slope compensation and complete HP-IB programmability.
The output power is internally leveled to at least 17 dB, with power variations less that 0.6 dB.SKU: 633 -
Signal Generator
HP-Agilent/Keysight 83650A

The Agilent 83650A synthesized sweeper is the standard of excellence for applications requiring the high performance and accuracy of a synthesized source and the speed and versatility of a sweep oscillator. Synthesized broadband frequency coverage and precise 1 Hz frequency resolution (Opt 008) are generated by indirect synthesis, enabling the Agilent 83650A to achieve low single-sideband phase noise performance. It delivers excellent harmonic performance with harmonics at least 50 dB below the carrier from 2.0 to 26.5 GHz, and at least 40 dB below the carrier above 26.5 GHz.
Features:
Scan modulation to simulate antenna scan patterns
Accurate fixed and swept frequency offset for two-tone measurement
User flatness correction for leveling at remote points in the test system
General purpose source for use in component test, receiver test and for frequency conversion
Sweep Modes: Step, List, Ramp
Maximum Power: +10 dBm 26.5 GHz
Maximum Power: +2.5 dBm >40 GHz
Power Sweep Range: -20 dBm to maximum power
Phase Noise (50 GHz at 10 KHz): -68 dBc
Max FM Deviation (locked): +/- 8 MHz
DatasheetSKU: n/a -
Power Sensor
HP-Agilent/Keysight 8487D

Il sensore di potenza a diodo 8487D misura la potenza media nell'intervallo di frequenza da 50 MHz a 50 GHz e l'intervallo di potenza da -70 a -20 dBm (intervallo dinamico 50 dB).
L'attenuatore Keysight 11708A 30 dB viene fornito con sensori di potenza serie 8480 con il suffisso “D”, per la calibrazione con misuratore di potenza 0 dBm, riferimento 50 MHz.
SWR eccellente per ridurre l'incertezza di mancata corrispondenza
Calibrazione e tracciabilità accurate alla calibrazione del sensore a onde millimetriche del National Institute of Standards and Technology (NIST)
Compatibile con misuratori di potenza EPM (nuovo N1913A / 14A, E4418B / 19B), EPM-P (E4416A / 17A) e serie P (N1911A / 12A), oltre al misuratore di potenza E1416A VXI e fuori produzione 70100A e 43X
Misurazioni di potenza media accurate oltre -70 a -20 dBm
Gamma di frequenza da 50 MHz a 50 GHz
Elemento di rilevamento della potenza del diodo
DatasheetSKU: n/a -
Spectrum Analyzer
HP-Agilent/Keysight 8590B

Features:
9 kHz to 1.8 GHz Frequency Range
Keyboard Entry of Parameters
Amplitude Range: -115 to +30 dBm
50 or 75 Ω Input
Need-Specific Test CapabilitiesThe HP 8590B Spectrum Analyzer offers basic RF and microwave measurement performance at a low cost. The 8590B has a frequency range of 9 kHz to 1.8GHz, a 50- or optional 75- ohm input, and a weight of only 30 pounds. Amplitude range is a wide -115 to +30 dBm. If AC power is not available, the 8590B can be operated using the HP 85901A portable AC power source.
The measurement capabilities of the 8590B can be adjusted to fit specific measurement needs. An optional memory card reader enables the loading of specific measurement personalities for cable television, electromagnetic compatibility, or digital radio applications.
SKU: 472 -
Module
HP-Agilent/Keysight N6731B

Keysight basic modules provide stable output, device protection, and accurate measurements. A single range allows programming voltages and currents from 0 V and 0 A to their maximum voltage and current rating. Use 2-wire local sense or 4-wire remote sense to improve regulation. All modules feature a quick disconnect connector.
Programmable output voltages: 0 to 150 V
Output power: 50 to 300 W
Voltage accuracy: 0.1% + 19 mV (5V output)
Ripple and noise 10 mV (5V output)
Up and down-programming with resistive load typically 20 msOvervoltage, overcurrent, and overtemperature protection
Basic modules are single wide allowing four per mainframe
Modules can operate at lower output power to stay within mainframe rating
Modules include a quick disconnect connector
DatasheetSKU: n/a -
Probe Offset Control and Power Module
HP-Agilent/Keysight 1143A

Keysight’s 1143A probe offset control and power module provides power and independent offset control for the Keysight 54700 Series probes. The probe’s offset is controllable via a nine-pin, D-subminiature connector on the rear panel. The ±50 V offset capability extends the dynamic range of the probe measurement system beyond that of many test and measurement instruments.
The Keysight 54701A active probe with the 1143A probe offset control and power module is versatile to use with any test and measurement equipment with a 50 ohm input.
programmable offset
±50 V offset
number of independently operated probes: 2
positive power output: +17.3 V ±150 mV
negative power output: -17.3 V ±150 mV
maximum current capability (both +17.3 V and -17.3 V supply): 300 mA
offset current: Variable from zero to ±5 mA
operating temperature: 0 to 55°C
operating humitity: 95% relative humidity at 40°C
net weight: 1.5 kg (3.4 lbs.)
shipping weight: 2.4 kg (5.4 lbs)
power requirements: 90 to 132 / 198 to 264 Vac, 47 to 440 Hz, 40 VA maximum
Dimensions: 211 mm (W) x 173 mm (D) x 78 mm (H) (8.3 x 6.8 x 3.1 inches)SKU: n/a -
Detector
HP-Agilent/Keysight 11664A

HP 11664A is a detector designed for operation with the 8757/8756/8755 scalar network analyzers. The detect the envelope of the 27.8 kHz modulated RF signal to be displayed on the scalar network analyzer.
Frequency Range: 10 MHz to 18 GHz
Range: +16 dBm to -60 dBm
Maximum input power: +20 dBm (100 mW)
Input impedance: 50 ohms
Connector: N(m)
DatasheetSKU: 80
-
